CAUTION: The slides are lightly greased. Handle them carefully to avoid
soiling your clothing.
1. Attach a front mounting bracket
per bracket.
Make sure that on the right side, the tab on the bracket faces up and on the
left side, it faces down.
2. Pull the narrow segment of the slide
pressing the green release button
3. Attach the narrow segment of the slide to the system with five cap
screws
.
4. Repeat the procedure for the other slide.
along each edge, using one hex screw
out and detach it completely by
and continuing to pull.
Installing a System into a Cabinet
5
