  • Page 1 G5 Intelligent PDU User Manual v4.7...
  • Page 2 Setting Up the System for RADIUS Authentication ............ 51 Configuring the system with LDAP Server Settings ........... 52 Section 3 – Simple Network Management Protocol (SNMP) ......... 57 SNMP Management Configuration ................57 Configuring Users for SNMP V1/V2c ................. 59 PANDUIT G5 PDU USER MANUAL...
  • Page 3 Controlling the Beacon.................... 101 The Status LED ....................... 103 Setting Status LED State ..................104 Handle and Compatible Card Types ................ 104 Section 8 – Panduit G5 Accessories ................105 Hardware Overview ....................105 PANDUIT G5 PDU USER MANUAL...
  • Page 4 Other Features ......................111 Warranty and Regulatory Information................112 Warranty Information ....................112 Regulatory Information .................... 112 Panduit Support and Other Resources ................ 113 Accessing Panduit Support ..................113 Acronyms and Abbreviations ..................115 Appendix A: Sensor Configuration ................109 Door Switch Sensor ....................
  • Page 5 Trap Codes assigned to Alarms List ................ 122 Appendix F: Panduit Network Controller Replace or Rotate 180° ....... 129 Appendix G: Direct connect to the PDU by Changing Your PC’s IP Address ....131 Appendix H: Command Line Interface (CLI) ..............137 CLI Commands ......................
  • Page 6 Figure 32: Email Setup ....................43 Figure 33: SMTP Account Settings ................44 Figure 34: Email Recipients ..................45 Figure 35: Event Notifications ..................46 Figure 36: Data Log....................... 48 Figure 37: Data Log Configuration ................49 PANDUIT G5 PDU USER MANUAL...
  • Page 7 Figure 72: Electronic Security Handles ................. 91 Figure 73: Connection Diagram for Electronic Security Handle ........92 Figure 74: Rack Access Control Web GUI ..............94 Figure 75: Rack Access Control Actions Web GUI ............94 PANDUIT G5 PDU USER MANUAL...
  • Page 8 Figure 105: Internet Protocol Version 4 ............... 135 Figure 106: IP Settings for Direct Connection ............. 136 Figure 107: Connect MA017 to the PDU In/Serial port ..........138 Figure 108: Serial Cable Pinout .................. 139 PANDUIT G5 PDU USER MANUAL...
  • Page 9 Section 1 – System Overview PDU Controller All Panduit G5 Intelligent PDUs feature a Rotatable or Hot Swappable Intelligent Network Controller (iNC). This centralized piece of intelligent hardware receives an IP address, contains a Graphical Web Interface and is addressable over the network.
  • Page 10 3. Verify access to the Web interface. The Ethernet LED on the PDU front panel provides communication status by color and display activity (see Figure 2). Status LED Serial In Figure 2: Status LED & Serial In Port Identified Additional details in Appendix PANDUIT G5 PDU USER MANUAL...
  • Page 11 Changing Your Password At initial login, you are required to change the default password: 1. Enter the current password and new password twice to confirm. By default, passwords must be between 8 and 32 characters. PANDUIT G5 PDU USER MANUAL...
  • Page 12 2. Click Change Password to complete the password change. After the initial login, change the password by the following steps: 1. Go to User Name and select Change Password. Figure 4: After Login 2. The Change User Password window opens. PANDUIT G5 PDU USER MANUAL...
  • Page 13 Logging in to the Web Interface • Open a supported web browser and enter the IP address of the PDU (HTTPS) • If browser displays “refused to connect” please double check that you are using the “https://” protocol not “http://” PANDUIT G5 PDU USER MANUAL...
  • Page 14 If username and password have NOT been configured, use the default username: admin and password: 12345678. For security purposes, a change of password is required upon initial login. o If admin credentials are lost use Appendix D to factory reset the PDU. PANDUIT G5 PDU USER MANUAL...
  • Page 15 Introduction to the Web GUI Login Page Note: https:// must be used (for initial login) Figure 7: Login Page Landing Page/Dashboard Figure 8: Landing Page/Dashboard PANDUIT G5 PDU USER MANUAL...
  • Page 16 Receiver, Thresholds, and Rack Access Control. The search icon allows you to input key words and search for the related results. Information about the PDU can be found using this icon. You also can also PANDUIT G5 PDU USER MANUAL...
  • Page 17 Screen Resize Due to Multiple PDU Configuration Resizing a Screen Multiple PDUs can now cause the user to resize the screen to fit the information on the dashboard due to the update. Figure 9 - Resized Dashboard Screen PANDUIT G5 PDU USER MANUAL...
  • Page 18 Menu Dropdowns Overview Alarms Help Language Logs Settings Admin Introduction to the Dashboard Power Summary Page Figure 10: Power Summary Page PANDUIT G5 PDU USER MANUAL...
  • Page 19 Figure 12: Environmental Monitoring Page Security Monitoring Page Figure 13: Security Monitoring Page Network Settings The Network Settings allow management of IP Configuration, Web RESTapi Access Configuration, SSH/FTPs Configuration, Network Time Protocol (NTP), Date/Time Settings and Daylight-Savings Time. PANDUIT G5 PDU USER MANUAL...
  • Page 20 IP Configuration: Web RESTapi Access Configuration can be used to set HTTP, HTTPS or Disable the onboard Web GUI. PANDUIT G5 PDU USER MANUAL...
  • Page 21 The system management information is a way to distinguish the PDU system’s name and location inside the data center. To configure the system management information, select System Management under the gear icon. Figure 14: System Management PANDUIT G5 PDU USER MANUAL...
  • Page 22 Note: If editing ‘system management’ – all fields are required to be filled to save the information. Rack Location The rack location describes the physical location of the rack or cabinet where the PDU PANDUIT G5 PDU USER MANUAL...
  • Page 23 The Power Panel & Core Location describes the name of each PDU that is part of the PDU system. It also indicates the location of the PDUs inside the rack or cabinet. To configure, follow these steps: 1. Select the pencil icon next to Power Panel & Core Location. PANDUIT G5 PDU USER MANUAL...
  • Page 24 You can set the internal clock manually or link to a Network Time Protocol (NTP) server and set the date and time: Manually Setting Time and Date 1. Go to Network Settings and select Date/Time Settings. PANDUIT G5 PDU USER MANUAL...
  • Page 25 Time is measured in 24-hour format. Enter 13 for 1:00pm, 14 for 2:00pm, etc. 4. Press Save. Link to a Network Time Protocol (NTP) 1. Go to Network Settings and select Network Time Protocol (NTP). Figure 18: NTP Configuration PANDUIT G5 PDU USER MANUAL...
  • Page 26 1. Go to Network Settings and select Daylight Saving Time. Figure 19: Daylight Saving Time Configuration 2. Ensure Enable is selected. 3. Select the specifics of the Start Month: • Month • Week • Day • Time PANDUIT G5 PDU USER MANUAL...
  • Page 27 Outlet Power Management Naming an Outlet For Panduit PDUs with outlet level control or monitoring, you can customize each outlet and view all circuit breaker to outlet associations through the Web GUI. 1. In the Control & Manage tab, expand the Outlet Information folder by clicking the pencil icon.
  • Page 28 3. Select the desired Power Control from the dropdown menu. 4. Select Apply. Setting the Outlet Power On/Off Delay for Panduit PDUs This is only applicable to outlet-switched PDUs. When the PDU is turned ON, outlets will consecutively power on from Outlet 1 to the highest available outlet number.
  • Page 29 Select Outlet Control Enabled Figure 21: Outlet Control Enabled 3. For each Outlet select the Edit pencil. Figure 22: Edit Outlets 4. In the Edit Outlet window enter the On-Delay time (0-7200 seconds) then select Save. PANDUIT G5 PDU USER MANUAL...
  • Page 30 5. Your Outlet Power Sequence has been set. Figure 24: Saved Sequence Setting Metering Thresholds Power Threshold The PANDUIT PDU will send alert notifications when a power threshold wattage crosses above or below the settings you specify in the Power Threshold configuration: PANDUIT G5 PDU USER MANUAL...
  • Page 31 Figure 25: Power Threshold 3. Select and enter the appropriate thresholds in amps and click Save. • Lower Critical (W) • Lower Warning (W) • Upper Warning (W) • Upper Critical (W) • Reset Threshold (W) PANDUIT G5 PDU USER MANUAL...
  • Page 32 4. Repeat steps 1 - 3 for all PDUs. Energy Threshold The PANDUIT PDU will send alert notifications when an energy threshold kilowattage crosses above or below the settings you specify in the Energy Threshold configuration: 1. Go to the Thresholds > Energy Page.
  • Page 33 This prevents several threshold alerts from being generated if the measurements return to normal immediately after rising above an upper threshold or dropping below a lower threshold. 4. Repeat steps 1 - 3 for all PDUs. PANDUIT G5 PDU USER MANUAL...
  • Page 34 Phase Current Alarm Threshold The PANDUIT PDU will send alert notifications when a phase current alarm amp crosses above or below the settings you specify in the Phase Current Alarm configuration: 1. Go to the Thresholds > Phase Page. 2. Click the Pencil for the Phase Current Alarm to update.
  • Page 35 4. Repeat steps 1 - 3 for all phases. Phase Voltage Alarm Threshold The PANDUIT PDU will send alert notifications when a phase voltage crosses above or below the settings you specify in the Phase Voltage Alarm configuration: 1. Go to the Thresholds > Phase Page.
  • Page 36 • Upper Warning (V) • Upper Critical (V) • Reset Threshold (V) The Reset threshold is the number of amps the reading needs to fall below the threshold setting for the condition to be cleared. PANDUIT G5 PDU USER MANUAL...
  • Page 37 4. Repeat steps 1 - 3 for all phases. Circuit Breaker Alarm Threshold The PANDUIT PDU will send alert notifications when a circuit breaker amperage crosses above or below the settings you specify in the Circuit Breaker Alarms configuration: 1.
  • Page 38 Figure 29: Load Segment Breaker 3. Select and enter the appropriate thresholds in amps and click Save. • Lower Critical (A) • Lower Warning (A) • Upper Warning (A) • Upper Critical (A) • Reset Threshold (A) PANDUIT G5 PDU USER MANUAL...
  • Page 39 Any detected current below the threshold will be reported as zero. To change this threshold, follow the following steps: 1. Go to the Thresholds > Outlet Page. 2. Click the pencil next to Device Detection Threshold. PANDUIT G5 PDU USER MANUAL...
  • Page 40 3. Change the value for the number of milli-amps to set the threshold. Outlet Alarm Threshold The PANDUIT PDU will send alert notifications when an outlet amperage crosses above or below the settings you specify in the Outlet Alarms configuration: 1.
  • Page 41 Figure 31: Outlet Information 3. Select and enter the appropriate thresholds in amps and then click Save. • Lower Critical (W) • Lower Warning (W) • Upper Warning (W) • Upper Critical (W) • Reset Threshold (W) PANDUIT G5 PDU USER MANUAL...
  • Page 42 Repeat steps 1 - 3 for all outlets. Email Setup The Panduit PDU can be configured to send Emails to specific users when an event occurs. To do this, the information about the SMTP (Simple Mail Transfer Protocol) server needs to be configured.
  • Page 43 Figure 32: Email Setup 2. Select the pencil icon next to SMTP Account Settings and begin filling out the Edit screen. PANDUIT G5 PDU USER MANUAL...
  • Page 44 If the SMTP does not require authentication, a username and password will need to be entered, but they will not be used. • Set Number of Sending Retries. This will be the number of times the PANDUIT G5 PDU USER MANUAL...
  • Page 45 1. Select the pencil icon to display the Email Recipients screen. Figure 34: Email Recipients 2. Enter the desired email address and press Enable. 3. Press Save. Note: A maximum of 5 users can be entered to receive email alerts. PANDUIT G5 PDU USER MANUAL...
  • Page 46 Event Notifications The Panduit G5 iPDU can be configured to provide event notifications. Figure 35: Event Notifications Note: Not every Event Notification applies or is supported by every PDU type even though the toggle switch in the Web GUI may seem like the feature is supported. In that instance the user is advised to ignore that toggle switch.
  • Page 47 Communication Status       Changed Daisy Chain Status       Changed Enter Bootloader Mode       LDAP/Radius Error       PANDUIT G5 PDU USER MANUAL...
  • Page 48 2000 records with up to 13.89 days of data.) Once the data log reaches the maximum of 2000 records, the oldest entries ae overwritten by the newer entries. 1. Go to Logs and select Data Log. Figure 36: Data Log 2. Select the Actions drop-down menu and choose Data Log Configuration. PANDUIT G5 PDU USER MANUAL...
  • Page 49 Only profile. The “Admin Role” is typically the system administrator and has the Administrator Privileges with full operating permissions. By default, the User Role is a Read Only profile. All other users must be added by a user with administrator PANDUIT G5 PDU USER MANUAL...
  • Page 50 8-32 characters in length, and have at least one numeric character, and at least one special character. 4. Use the Roles tab to set full or read only privileges. 5. Select Add User to save the new user profile. PANDUIT G5 PDU USER MANUAL...
  • Page 51 2. Select the red X next to user name. Setting Up the System for RADIUS Authentication 1. Go to User Settings in the admin menu. Figure 38: User Settings 2. Go to RADIUS Configuration and click the edit pencil. PANDUIT G5 PDU USER MANUAL...
  • Page 52 Note: By default, a RADIUS user will have the “user” Role if one is not specified. The administrator of the RADIUS server may configure a Panduit vendor (19536) dictionary, with a “User-Role” integer attribute set to User (1) or Admin (2). When this User-Role attribute is the first attribute for the user, that user will have the admin Role after logging in.
  • Page 53 7. Enter the password in the Bind Password and Confirm Password fields. 8. In the Search User DN field: DC=subdomain DC=mydomain DC=com 10 9. In the Login Name Attribute field, enter sAMAccountName (typically). 10. In the User Entry Object Class field, enter person. PANDUIT G5 PDU USER MANUAL...
  • Page 54 Within the Active Directory, create a group for the users that you wish to be PDU administrators. i.e. admins Note: There are no limits to the amounts of admins that the PDU imposes. However, there may be limits by the LDAP server. PANDUIT G5 PDU USER MANUAL...
  • Page 55 Within the PANDUIT PDU Web Interface, go to User Settings (under admin menu) > Roles. Enter the Role Name that was created in AD. i.e. admins Enable role privileges as needed (pictured below). Figure 41: Enable Role Privileges LDAP authentication is ready to use.
  • Page 56 Figure 42: Test LDAP Configuration Note: Be sure to log in without a domain name. PANDUIT G5 PDU USER MANUAL...
  • Page 57 Protocol (SNMP) SNMP Management Configuration Setup SNMP 1. Access the Web interface and login. 2. Under SNMP Managers, select SNMP General (or type SNMP in the search). The SNMP General page displays. Figure 43: SNMP Management PANDUIT G5 PDU USER MANUAL...
  • Page 58 3. The SNMP General includes SNMP Access and Version. Figure 44: SNMP General Setup SNMP Port 1. Access the Web interface and log in. 2. Under SNMP Managers, select SNMP Port. The SNMP Port page displays. PANDUIT G5 PDU USER MANUAL...
  • Page 59 Configuring Users for SNMP V1/V2c 1. Access the Web interface and log in. 2. Under SNMP Manager, select SNMP V1/V2c. 3. In the SNMP V1/V2c panel, select the SNMP V1/V2c manager to configure. Select the pencil icon. PANDUIT G5 PDU USER MANUAL...
  • Page 60 4. The Edit panel pop up displays. Figure 48: Edit V1/2c Manager 5. Set the following options: • IP Address: the IP address of the host for this SNMP V1/V2 manager. Only requests from this address will be acted upon. PANDUIT G5 PDU USER MANUAL...
  • Page 61 3. In the SNMP V3 panel, select the SNMP V3 manager to configure. Select the pencil icon in the last column. Figure 49: SNMP V3 Manager 4. The Edit panel pop-up displaying the configurable options. PANDUIT G5 PDU USER MANUAL...
  • Page 62 • NoAuthNoPriv: No authentication and no privacy. This is the default. • AuthNoPriv: Authentication and no privacy. • AuthPriv: Authentication and privacy. 7. Enter a new unique password to be used for authentication 8. Select the desired authentication algorithm. • MD5 • SHA PANDUIT G5 PDU USER MANUAL...
  • Page 63 3. Enter the Name, Host, and a community name in the fields provided. a. The name is a user assigned name to help distinguish the different receivers. b. The host name is the IP Address to which the traps are sent by the SNMP PANDUIT G5 PDU USER MANUAL...
  • Page 64 The host name is the IP Address to which the traps are sent by the SNMP system agent. 4. Choose a Security Level from the dropdown menu • NoAuthNoPriv: No authentication and no privacy. This is the default. PANDUIT G5 PDU USER MANUAL...
  • Page 65 7. Enter the key from the SNMP Server for privacy algorithm 8. Select the desired privacy algorithm • AES-128 • AES-192 • AES-256 9. Select Enable to enable the receiver. 10. Select Save to save and exit. PANDUIT G5 PDU USER MANUAL...
  • Page 66 Section 4 – Cisco Nexus Dashboard Integration The Panduit G5 PDU is specially designed, tested and validated to integrate into the Cisco Nexus Dashboard. To integrate the PDUs into the dashboard please see instructions at Panduit.com [LINK] Document Title: Panduit Collector for Cisco Nexus Dashboard Installation Guide...
  • Page 67 Standby mode: This happens when a PDU is idle (no buttons pushed) for 30 seconds while in Menu mode. • In Standby mode, the PDU scrolls through key power values (Frequency, Amps, Volts, Watts, and kVA) and IP addresses (for both IPv4 and IPv6). PANDUIT G5 PDU USER MANUAL...
  • Page 68 Status LED The LED will change colors depending on the state of the PDU. LED State Description Solid Green Normal Operation Solid Red Critical or Warning Alarm Flashing Orange No network connection PANDUIT G5 PDU USER MANUAL...
  • Page 69 The PDU menu selection hierarchy consists of Setup, Alarms, Power, and Sensors. On the main menu, scroll down to highlight Setup. Press Select. Scroll down to select a submenu and press Select to display the submenu options. Press Menu to return to the previous menu. PANDUIT G5 PDU USER MANUAL...
  • Page 70 Network. Press Select to enter the Network Submenu. Scroll down to highlight the selected option from the menu. Press Select to display the screens that display the IP address. Press Menu to return to the previous menu. PANDUIT G5 PDU USER MANUAL...
  • Page 71 Firmware version. On the Setup menu, scroll down to highlight Device submenu. Press Select to enter the Device Submenu. Scroll down to the item you wish to display, and press Select. Press Menu to return to the previous menu. PANDUIT G5 PDU USER MANUAL...
  • Page 72 The Screen submenu allows you to customize settings for Contrast, Rotate, and Always on. In the Setup menu, scroll down to highlight Screen. Press Select to select the submenu. Press Menu to return to the previous menu. PANDUIT G5 PDU USER MANUAL...
  • Page 73 Setup menu, scroll down to highlight Lang. Press Select to display the screens to select the submenu. After you select the values, press Select to set the values as displayed on the screen. Press Menu to return to the previous menu. PANDUIT G5 PDU USER MANUAL...
  • Page 74 Note: If a USB drive is not present in the USB slot the PDU will enter normal operation. Note: If you are in USB mode and you want to exit USB mode, you must remove the USB drive before existing USB mode. Otherwise, the PDU will reboot and re-enter USB mode. PANDUIT G5 PDU USER MANUAL...
  • Page 75 Figure 61: USB Submenu PANDUIT G5 PDU USER MANUAL...
  • Page 76 Units. Press Select to enter the Units Submenu. After you select the values, press Select to set the values as displayed on the screen. Press Menu to return to the previous menu. Note: This can only be done locally at the PDU. Figure 62: Units Submenu PANDUIT G5 PDU USER MANUAL...
  • Page 77 The Alarms menu displays active alarms for the PDU. On the Main Menu, scroll down to highlight Alarms. Press Select to display the Alarm Screen. When you finish your review, press Menu to return to the main menu. Figure 63: Alarms Menu PANDUIT G5 PDU USER MANUAL...
  • Page 78 The Power menu manages device, phase, breaker and outlet. On the Main Menu, scroll down to highlight Power. Press Select. Scroll down to select a submenu and press Select to display the submenu options. Press Menu to return to the previous menu. Figure 64: Power Menu PANDUIT G5 PDU USER MANUAL...
  • Page 79 The Device submenu is to display current, voltage and power. On the Power menu, scroll down to highlight Device. Press Select to display the power values for the entire PDU. Press Menu to return to the previous menu. Figure 65: Device Submenu PANDUIT G5 PDU USER MANUAL...
  • Page 80 Phase. Press Select to display the screens to set the values for the submenu. After you select the phase, press Select to display the values for that phase on the screen. Press Menu to return to the previous menu. Figure 66: Phase Submenu PANDUIT G5 PDU USER MANUAL...
  • Page 81 The Breaker submenu is to display power values for the breakers. Press Select to display the values of the first breaker. To go to the next breaker, Select next. Press Menu to return to the previous menu. Figure 67: Breaker Submenu PANDUIT G5 PDU USER MANUAL...
  • Page 82 Note: Custom outlet names noted in the Web GUI do not make changes to the local display. This is done to make it easier to map to outlet numbers which can locally be seen on the outlets themselves. PANDUIT G5 PDU USER MANUAL...
  • Page 83 Main Menu, scroll down to highlight Sensor. Press Select. This will display the sensor data for the first sensor. To go to the next sensor, Select next. Press Menu to return to the previous menu. Figure 69: Sensors NOTE: Maximum of 8 sensors are configured per PDU. PANDUIT G5 PDU USER MANUAL...
  • Page 84 PDUs for each IT rack. PDUs used in RNA applications must be the same SKU/Part Number. A maximum of (2) PDU can be used in the RNA convention. See the below figure for a connection diagram when deploying RNA. PANDUIT G5 PDU USER MANUAL...
  • Page 85 To set up RNA mode on two PDUs, the user must (1) configure the PDUs for RNA Mode (using CLI) and then (2) connect the LAN Network cords and Ethernet cords between PDUs. To Configure RNA Mode in the CLI PANDUIT G5 PDU USER MANUAL...
  • Page 86 6. To enable this account, login to the CLI with admin credentials. 7. Enter the command ‘dev daisy rna init’. 8. The following message will appear to confirm the landlord account is enabled: SUCCESS. 9. RNA is now configured and enabled. PANDUIT G5 PDU USER MANUAL...
  • Page 87 MA031 is required for the power share function. However, due to limited available power from the Panduit iPDU Controller, power share was designed and tested under the following conditions: ACF05 or AC06 Electronic Security Handle, ACF10 (T+D), ACF11 (3T+D). Care must be taken to not overload the system with accessories as this may cause instability or power share to become unavailable.
  • Page 88 The iPDU controller has a maximum output power capacity of 800mA @ 5V = 4 watts. Based on this, DO NOT deploy the Automatic Light Bar (PN: ACD01) when deploying solutions leveraging Power Share. Uniquely designed power share patch cord MA031 is required for the power share function. PANDUIT G5 PDU USER MANUAL...
  • Page 89 Figure 71: Connection Diagram Power Share & Daisy Chain To confirm that your controller has Power Share from the Web GUI Home → Control & Manage → Power Share Enable power share under the edit menu. PANDUIT G5 PDU USER MANUAL...
  • Page 90 PANDUIT G5 PDU USER MANUAL...
  • Page 91 Section 7 – Electronic Security Handle The Panduit Intelligent PDUs allow users to electronically secure and control access to cabinets. G5 PDU Firmware v3.3.1 (or higher is required). For the latest firmware please visit: panduit.com → Support → Download Center → PDUs Note: For security, verify that the handle is seated prior to engaging locking mechanism.
  • Page 92 Use the below table to help count total sensors being deployed. Part Number Number onboard Device connects to Sensors ACF05 Panduit G5 PDU ACF06 Panduit G5 PDU ACF11 Panduit G5 Handle ACF10 Panduit G5 Handle ED001 Panduit G5 PDU EE001 Panduit G5 PDU PANDUIT G5 PDU USER MANUAL...
  • Page 93 Panduit G5 PDU EC001 Panduit G5 PDU Note: A maximum of 8 sensors can be managed by the Panduit G5 PDU controller. A maximum of 2 handles can be managed by each individual Panduit G5 iPDU. Configuring Cabinet Access Control All Rack Access Control configuration can be done under the Rack Access Control Page from the Web GUI.
  • Page 94 3. The Actions Menu on the right side of the page will allow the user to Add Card, Rack Access Settings, Handle Settings, Keypad Settings, Remote Control, Beacon Settings, and Status LED Settings. Figure 75: Rack Access Control Actions Web GUI PANDUIT G5 PDU USER MANUAL...
  • Page 95 4. The number in the message is the card ID. Adding a Local access user 1. To add a new card (or user), select Add Card from the Actions menu. Figure 76: Local Rack Access Web GUI PANDUIT G5 PDU USER MANUAL...
  • Page 96 The Rack Access Setting are common to the entire system. These include Aisle Control, AutoLock Time, Door Open Time, and Max Door Open Time. 2. To update the rack access settings, select Rack Access Settings from the Actions menu. PANDUIT G5 PDU USER MANUAL...
  • Page 97 Keypad Only: Gain access to the cabinet through depressing an authorized secret pin into the keypad: c. Dual Authentication (Card (RFID) + Keypad): First swipe an authorized card then within 5 seconds enter an authorized secret PIN into the keypad. PANDUIT G5 PDU USER MANUAL...
  • Page 98 4. The Firmware Version, Hardware Version and Serial are read-only attributes about the handle. a. Firmware Version is the firmware version running on the handle. b. Hardware Version is the version of hardware of the handle. c. Serial is the serial number of the handle. PANDUIT G5 PDU USER MANUAL...
  • Page 99 The remote control will allow you to remotely open and close a handle. 1. To remotely control a handle, select Remote Control from the Actions menu. Figure 79: Remote Control 2. Select the handle to control: PANDUIT G5 PDU USER MANUAL...
  • Page 100 Under the PDU section, Select the handle 3. Select the action you wish to perform. a. Lock remotely locks the handle b. Unlock remotely unlocks the handle. 4. When finished, click Close. PANDUIT G5 PDU USER MANUAL...
  • Page 101 Any critical alarm in the system. (not customizable) Alarm Warning Blinking Yellow Any warning alarm in the system (not customizable) Alarm Blue, Green, Normal Solid Yellow, Red, Visual indicator on the handle. (customizable) State White, Magenta PANDUIT G5 PDU USER MANUAL...
  • Page 102 1. To control a handle beacon, select Beacon Settings Control from the Actions menu. Figure 81: Beacon Settings Web GUI 2. Select the function of the beacon: a. Standby –beacon color no alarms b. Locate –flash beacon 3. Select color for Standby or Locate. 4. Select Save. PANDUIT G5 PDU USER MANUAL...
  • Page 103 Handle open past Door Open Time (not customizable) Lock open for longer than Autolock Time. (look for obstruction) Red - Solid (not customizable) Door open for longer than Door Open Time (door sensor) Red - Solid (not customizable) PANDUIT G5 PDU USER MANUAL...
  • Page 104 The table below lists which cards are supported on the different swing handles. MIFARE® MIFARE MIFARE® HID® HID® Classic Plus® DESFire® iCLASS 125kHz 125kHz Prox Prox ACF05 ACF06 CSN = Card Serial Number / UID = Unique Identifier PANDUIT G5 PDU USER MANUAL...
  • Page 105 IT room atmosphere. Note: A maximum of 8 sensors can be managed by the Panduit G5 PDU controller. Sensors may be installed with PDUs powered on. The following table lists available sensors as well as sensor count:...
  • Page 106 30m. Panduit G5 Dry Contact Input to the G5 iPDU and Sensor (ACC01) designed to monitor a change in contact state. Sensor Sensor Figure 83: Sensor Ports for Vertical PDU PANDUIT G5 PDU USER MANUAL...
  • Page 107 2. The button at the top of the screen can be used to select Celsius or Fahrenheit. Figure 86: Celsius Setting Figure 87: Fahrenheit Setting Configuring Environmental Sensors To configure the sensor location, alarms, notifications, and details, open the WEB Interface: PANDUIT G5 PDU USER MANUAL...
  • Page 108 5. Go to External Sensors. 6. Select Edit button to configure the desired sensors. 7. In the Edit dialog box, type value of up critical, up warning, low warning, and low critical. Select Save to exit the sensor setup. PANDUIT G5 PDU USER MANUAL...
  • Page 109 Network Configuration Data Network Configuration, including Static IP addresses and addresses obtained by • DHCP are exposed on an “Identification” page and on a Network Configuration page, to aid in network management of the product. PANDUIT G5 PDU USER MANUAL...
  • Page 110 • • LDAP is not encrypted over the network. • The remote LDAP server authenticity (fingerprint) is not validated. • The Radius protocol is designed to only transmit hashed and obfuscated passwords over the network. PANDUIT G5 PDU USER MANUAL...
  • Page 111 Other Features The product includes a real-time clock and a capacitor that maintains time for a • short amount of time when no power is applied. When combined with NTP, accurate timestamps on logs are provided. PANDUIT G5 PDU USER MANUAL...
  • Page 112 Warranty and Regulatory Information Warranty Information (http://www.Panduit.com) Regulatory Information Safety and regulatory compliance For important safety, environmental, and regulatory information, see Safety and Compliance Information at the Panduit website (http://www.Panduit.com) PANDUIT G5 PDU USER MANUAL...
  • Page 113 Panduit Support and Other Resources Majority of your support needs can be met by visiting Panduit.com and navigating to the respective product page. If you require additional assistance; we are here to help. Accessing Panduit Support North America Europe / Middle East...
  • Page 114 Global PDU System Support: • Firmware Updates • Bulk Configuration DCIM Software Support Email: systemsupport@panduit.com Phone: 1-866-721-5302 PANDUIT G5 PDU USER MANUAL...
  • Page 115 Gigabyte Secure Hash Algorithms Graphical User Interface SNMP Simple Network Management Protocol Internet Protocol TCP/IP Transmission Control Protocol/Internet Protocol Kilo-Volt-Ampere USB Universal Serial Bus V Volts Kilowatts kWH Kilowatt Hour Watts LAN Local Area Network PANDUIT G5 PDU USER MANUAL...
  • Page 116 Figure 88: Door Switch Sensor Configuration Note: The Door Switch Sensor is only designed to connect to a Panduit PDU. Connecting it to another device may result in damage.
  • Page 117 Figure 89: Dry Contact Cable Note: The dry contact cable is only designed to connect to a Panduit PDU. Connecting it to another device may result in damage. Temperature & Humidity Sensors Temperature and humidity sensors are designed to add comprehensive environmental monitoring to any Panduit PDU.
  • Page 118 Figure 90: Temperature and Humidity Sensors Configuring Environmental Sensors Each Panduit G5 Intelligent PDU features an onboard controller capable of managing a maximum of 8 sensors. To configure the sensor location, alarms, notifications, and details, open the WEB Interface: 8. Open the Settings.
  • Page 119 12. In the Edit dialog box, type value of up critical, up warning, low warning, and low critical. 13. Select Save to exit the sensor setup. Repeat this process for additional sensors. Sensor Port Sensor Port Figure 91: Sensor Ports on controller PANDUIT G5 PDU USER MANUAL...
  • Page 120 1. Open the User interface in a web browser by entering the PDU IP address. 2. Login to with Administration credentials. 3. Go to Settings > System Management > Actions > Update Firmware. 4. In the Firmware Update dialog box, browse to (Panduit.FW) firmware file. Figure 92: Upload Firmware PANDUIT G5 PDU USER MANUAL...
  • Page 121 2. Transfer the updated *FW file to the root directory. Close the FTPs. 3. Connect to the PDU via SSH using a program such as HyperTerm or PuTTY. 4. Login using a role with administration privileges. 5. Enter the command sys upd all. PANDUIT G5 PDU USER MANUAL...
  • Page 122 6. It will show the message: System will enter upgrade mode after reboot, System Reboot now, Are you sure? (Y/N). 7. Enter Y. 8. When the upload is finished, the system will reboot automatically. PANDUIT G5 PDU USER MANUAL...
  • Page 123 Note: Simplify firmware upgrade from 2.x to 3.x using this utility down to a single click. 2. Configuration Replication of Common Parameters a. Pre-set the common parameters (e.g. thresholds, rack access control, etc..) via the Web GUI and download configuration (conf.ini) from the System Management menu. PANDUIT G5 PDU USER MANUAL...
  • Page 124 Load the confi.ini file to the G5 Upgrade Utility and click Start Conf.ini Figure 95: G5 Upgrade Tool Interface 3. Configuration Replication of Un-Common Parameters a. Insert IP Address or Range of the target PDU(s) b. Insert admin credentials c. Edit and Save the .csv file. PANDUIT G5 PDU USER MANUAL...
  • Page 125 Figure 96: Example CSV File d. Load the Config.csv file to the G5 Upgrade Utility and click Start Config.csv Figure 97: G5 Upgrade Tool Interface PANDUIT G5 PDU USER MANUAL...
  • Page 126 To Default the controller to factory settings, press and hold the Reset Button for at least 20 seconds. This will cause a reset of the iNC controller erasing all existing configurations, including username(s) and password(s). It does not change the Energy (kWh) value and does not affect the outlet state. PANDUIT G5 PDU USER MANUAL...
  • Page 127 Circuit Breaker Status ON Circuit Breaker Status OFF Outlet X Active Power Above upper critical Outlet X Active Power Above upper warning Outlet Outlet X Active Power Below lower warning Outlet X Active Power Below lower critical PANDUIT G5 PDU USER MANUAL...
  • Page 128 System Communication Lost Daisy Chain state changed USB Port User Activity User X Authentication failure User Activity User X User logged in User Activity User Activity User X Session timeout User Activity User X User blocked PANDUIT G5 PDU USER MANUAL...
  • Page 129 The circuit breaker (1-12) current is ABOVE critical threshold value 28-30 The circuit breaker (1-12) current is BELOW critical threshold value 40-51 The circuit breaker (1-12) is in OFF state 52-99 The outlet (1-48) active power is ABOVE critical threshold PANDUIT G5 PDU USER MANUAL...
  • Page 130 Trap codes assigned for warning alarms: Trap Class Trap Trap Description Code Warning The PDU unit active power is ABOVE warning threshold value. The PDU unit active power is BELOW warning threshold value. The PDU warning energy alarm. PANDUIT G5 PDU USER MANUAL...
  • Page 131 Trap Trap Description Code Informational 380-391 The circuit breaker (1-12) is in ON state. 392-439 The outlet (1-48) IMMEDIATE ON occurred. 440-487 The outlet (1-48) DELAYED ON occurred. 488-535 The outlet (1-48) IMMEDIATE OFF occurred. PANDUIT G5 PDU USER MANUAL...
  • Page 132 Communication Module reset. Communication Module start. Daisy Chain state changed. User xxx logged in. User xxx session timeout. User xxx blocked. User xxx password changed. User password settings changed. User xxx added. User xxx deleted. PANDUIT G5 PDU USER MANUAL...
  • Page 133 The outlet (1-48) active power current alarm cleared. 838-845 The sensor (1-8) temperature/humidity alarm cleared. 846-853 The sensor (1-8) lost communication alarm cleared. 854-856 Input Phase (1-3) Frequency Deasserted above upper critical 857-859 Input Phase (1-3) Frequency Deasserted below lower critical. PANDUIT G5 PDU USER MANUAL...
  • Page 134 Input Phase Measurement Active Power of PHASE (1-3) asserted 1124-1126 below lower critical Input Phase Measurement Apparent Power of PHASE (1-3) 1127-1129 asserted above upper critical Input Phase Measurement Apparent Power of PHASE (1-3) 1130-1132 asserted below lower critical Warning PANDUIT G5 PDU USER MANUAL...
  • Page 135 Input Phase Measurement Apparent Power of PHASE (1-3) deasserted above upper critical/below lower critical/above 1148-1150 upper warning/below lower warning Role Added by Admin User 1151 Role Deleted by Admin User 1152 Role Modified by Admin User 1153 PANDUIT G5 PDU USER MANUAL...
  • Page 136 Appendix F: Panduit Network Controller Replace or Rotate 180° 1. Use a T10 Torx screwdriver on the screws as shown in Figure 98. The screws are held in with retaining washers. Figure 98: Screws on Network Controller a. Controller may be rotated to accommodate overhead or underfloor power. If rotating controller, YOU MUST DISCONNECT the ribbon cable to prevent damage to the ribbon cable.
  • Page 137 Figure 99: Ribbon Cable for the Network Controller 3. Replace and tighten the two (T10) screws on the Intelligent Network Controller to 2.2 – 3.1 lbf-in (0.25 – 0.35 N-M). Overtightening the screws may result in metal deformation. PANDUIT G5 PDU USER MANUAL...
  • Page 138 Note: Instructions refer specifically to Windows 10. Please refer to your operating system documentation if you are not using Windows 10. 1. Type control into Windows Search and select Control Panel. Figure 100: Control Panel PANDUIT G5 PDU USER MANUAL...
  • Page 139 2. In the Control Panel window, select View network status and tasks under the Network and Internet heading. Figure 101: Network Status and Tasks 3. Select Change adapter settings from the menu on the left. PANDUIT G5 PDU USER MANUAL...
  • Page 140 Figure 102: Change Adapter Settings 4. Right-click Ethernet and select Properties. Figure 103: Properties PANDUIT G5 PDU USER MANUAL...
  • Page 141 Figure 104: Ethernet Properties 5. Select Internet Protocol (TCP/IP) Version 4 (you may need to scroll down). Then click the Properties button. PANDUIT G5 PDU USER MANUAL...
  • Page 142 Figure 105: Internet Protocol Version 4 6. Select the Use the following IP address radio button. The Use the following DNS server addresses radio button then selects automatically. PANDUIT G5 PDU USER MANUAL...
  • Page 143 8. Connect the PDU network connection directly to the PC’s Ethernet card using a patch cable. 9. Power the PDU unit. 10. Open a web browser on the PC. 11. Enter the address bar http://192.168.0.1 into your browser. PANDUIT G5 PDU USER MANUAL...
  • Page 144 ([ ]). For data of type array, the 'x' character as index of array in command input syntax means all indexes. You must be logged into the PDU before commands can be sent. See below for a list of all CLI commands. PANDUIT G5 PDU USER MANUAL...
  • Page 145 Connecting to the CLI through the serial interface An option to communicating through the serial interface is to use the specialized YOST Serial Data Cable Panduit Part Number: MA017. This cable Remaps Panduit G5 Serial Interface to a YOST interface.
  • Page 146 6. Enter your password. Press Enter. 7. You are now logged into the SSH. Refer to the CLI Commands table below for available commands. NOTE: SSH connection is not available when serial connection is enabled. PANDUIT G5 PDU USER MANUAL...
  • Page 147 Panduit>sys time time. Panduit>sys time 14:35:34 Synchronize system date sys ntp <IP Address> >sys ntp 69.25.96.13 and time, with ntp server NOTE: IP Address must be a you set. valid ntp, server address otherwise, executes, failed PANDUIT G5 PDU USER MANUAL...
  • Page 148 NOTE 2: If in daisy chain configuration, main PDUs will upgrade all daisy chain firmware. Update system’s sys upd conf Panduit>sys upd conf configuration. SUCCESS system will enter upgrade mode after reboot System Reboot now, Are you sure? (Y/N):Y PANDUIT G5 PDU USER MANUAL...
  • Page 149 Panduit>net ssh SUCCESS, SSH Port: 22 SSH Server is running Panduit>net ssh on SUCCESS Panduit>net ssh off SUCCESS net ftps [on/off] Query or on/off FTPs. Net ftps SUCCESS FTPS Port: 21 Service is running Is Ftps PANDUIT G5 PDU USER MANUAL...
  • Page 150 (Y/N): Y net tcpip <static ip, mask, Set static IP, mask and Panduit>net tcpip static gateway> gateway. 192.168.30.39 255.255.255.0 192.168.30.1 SUCCESS Network is reconfigured, Please reboot to validate System Reboot now, Are you sure? (Y/N): Y PANDUIT G5 PDU USER MANUAL...
  • Page 151 SUCCESS daisy chain unit number: 1 daisy chain address list: Daisy Mode: RNA Panduit>dev daisy qna SUCCESS System Reboot now, Are you sure? (Y/N): N dev daisy <rna|qna> init Initialize daisychain. Panduit>dev daisy qna init PANDUIT G5 PDU USER MANUAL...
  • Page 152 1; if in daisy chain, the main PDUID is 1, the Daisy chain PDUID’s are 2,3,4. dev outlet <PDUID> Query or set specified Panduit> dev outlet 1 1 off <outlet index> [on|off] PDUID and outlet-index's SUCCESS outlet status. NOTE: For Monitored PDUs, this command is invalid.
  • Page 153 FuncType: PDU Monitored Rating :220-240V, 16A, 3.5-3.8kVA, 50/60Hz Mac :C8:45:44:66:2B:26 Tcpip :192:168:30:38 Panduit>pwr unit 1 SUCCESS PDU UNIT 1 power Feature voltage: 0V current : 0.0A active power: 0W apparent power: 0W power factor: 0.00 energy: 0.000kWh PANDUIT G5 PDU USER MANUAL...
  • Page 154 <idx> Query specified outlet’s Panduit> pwr outlet 1 electric information. SUCCESS PDU OUTLET 1 power Feature voltage: 0V current : 0.0A active power: 0W apparent power: 0W NOTE: For Monitored PDUs, this command is invalid. PANDUIT G5 PDU USER MANUAL...
  • Page 155 User-Role User VALUE User-Role Admin END-VENDOR Panduit 4. Load dictionary.Panduit by appending the following line to /etc/freeradius/3.0/dictionary $INCLUDE /usr/share/freeradius/dictionary.Panduit 5. Add authorized users to with the /etc/freeradius/3.0/mods-config/files/authorize desired role. (Note: the ‘users’ file location may vary based on unique customizations or different package managers.) When specified, the User-Role MUST be the first attribute of the user.
  • Page 156 User-Role. Note: You may need to change this example based on any client restrictions that are enforced. Usage: radtest [OPTS] user passwd radius-server[:port] nas-port-number secret # radtest 'radroleadmin' '34567890’ 192.0.2.1 0 'panduit#1' '' Sending Access-Request of id 212 to 192.0.2.1 port 1812 User-Name = "radroleadmin"...
  • Page 157 KE025X Option 5 Key for Tumbler TU025X Note: Panduit G5 PDU Controller can handle a maximum of 8 sensors. Some part numbers have multiple sensors built in (e.g. EC001 has 4 sensors, ACF05 or ACF06 has 2 sensors). PANDUIT G5 PDU USER MANUAL...
  • Page 158 4: 200-240Vac (Delta), 3 phase 5: 100-240Vac, 1 phase 6: 120-208Vac (Wye), 3 phase #: Different management feature. 0: Basic PDU 1: Metered iPDU 2: Metered, Outlet switched iPDU 5: Outlet Metered iPDU 6: Outlet Metered, Outlet switched iPDU PANDUIT G5 PDU USER MANUAL...
  • Page 159 • Exponential numbers are not supported. • Nested arrays or arrays of objects are not supported. • Maximum object depth is 2. Method Supported URLs GET Response /redfish/v1/SessionService /redfish/v1/SessionService/Sessions /redfish/v1/SessionService/Sessions/{session_ids} /redfish/v1/AccountService /redfish/v1/AccountService/Accounts /redfish/v1/AccountService/Accounts/{username} /redfish/v1/AccountService/Roles /redfish/v1/AccountService/Roles/{rolename} /redfish/v1/Managers PANDUIT G5 PDU USER MANUAL...
  • Page 160 /redfish/v1/AccountService/Accounts /redfish/v1/SessionService/Sessions DELETE /redfish/v1/AccountService/Accounts/{username} Response /redfish/v1/SessionService/Sessions/{session_id} For the code on any of the above listed interfaces – please refer to Panduit TR128-SZ G5 RestfulAPI.pdf For a copy of this document send a request to systemsupport@panduit.com PANDUIT G5 PDU USER MANUAL...

This manual is also suitable for:

Smartzone p18e23m
