ITC 450/470
User manual
Register Write Range
32h Yes
33h Yes 0 ÷ 999
34h Yes 0 ÷ 999
35h Yes
36h Yes
37h Yes -999 ÷ 9999
38h Yes -999 ÷ 9999
39h Yes -999 ÷ 999
3Ah Yes
3Bh Yes 0 ÷ 999
3Ch Yes 0 ÷ 999
3Dh Yes
3Eh Yes
3Fh Yes -999 ÷ 9999
40h Yes -999 ÷ 9999
41h Yes -999 ÷ 999
42h Yes
43h Yes 0 ÷ 999
44h Yes 0 ÷ 999
"modE" parameter in "rEL1" menu: 0 - "noAC" mode; 1 - "on" mode; 2 - "oFF" mode;
0 ÷ 5
3 - "in" mode; 4 - "out" mode; 5 - "modb" mode
"t on" parameter in "rEL1" menu, expressed in tenth of seconds or
tenth of minutes depend on "unit" parameter - register no. 35h)
"toFF" parameter in "rEL1" menu, expressed in tenth of seconds
or tenth of minutes depend on "unit" parameter - register no. 35h)
"unit" parameter in "rEL1" menu:
0 ÷ 1
0 - seconds; 1 - minutes
"AL" parameter in "rEL1" menu:
0 ÷ 2
0 - no changes; 1 - on; 2 - off
"SEt2" parameter in "rEL1" menu, no decimal point included
"SEtP" parameter in "rEL2" menu, no decimal point included
"HySt" parameter in "rEL2" menu, no decimal point included
"modE" parameter in "rEL2" menu: 0 - "noAC" mode; 1 - "on" mode; 2 - "oFF" mode;
0 ÷ 5
3 - "in" mode; 4 - "out" mode; 5 - "modb" mode
"t on" parameter in "rEL2" menu, expressed in tenth of seconds or
tenth of minutes depend on "unit" parameter - register no. 3Dh)
"toFF" parameter in "rEL2" menu, expressed in tenth of seconds
or tenth of minutes depend on "unit" parameter - register no. 3Dh)
"unit" parameter in "rEL2" menu:
0 ÷ 1
0 - seconds; 1 - minutes
"AL" parameter in "rEL2" menu:
0 ÷ 2
0 - no changes; 1 - on; 2 - off
"SEt2" parameter in "rEL2" menu, no decimal point included
"SEtP" parameter in "rEL3" menu, no decimal point included
"HySt" parameter in "rEL3" menu, no decimal point included
"modE" parameter in "rEL3" menu: 0 - "noAC" mode; 1 - "on" mode; 2 - "oFF"
0 ÷ 5
mode; 3 - "in" mode; 4 - "out" mode; 5 - "modb" mode
"t on" parameter in "rEL3" menu, expressed in tenth of seconds or
tenth of minutes depend on "unit" parameter - register no. 45h)
"toFF" parameter in "rEL3" menu, expressed in tenth of seconds
or tenth of minutes depend on "unit" parameter - register no. 45h)
Register description
