Dynojet POWER COMMANDER V Installation Instructions Manual page 4

FIG.D
FIG.E
Unplug
FIG.F
20-052 www.powercommander.com
5 Secure the PCV ground wire with the small ring lug to the negative (-) terminal
of the bike's battery (Fig. D).
6 On the left side of the rear cylinder throttle body, locate and unplug the bike's
lower primary Throttle Position Sensor (Fig. E).
There is a secondary TPS with the same connector higher up on the same
throttle body. Make sure you are going to the lower primary TPS.
7 Plug the pair of the 3-pin connectors on the PCV wiring harness in-line of the
bike's TPS and the stock wiring harness (Fig. F).
2017-2018 Suzuki DL1000 (V-Strom) - PCV - 4
