Dynojet POWER COMMANDER V Installation Instructions Manual page 3

FIG.A
Remove
FIG.B
FIG.C
20-052
Remove
Remove
Remove
www.powercommander.com
1 Remove the seat, the body panels surrounding the fuel tank, and remove the
fuel tank (Fig. A).
2 Remove the airbox (Fig. B).
3 Using the supplied Velcro, secure the PCV module in the tail section (Fig. C).
Clean both surfaces with the supplied alcohol swab prior to applying the
Velcro adhesive.
4 Route the PCV wiring harness forward towards the engine following along the
left side frame rail.
2017-2018 Suzuki DL1000 (V-Strom) - PCV - 3
