Level Pro ITC 450 User Manual page 48

ITC 450/470
User manual
Register Write Range
16h Yes 0 ÷ 999
17h Yes 0 ÷ 199
18h Yes -99 ÷ 99
19h Yes
Yes 0 ÷ 199
2
20h
No 20D8h
21h
Yes
3
22h
4 Yes
23h
Yes see descr.
24h
Yes
25h
Yes
27h
Yes
28h
Yes
29h
Yes
2Ah
Yes
2Bh
Yes
2Ch
2Dh Yes
2Fh Yes
30h Yes -999 ÷ 9999
31h Yes -999 ÷ 999
"Lo r" parameter in "InPt" menu, in 0.1%
"Hi r" parameter in "InPt" menu, in 0.1%
"toFS" parameter in "InPt" menu (shift of measurement scale),
expressed by 0.1°C (for RTD input) or by 1.0°C (for TC input)
"Conn" parameter in "InPt" menu (RTD input connection method):
0 ÷ 2
0 - "4 in"; 1 - "3 in"; 2 - "2 in"
Device address
Device identification code (ID)
"bAud" parameter in "rS" menu (baud rate);
0 ÷ 7
0 - 1200 baud; 1 - 2400 baud; 2 - 4800 baud; 3 - 9600 baud;
4 - 19200 baud; 5 - 38400 baud; 6 - 57600 baud; 7 - 115200 baud
"mbAc" parameter in "rS" menu (permission to write registers via
0 ÷ 1
RS-485 interface); 0 - write denied ; 1 - write allowed
Parameters of "SECU" menu (binary format (0 - „oFF", 1 - „on"):
bit 0 - "A r1" parameter; bit 1 - "A r2" parameter
bit 2 - "A r3" parameter; bit 3 - "A r4" parameter
"rESP" parameter in "rS" menu (additional response delay);
0 ÷ 5
0 - no additional delay; 1 - "10c" option; 2 - "20c" option;
3 - "50c" option; 4 - "100c" option; 5 - "200c" option;
"mbtO" parameter in "rS" menu (maximum delay between received frames);
0 ÷ 99
0 - no delay checking;
1 ÷ 99 - maximum delay expressed in seconds
"AL" parameter in "bEEP" menu: 0 - off; 1 - on
0 ÷ 1
"R1" parameter in "bEEP" menu: 0 - off; 1 - on
0 ÷ 1
"R2" parameter in "bEEP" menu: 0 - off; 1 - on
0 ÷ 1
"R3" parameter in "bEEP" menu: 0 - off; 1 - on
0 ÷ 1
"R4" parameter in "bEEP" menu: 0 - off; 1 - on
0 ÷ 1
"bri" parameter (display brightness);
1 ÷ 8
1 - the lowest brightness; 8 - the highest brightness
"Edit" parameter (numerical parameters edit mode);
0 ÷ 1
0 - „dig" mode; 1 - „SLid" mode
"SEtP" parameter in "rEL1" menu, no decimal point included
"HySt" parameter in "rEL1" menu, no decimal point included
Register description
