- Page 1 Owner’s Guide and Installation Manual Series Fan Attach sales receipt to this card and retain as your proof of purchase DATE OF PURCHASE: RETAILER NAME: RETAILER ADDRESS: MODEL NUMBER: 9.3 kgs 20.5 lbs Total fan weight with light kit...
- Page 2 Cautions and Warnings WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70), including fire-rated construction.
- Page 3 Mounting plate Before you begin installing the fan, Switch Before installing this fan make sure the Use metal outlet box suitable for fan power off at Service panel and lock outlet box is properly installed to the support and use only the screws provided service disconnecting means to prevent house structure.
- Page 4 Grounded wires Ungrounded wires After making the wire connections, the wires Loosen 2 screws across from each other Lift motor assembly, aligning the keyhole should be spread apart with the grounded slots with the preassembled screws on and remove the other 2 preassembled conductor and the equipment-grounding mounting plate, and twist clockwise till screws from side of mounting plate...
- Page 5 Install LED Light Kit Install blanking plate LED Module Light shade Light plate LED light kit Reverse switch Connect white wire from fan to white wire Setting the reverse switch on the left Remove LED module and Light shade from LED light kit and then connect blue hand side will result in downward airflow from Light plate as shown in illustration.
- Page 6 Wall Control Wiring, Installation and Operation Warning: Before proceeding, be sure to shut off electricity at main switch or circuit breaker in order to avoid electrical shock. Note: Before installing the wall transmitter, place it in OFF position. (Fig.2) Make series-wound connection for the wall controller with HOT wire from house and lead wires from fan.
- Page 7 Trouble Shooting Warning Trouble Suggested Remedy CAUTION CAUTION CAUTION...
