Page 1 Intelligent PDU User Manual v1.2...
Page 2: Table Of Contents
Table of Contents Section 1 – System Overview ..................9 PDU Controller ......................9 Connecting the PDU via Ethernet Port ................ 9 Connecting the PDU to a Computer Serial Port ............10 Section 2 – Web Graphical User Interface (GUI) Configuration ........11 Internet Protocol (IP) Addressing ................
Page 3 Remote Controlling the Handle................100 Controlling the Beacon.................... 102 The Status LED ....................... 104 Setting Status LED State ..................105 Handle and Compatible Card Types ................ 105 Section 7 – Panduit G6 Accessories ................106 Hardware Overview ....................106 INTELLIGENT PDU USER MANUAL...
Page 4 Other Features ......................110 Warranty and Regulatory Information ................111 Warranty Information ....................111 Regulatory Information .................... 111 Panduit Support and Other Resources ................ 112 Accessing Panduit Support ..................112 Acronyms and Abbreviations ..................113 Appendix A: Sensor Configuration ................109 Door Switch Sensor ....................
Page 5 Appendix E: PDU Alarms .................... 120 Trap Codes assigned to Alarms List ................ 122 Appendix F: Panduit Network Controller Replace or Rotate 180° ....... 129 Appendix G: Direct connect to the PDU by Changing Your PC’s IP Address ....131 Appendix H: Command Line Interface (CLI) ..............
Page 6 Table of Figures Figure 1: Primary GB Ethernet Port for Network Connection .......... 9 Figure 2: Status LED & Serial In Port Identified ............10 Figure 3: Shows ETH0 & ETH1 and Dual IP Modes ............. 11 Figure 4: Edit ETH0 ....................... 12 Figure 5: Changing Your Password................
Page 7 Figure 38: Email Recipients ..................49 Figure 39: Event Notifications ..................50 Figure 40: Data Log....................... 52 Figure 41: Data Log Configuration ................53 Figure 42: User Settings ....................55 Figure 43: RADIUS Configuration ................. 56 Figure 44: LDAP Configuration ..................58 Figure 45: Enable Role Privileges .................
Page 8 Figure 95: Sensor Ports on controller ................112 Figure 96: Upload Firmware ..................113 Figure 97: G6 Upgrade Tool Interface ................. 116 Figure 98: System Management Download Configuration Web GUI ......117 Figure 99: G6 Upgrade Tool Interface ................. 117 Figure 100: Example CSV File ..................
Page 9: Section 1 - System Overview
Section 1 – System Overview PDU Controller Panduit G6 Intelligent PDUs feature a Rotatable or Hot Swappable Intelligent Network Controller (iNC). This centralized piece of intelligent hardware receives an IP address, contains a Graphical Web Interface and is addressable over the network.
Page 10: Connecting The Pdu To A Computer Serial Port
will restart the DHCP server search process. Connecting the PDU to a Computer Serial Port If unable to connect to network, you can change the network setting using the serial interface. To configure the network setting, perform the following steps: 1.
Page 11: Section 2 - Web Graphical User Interface (Gui) Configuration
IP address (if desired). IPV4, IPV6 or Dual Panduit G6 iPDU features a Dual Ethernet interface where ETH0 is the primary and ETH1 is the internal ethernet interface used during daisy chain. The Panduit G6 also features a full IP stack for either IPV4 or IPV6.
Page 12: Connecting To The Pdu
Figure 4: Edit ETH0 Connecting to the PDU 1. Ethernet port on the PDU indicates solid green light on the right and a flashing yellow light on the left. This indicates successful connectivity to the network. 2. Use the menu buttons to look up the IP address of the device on the OLED display by selecting Setup >...
Page 13: Web Configuration
Web Configuration Supported Web Browsers The supported Web browsers are Google Chrome (mobile and desktop), Mozilla Firefox, Microsoft Edge and Apple Safari (mobile and desktop). Changing Your Password At initial login, you are required to change the default password: 1. Enter the current password and new password twice to confirm. By default, passwords must be between 8 and 32 characters.
Page 14: Figure 6: After Login
Figure 6: After Login 2. The Change User Password window opens. Figure 7: Change User Password 3. Enter the old password and then new password twice to confirm. By default, passwords must be between 8 and 32 characters. INTELLIGENT PDU USER MANUAL...
Page 15: Figure 8: Change Password
Figure 8: Change Password 4. Click Change Password to complete the password change. Logging in to the Web Interface • Open a supported web browser and enter the IP address of the PDU (HTTPS) • If browser displays “refused to connect” please double check that you are using the “https://”...
Page 16: Introduction To The Web Gui
Introduction to the Web GUI Login Page Note: https:// must be used (for initial login) Figure 9: Login Page Landing Page/Dashboard Figure 10: Landing Page/Dashboard Number Icon Description The home icon provides an overview of the PDU with access to the Dashboard, INTELLIGENT PDU USER MANUAL...
Page 17 Number Icon Description Identification, and Control & Manage. The Alarm icon provides details of the active critical alarms and active warning alarms. This icon lets you select a Language. There are seven languages available to choose from: English, Chinese, French, Italian, German, Spanish, Korean and Japanese.
Page 18: Screen Resize Due To Multiple Pdu Configuration
Number Icon Description This icon shows who is logged in (user or admin). Account passwords can be changed, and user accounts managed through this page. Screen Resize Due to Multiple PDU Configuration Resizing a Screen Multiple PDUs can now cause the user to resize the screen to fit the information on the dashboard due to the update.
Page 19: Menu Dropdowns
Menu Dropdowns Overview Alarms Help Language Logs Settings Admin Introduction to the Dashboard Power Summary Page Figure 12: Power Summary Page INTELLIGENT PDU USER MANUAL...
Page 20: Network Settings
Outlet Monitoring Page Figure 13: Outlet Monitoring Page Environmental Monitoring Page Figure 14: Environmental Monitoring Page Security Monitoring Page Figure 15: Security Monitoring Page Network Settings The Network Settings allow management of IP Configuration, Web RESTapi Access Configuration, SSH/FTPs Configuration, Network Time Protocol (NTP), Date/Time Settings and Daylight-Savings Time.
Page 21 IP Configuration (ETH0): IP Configuration (ETH1): INTELLIGENT PDU USER MANUAL...
Page 22 Domain Name System (DNS): INTELLIGENT PDU USER MANUAL...
Page 23 Web RESTapi Access Configuration can be used to set HTTP, HTTPS or Disable the onboard Web GUI. SSH/FTP Configuration: INTELLIGENT PDU USER MANUAL...
Page 24: System Management Information
System Management Information The system management information is a way to distinguish the PDU system’s name and location inside the data center. To configure the system management information, select System Management under the gear icon. Figure 16: System Management System Info The system information includes the name of the PDU system and information of the person to contact in case an issue arises.
Page 25: Figure 17: System Management Configuration
Figure 17: System Management Configuration 2. Enter the System Name: The “system” is the main PDU and all daisy-chained PDUs. A system can have 6 PDUs. 3. Enter the name of the person who should be contacted if there is a problem with the system into the Contact Name section.
Page 26: Figure 18: Rack Location Configuration
Figure 18: Rack Location Configuration 2. Enter the room location of the rack or cabinet that contains the PDU system into Room Name. 3. Enter the name of row where the PDU is located in Row Name. 4. Enter the position of the row where the PDU is positioned in Row Position. 5.
Page 27: Setting Time And Date On The Pdu
Figure 19: Power Panel & Core Location 2. Enter the name of the PDU in the Power Panel Name. 3. Select Front or Back for the Core Location. The Core Location is the side of the rack/cabinet where the PDUs are installed. For vertical PDUs, they are typically installed in the back.
Page 28: Figure 20: Ntp Configuration
2. Enter the date using the YYYY-MM-DD format or use the calendar icon to select a date. 3. Enter the time in the three fields provided: the hour in the first field, minutes in the next field, and seconds in the third field. Time is measured in 24-hour format. Enter 13 for 1:00pm, 14 for 2:00pm, etc.
Page 29: Figure 21: Daylight Saving Time Configuration
2. Click Enable to enable NTP. 3. Enter the IP address of the primary NTP server in the Primary NTP Server field. 4. Enter the IP address of the primary NTP server in the Secondary NTP Server field. 5. Select the appropriate time zone from the Time Zone drop-down list. 6.
Page 30: Outlet Power Management
Outlet Power Management Naming an Outlet For Panduit PDUs with outlet level control or monitoring, you can customize each outlet and view all circuit breaker to outlet associations through the Web GUI. 1. In the Control & Manage tab, expand the Outlet Information folder by clicking the pencil icon.
Page 31: Figure 23: Outlet Control
Switching an Outlet On or Off This is only applicable to outlet-switched PDUs. • Outlets on the switched PDU models in the Panduit PDU are easily switched on, switched off, or power cycled. This action requires the user to have Administrator Privileges.
Page 32: Outlet Power Sequence Setup
1. Select the Home Icon then Control & Manage from the drop-down menu in the Web UI. 2. Select the outlet(s) for which to set a delay by clicking on the pencil icon. 3. Configure the length of the delay and/or length of reboot. 4.
Page 33: Figure 25: Outlet Control Enabled
Figure 25: Outlet Control Enabled 3. For each Outlet select the Edit pencil. Figure 26: Edit Outlets 4. In the Edit Outlet window enter the On-Delay time (0-7200 seconds) then select Save. INTELLIGENT PDU USER MANUAL...
Page 34: Setting Metering Thresholds
5. Your Outlet Power Sequence has been set. Figure 28: Saved Sequence Setting Metering Thresholds Power Threshold The PANDUIT PDU will send alert notifications when a power threshold wattage crosses above or below the settings you specify in the Power Threshold configuration: INTELLIGENT PDU USER MANUAL...
Page 35: Figure 29: Power Threshold
1. Go to the Thresholds > Input Page. 2. Click the pencil for the Power Threshold to update. Figure 29: Power Threshold 3. Select and enter the appropriate thresholds in amps and click Save. 4. Lower Critical (W) 5. Lower Warning (W) 6.
Page 36 4. Repeat steps 1 - 3 for all PDUs. Energy Threshold The PANDUIT PDU will send alert notifications when an energy threshold kilowattage crosses above or below the settings you specify in the Energy Threshold configuration: 1. Go to the Thresholds > Energy Page.
Page 37: Figure 30: Energy Threshold
Figure 30: Energy Threshold 3. Select and enter the appropriate thresholds in kilowatts and click Save. 10. Upper Critical (kWh) 11. Upper Warning (kWh) 12. Reset Threshold (kWh) 13. Alarm State Change Delay (samples) If enabled, the PDU asserts any warning or critical condition only after a specified number of consecutive samples that cross a threshold are generated.
Page 38: Figure 31: Phase Current Alarm
Phase Current Alarm Threshold The PANDUIT PDU will send alert notifications when a phase current alarm amp crosses above or below the settings you specify in the Phase Current Alarm configuration: 1. Go to the Thresholds > Phase Page. 2. Click the Pencil for the Phase Current Alarm to update.
Page 39 4. Repeat steps 1 - 3 for all phases. Phase Voltage Alarm Threshold The PANDUIT PDU will send alert notifications when a phase voltage crosses above or below the settings you specify in the Phase Voltage Alarm configuration: 1. Go to the Thresholds > Phase Page.
Page 40: Figure 32: Phase Voltage Alarm
Figure 32: Phase Voltage Alarm 3. Select and enter the appropriate thresholds in voltage and click Save. 21. Lower Critical (V) 22. Lower Warning (V) 23. Upper Warning (V) 24. Upper Critical (V) 25. Reset Threshold (V) The Reset threshold is the number of amps the reading needs to fall below the threshold setting for the condition to be cleared.
Page 41 4. Repeat steps 1 - 3 for all phases. Circuit Breaker Alarm Threshold The PANDUIT PDU will send alert notifications when a circuit breaker amperage crosses above or below the settings you specify in the Circuit Breaker Alarms configuration: 1.
Page 42: Figure 33: Load Segment Breaker
Figure 33: Load Segment Breaker 3. Select and enter the appropriate thresholds in amps and click Save. 27. Lower Critical (A) 28. Lower Warning (A) 29. Upper Warning (A) 30. Upper Critical (A) 31. Reset Threshold (A) INTELLIGENT PDU USER MANUAL...
Page 43 The Reset threshold is the number of amps the reading needs to fall below the threshold setting for the condition to be cleared. For example, the current critical threshold for the input phase is set to 19 amps (A). The current draw rises to 20A, triggering a Current Critical alert. The current then continues to fluctuate between 18.1A and 20A.
Page 44: Figure 34: Device Detection Threshold Information
3. Change the value for the number of milli-amps to set the threshold. Outlet Alarm Threshold The PANDUIT PDU will send alert notifications when an outlet amperage crosses above or below the settings you specify in the Outlet Alarms configuration: 1.
Page 45: Figure 35: Outlet Information
Figure 35: Outlet Information 3. Select and enter the appropriate thresholds in amps and then click Save. 33. Lower Critical (W) 34. Lower Warning (W) 35. Upper Warning (W) 36. Upper Critical (W) 37. Reset Threshold (W) INTELLIGENT PDU USER MANUAL...
Page 46: Email Setup
Repeat steps 1 - 3 for all outlets. Email Setup The Panduit PDU can be configured to send Emails to specific users when an event occurs. To do this, the information about the SMTP (Simple Mail Transfer Protocol) server needs to be configured.
Page 47: Figure 36: Email Setup
Figure 36: Email Setup 2. Select the pencil icon next to SMTP Account Settings and begin filling out the Edit screen. INTELLIGENT PDU USER MANUAL...
Page 48: Figure 37: Smtp Account Settings
Figure 37: SMTP Account Settings 39. Set the Email Server Address. This is the IP address of the SMTP that is going to accept the messages. 40. Set the Sender Address. This is the email address that the email is sent from. You could use a unique email address on each PDU or the same email address across all PDUs.
Page 49: Event Notifications
2. Enter the desired email address and press Enable. 3. Press Save. Note: A maximum of 5 users can be entered to receive email alerts. Event Notifications The Panduit G6 iPDU can be configured to provide event notifications. INTELLIGENT PDU USER MANUAL...
Page 50: Figure 39: Event Notifications
Figure 39: Event Notifications Note: Not every Event Notification applies or is supported by every PDU type even though the toggle switch in the Web GUI may seem like the feature is supported. In that instance the user is advised to ignore that toggle switch. INTELLIGENT PDU USER MANUAL...
Page 51 Below is a table of PDU types and the Event Notifications that particular PDU type supports. Event Notifications Monitored Monitored Monitored Monitored Monitored Monitored Input (MI Input > 6 Switched Switched > 6 Per Outlet Series) Breakers Breakers (MPO Switched (MS Series) Series) Per Outlet...
Page 52: Data Log
Power Share Changed       Data Log The period visible in the data log at any one time depends on the time between data log entries. The time range of each record can be configured from 1 to 1440 minutes. (As an example, if a data log is in an interval of 10 minutes, the entire data log contains 2000 records with up to 13.89 days of data.) Once the data log reaches the maximum of 2000 records, the oldest entries ae overwritten by the newer entries.
Page 53: Web Interface Access
Figure 41: Data Log Configuration 3. Enable must be selected and enter an interval number in the Log Interval field. (Valid range is from 1 to 1440 minutes. The default time is 10 minutes.) 4. Select Save. Web Interface Access Logging Out Users should logout after each session to prevent unauthorized changes to the system.
Page 54 privileges. Users are defined by their unique login credentials and by their user role. The level of access privilege determines what the user will see and what actions the user can perform. The level of access privilege determines which menu items the user can access, or which fields display on individual setting and configuration dialogs.
Page 55: Setting Up The System For Radius Authentication
Modify user profile: 1. Go to User Administration and select Users. 2. Select the User Name. 3. Select Edit. Make changes to the user profile. 4. Select Update. Delete user profile with the following steps: 1. Go to User Administration and select Users. 2.
Page 56: Configuring The System With Ldap Server Settings
Note: By default, a RADIUS user will have the “user” Role if one is not specified. The administrator of the RADIUS server may configure a Panduit vendor (19536) dictionary, with a “User-Role” integer attribute set to User (1) or Admin (2). When this User-Role attribute is the first attribute for the user, that user will have the admin Role after logging in.
Page 57 4. Enter an IP Address of the domain controller/Active Directory (AD) Server. i.e.: 192.168.1.101 (example) 5. Enter a Port. Note: For Microsoft, this is typically 389. 6. In the Base DN field, enter in the account to be used to access AD. i.e.
Page 58: Figure 44: Ldap Configuration
With these LDAP settings configured, the Bind is complete. Figure 44: LDAP Configuration Once LDAP is configured, the PDU must understand for which group authentication occurs. A role must be created on the PDU to reference a group within the Active Directory (AD).
Page 59: Figure 45: Enable Role Privileges
Within the PANDUIT PDU Web Interface, go to User Settings (under admin menu) > Roles. Enter the Role Name that was created in AD. i.e. admins Enable role privileges as needed (pictured below). Figure 45: Enable Role Privileges LDAP authentication is ready to use.
Page 60: Figure 46: Test Ldap Configuration
Figure 46: Test LDAP Configuration Note: Be sure to log in without a domain name. INTELLIGENT PDU USER MANUAL...
Page 61: Section 3 - Simple Network Management Protocol (Snmp)
Section 3 – Simple Network Management Protocol (SNMP) SNMP Management Configuration Setup SNMP 1. Access the Web interface and login. 2. Under SNMP Managers, select SNMP General (or type SNMP in the search). The SNMP General page displays. Figure 47: SNMP Management INTELLIGENT PDU USER MANUAL...
Page 62: Figure 48: Snmp General
3. The SNMP General includes SNMP Access and Version. Figure 48: SNMP General Setup SNMP Port 1. Access the Web interface and log in. 2. Under SNMP Managers, select SNMP Port. The SNMP Port page displays. INTELLIGENT PDU USER MANUAL...
Page 63: Configuring Users For Snmp V1/V2C
Figure 49: SNMP Port 3. Set up SNMP Port and SNMP Trap Port. Figure 50: Setup SNMP Port and Trap Port Configuring Users for SNMP V1/V2c 1. Access the Web interface and log in. 2. Under SNMP Manager, select SNMP V1/V2c. 3.
Page 64: Figure 51: Define Snmp V1/V2C User
Figure 51: Define SNMP V1/V2c User 4. The Edit panel pop up displays. Figure 52: Edit V1/2c Manager 5. Set the following options: • IP Address: the IP address of the host for this SNMP V1/V2 manager. Only requests from this address will be acted upon. INTELLIGENT PDU USER MANUAL...
Page 65: Configuring Users For Snmp V3
Note: An IP address configured to 0.0.0.0 will act as a wildcard and all requests will be acted upon. • Read Community: the read-only community string to allow an SNMP V1/V2c manager to read a SNMMP object. • Write Community: the write-only community string to allow an SNMP V1/V2c manager to write an SNMMP object.
Page 66: Figure 54: Snmp V3 Edit
Figure 54: SNMP V3 Edit 5. Configure the SNMP username 6. Choose a Security Level from the dropdown menu • NoAuthNoPriv: No authentication and no privacy. This is the default. • AuthNoPriv: Authentication and no privacy. • AuthPriv: Authentication and privacy. 7.
Page 67: Configuring Snmp Traps
9. Enter a new unique key for privacy algorithm 10. Select the desired privacy algorithm • AES-128 • AES-192 • AES-256 11. Click Enable and Save. Configuring SNMP Traps The PDU keeps an internal log of all events. These events can be used to send SNMP traps to a third-party manager.
Page 68: Figure 56: Snmpv3 Trap Server Information
system agent. c. Community is the password on the SNMP management stations. 4. Select Enable to enable the receiver. 5. Select Save to save and exit. Configuring SNMP v3 Trap Settings 1. Go to Device Configuration > Network Services > SNMP 2.
Page 69 • AuthNoPriv: Authentication and no privacy. • AuthPriv: Authentication and privacy. 5. Enter the password from the SNMP Server to be used for authentication. 6. Select the desired authentication algorithm. • MD5 • SHA 7. Enter the key from the SNMP Server for privacy algorithm 8.
Page 70: Section 4 - Local Display
Section 4 – Local Display Onboard Display and Network Controller The Onboard Display provides information about the PDU and connected devices. The PDU has a three-button, graphical Network Controller panel (see Figure 22). Use the buttons to change the screen display and retrieve specific data. Display Figure 57: Network Controller The Network Controller Display has three modes:...
Page 71: Control Buttons
Power Save mode: The PDU enters Power Save mode when it has been in Standby mode for an hour. To exit Power Save mode, press any button on the display. Control Buttons The table below summarizes how to use the control buttons on the Network Controller display.
Page 72: Network Controller Menu Structure
Network Controller Menu Structure Figure 58: Network Controller Menu Structure Main Menu Selections The PDU menu selection hierarchy consists of Setup, Alarms, Power, and Sensors. On the main menu, scroll down to highlight Setup. Press Select. Scroll down to select a submenu and press Select to display the submenu options.
Page 73: Setup Menu
Figure 59: Main Menu Selections Setup Menu The Setup menu provides user configuration options including Network, Device, Screen, Language, USB, and Units. Figure 60: Setup Menu Network Submenu The Network submenu allows you to view IP address IPv4 or IPv6. On the Setup menu, scroll down to Network.
Page 74: Figure 61: Network Submenu
Figure 61: Network Submenu Device Submenu The Device submenu provides the SKU number, Serial number, MAC address and Firmware version. On the Setup menu, scroll down to highlight Device submenu. Press Select to enter the Device Submenu. Scroll down to the item you wish to display, and press Select.
Page 75: Figure 62: Device Submenu
Figure 62: Device Submenu Screen Submenu The Screen submenu allows you to customize settings for Contrast, Rotate, and Always on. In the Setup menu, scroll down to highlight Screen. Press Select to select the submenu. Press Menu to return to the previous menu. INTELLIGENT PDU USER MANUAL...
Page 76: Figure 63: Screen Submenu
Figure 63: Screen Submenu Language Submenu The Language submenu allows you to select the language you need to use. On the Setup menu, scroll down to highlight Lang. Press Select to display the screens to select the submenu. After you select the values, press Select to set the values as displayed on the screen.
Page 77: Figure 64: Language Submenu
Figure 64: Language Submenu USB Submenu The USB submenu allows you to upload firmware file and download event log or data log. On the Setup menu, scroll down to highlight USB. Press Select to enter the USB Submenu. The user will be asked to verify the want to the enter the USB operation and Configuration Mode.
Page 78: Figure 65: Usb Submenu
Figure 65: USB Submenu INTELLIGENT PDU USER MANUAL...
Page 79: Figure 66: Units Submenu
Units Submenu The Units submenu displays the temperature units. On the Setup menu, scroll down to highlight Units. Press Select to enter the Units Submenu. After you select the values, press Select to set the values as displayed on the screen. Press Menu to return to the previous menu.
Page 80: Figure 67: Alarms Menu
Alarms Menu The Alarms menu displays active alarms for the PDU. On the Main Menu, scroll down to highlight Alarms. Press Select to display the Alarm Screen. When you finish your review, press Menu to return to the main menu. Figure 67: Alarms Menu INTELLIGENT PDU USER MANUAL...
Page 81: Figure 68: Power Menu
Power Menu The Power menu manages device, phase, breaker and outlet. On the Main Menu, scroll down to highlight Power. Press Select. Scroll down to select a submenu and press Select to display the submenu options. Press Menu to return to the previous menu. Figure 68: Power Menu INTELLIGENT PDU USER MANUAL...
Page 82: Figure 69: Device Submenu
Device Submenu The Device submenu is to display current, voltage and power. On the Power menu, scroll down to highlight Device. Press Select to display the power values for the entire PDU. Press Menu to return to the previous menu. Figure 69: Device Submenu INTELLIGENT PDU USER MANUAL...
Page 83: Figure 70: Phase Submenu
Phase Submenu The Phase submenu is to display the status of 3-Phase. On the Power menu, scroll down to highlight Phase. Press Select to display the screens to set the values for the submenu. After you select the phase, press Select to display the values for that phase on the screen.
Page 84: Figure 71: Breaker Submenu
Breaker Submenu The Breaker submenu is to display power values for the breakers. Press Select to display the values of the first breaker. To go to the next breaker, Select next. Press Menu to return to the previous menu. Figure 71: Breaker Submenu INTELLIGENT PDU USER MANUAL...
Page 85: Figure 72: Outlet Submenu
Outlet Submenu The Outlet submenu is to display voltage, current and power from outlet number 1 to number n. On the Power menu, scroll down to highlight Outlet. Press Select to display values for the first outlet. To go to the next outlet, Select next. Press Menu to return to the previous menu.
Page 86: Sensors Menu
Sensors Menu The Sensor menu is to display temperature, humidity, door switch, fluid leak etc. On the Main Menu, scroll down to highlight Sensor. Press Select. This will display the sensor data for the first sensor. To go to the next sensor, Select next. Press Menu to return to the previous menu.
Page 87: Section 5 - Daisy Chain Configuration
Section 5 – Daisy Chain Configuration Daisy-Chain Overview In daisy chain mode, up to (32) PDUs of the same SKU number, and on the same Firmware version, can be connected via one IP address. This allows users to gather information and data on all daisy-chained PDUs from the main PDU. The daisy chain functionality reduces network cost for PDUs.
Page 88: Rna (Redundant Network Access) Functionality
Figure 74: Connection Diagram 6 PDU Daisy Chain RNA (Redundant Network Access) Functionality RNA allows secure access of PDU data and statistics on two separate, private networks. RNA must be used with a redundant power delivery design including two rack PDUs for each IT rack.
Page 89: Rna Setup
Figure 75: Connection Diagram RNA Daisy Chain How it works: • Using RNA, the main and expansion unit maintain two separate private networks that do not overlap. • RNA works using a redundant power delivery design (two rack PDUs for each IT rack).
Page 90: Power Share
1. Log in to the CLI and enter the command ‘dev daisy rna.’ 2. The following message will appear: • Reboot Required for change to take effort. • System Reboot now, Are you sure? (Y/N). 3. Enter Y to confirm reboot. 4.
Page 91: Figure 76: Connection Diagram Power Share & Daisy Chain
PDUs only. However, due to limited available power from the Panduit iPDU Controller, power share was designed and tested under the following conditions: ACF05 or AC06 Intelligent Rack Security Handle, ACF10 (T+D), ACF11 (3T+D). Care must be taken to not overload the system with accessories as this may cause instability or power share to become unavailable.
Page 92: Section 6 - Intelligent Rack Security Handle
Section 6 – Intelligent Rack Security Handle The Panduit Intelligent PDUs allow users to electronically secure and control access to cabinets. For the latest firmware please visit: panduit.com → Support → Download Center → PDUs Note: For security, verify that the handle is seated prior to engaging locking mechanism.
Page 93: Figure 78: Connection Diagram For Intelligent Rack Security Handle
Security Handle optimizing cable routing. Use the below table to help count total sensors being deployed. Part Number Number onboard Device connects to Sensors ACF05 Panduit G6 PDU ACF06 Panduit G6 PDU ACF11 Panduit G6 Handle ACF10 Panduit G6 Handle...
Page 94: Configuring Cabinet Access Control
Panduit G6 PDU EC001 Panduit G6 PDU Note: A maximum of 8 sensors can be managed by the Panduit G6 PDU controller. A maximum of 2 handles can be managed by each individual Panduit G6 iPDU. Configuring Cabinet Access Control All Rack Access Control configuration can be done under the Rack Access Control Page from the Web GUI.
Page 95: Figure 79: Rack Access Control Web Gui
Figure 79: Rack Access Control Web GUI 3. The Actions Menu on the right side of the page will allow the user to Add Card, Rack Access Settings, Handle Settings, Keypad Settings, Remote Control, Beacon Settings, and Status LED Settings. Figure 80: Rack Access Control Actions Web GUI INTELLIGENT PDU USER MANUAL...
Page 96: Adding A User For Local Rack Access
Adding a User for Local Rack Access Every user that needs access to the cabinet needs to have their access card added into the PDU. Each card (or user) must have a username and either a card ID or keypad PIN code.
Page 97: Configuring Rack Access Settings
Figure 81: Local Rack Access Web GUI 2. Enter a username to identify the user. 3. If the system is configured for RFID Only or Dual Auth, enter the determined card 4. If the system is configured for Keypad Only or Dual Auth, enter the pin. Note: users must be assigned unique PIN codes in ‘Keypad Only’...
Page 98: Figure 82: Rack Access Settings Web Gui
Actions menu. Figure 82: Rack Access Settings Web GUI 2. Select from two options in the Aisle Control. a. Hot/Cold Combined – Operating hot or cold causes both handles to open. b. Hot/Cold Standalone – Operates hot or cold independently 3.
Page 99: Configuring Handle Settings
Configuring Handle Settings. Handle settings and information relate to a specific handle. These include the Access Control Unit (ACU) name. 1. To update the handle settings, select Handle Settings from the Actions menu. Figure 83: Handle Settings Web GUI 2. Select the handle to edit or get information about. a.
Page 100: Configuring Keypad Settings
Configuring Keypad Settings If a Intelligent Rack Security Handle with Keypad is deployed; the user has the following options: a. PIN Mode turned on hides the user PIN in the Web GUI. b. All users must adhere to the same PIN length. c.
Page 101 a. Under the PDU section, Select the handle 3. Select the action you wish to perform. a. Lock remotely locks the handle b. Unlock remotely unlocks the handle. 4. When finished, click Close. INTELLIGENT PDU USER MANUAL...
Page 102: Controlling The Beacon
Controlling the Beacon. The beacon is a visual indicator to give you status of the cabinet at a glance. The beacon will flash yellow when the cabinet is in a minor alarm or flash red when the cabinet has a critical alarm. You can also use the beacon’s locate function to flash the beacon a certain color to easily locate the cabinet.
Page 103: Figure 86: Beacon Settings Web Gui
1. To control a handle beacon, select Beacon Settings Control from the Actions menu. Figure 86: Beacon Settings Web GUI 2. Select the function of the beacon: a. Standby –beacon color no alarms b. Locate –flash beacon 3. Select color for Standby or Locate. 4.
Page 104: The Status Led
The Status LED The Intelligent Rack Security Handle is equipped with a status LED to give a visual indication of the handle and security status. A summary of all the status LED states can be seen in the follow table. The default state of the status LED is on solid green. Status Status LED Table in Order of Priority: Status LED Color...
Page 105: Setting Status Led State
Setting Status LED State 1. To set the standby state of the status LED state, select Status LED Settings from the Actions menu. Figure 87: Status LED Settings Web GUI 2. Select the color of Status LED when the handle is in standby state. 3.
Page 106: Section 7 - Panduit G6 Accessories
IT room atmosphere. Note: A maximum of 8 sensors can be managed by the Panduit G6 PDU controller. Sensors may be installed with PDUs powered on. The following table lists available sensors as well as sensor count:...
Page 107: Figure 88: Sensor Ports For Vertical Pdu
30m. Panduit G6 Dry Contact Input to the G6 iPDU and Sensor (ACC01) designed to monitor a change in contact state. Sensor Sensor...
Page 108: Configuring Temperature Scale
Configuring Temperature Scale To configure the temperature scale (Celsius or Fahrenheit) of the temperature sensors: 1. Go to User Accounts. Figure 89: User Settings 2. The button at the top of the screen can be used to select Celsius or Fahrenheit. Figure 90: Celsius Setting Figure 91: Fahrenheit Setting Configuring Environmental Sensors...
Page 109: Security
This product contains software that stores user entered data. All data entered by the user is stored in non-volatile storage on the system running the software. Non-volatile Storage The G6 iNC Controller uses non-volatile storage on the G6 PDU to store all • configuration information.
Page 110: External Authorization Mechanisms
• The product implements an internal authentication mechanism, authorization events generate “Event Logs” containing the IP address and username of successful logins, and the IP address of failed logins for valid usernames. External Authorization Mechanisms LDAP & Radius – username & password are stored in non-volatile storage. •...
Page 111: Warranty And Regulatory Information
Warranty and Regulatory Information Warranty Information https://www.panduit.com/en/legal-information/panduit-limited-product-warranty.html Regulatory Information Safety and regulatory compliance For important safety, environmental, and regulatory information, reference Panduit website: https://www.panduit.com/en/support/download-center/certifications.html INTELLIGENT PDU USER MANUAL...
Page 112: Panduit Support And Other Resources
Panduit Support and Other Resources Majority of your support needs can be met by visiting Panduit.com → Support. If you require additional assistance, we are here to help. Accessing Panduit Support North America Europe / Middle East Customer Service Customer Service •...
Page 113: Acronyms And Abbreviations
Acronyms and Abbreviations LCD Liquid-Crystal Display LDAP Amps/Amperes Lightweight Directory Access Protocol Alternating Current OLED Organic Light-Emitting Diode Advanced Encryption Standard Power Distribution Unit Command Line Interface DHCP Quad-Network Interface Dynamic Host Configuration Protocol Redundant Network Interface Gigabyte Secure Hash Algorithms Graphical User Interface SNMP Simple Network Management Protocol...
Page 114: Appendix A: Sensor Configuration
Figure 92: Door Switch Sensor Configuration Note: The Door Switch Sensor is only designed to connect to a Panduit PDU. Connecting it to another device may result in damage.
Page 115: Temperature & Humidity Sensors
Figure 93: Dry Contact Cable Note: The dry contact cable is only designed to connect to a Panduit PDU. Connecting it to another device may result in damage. Temperature & Humidity Sensors Temperature and humidity sensors are designed to add comprehensive environmental monitoring to any Panduit PDU.
Page 116: Configuring Environmental Sensors
Figure 94: Temperature and Humidity Sensors Configuring Environmental Sensors Each Panduit G6 Intelligent PDU features an onboard controller capable of managing a maximum of 8 sensors. To configure the sensor location, alarms, notifications, and details, open the WEB Interface: 8. Open the Settings.
Page 117: Figure 95: Sensor Ports On Controller
12. In the Edit dialog box, type value of up critical, up warning, low warning, and low critical. 13. Select Save to exit the sensor setup. Repeat this process for additional sensors. Sensor Port Sensor Port Figure 95: Sensor Ports on controller PANDUIT PDU USER MANUAL...
Page 118: Appendix B: Firmware Upgrade Options
Note: If you load incompatible firmware, no damage will occur and PDU will maintain the original firmware. G6 Upgrade Tool (GUT) The ‘G6 Upgrade Tool’ has been created to streamline the firmware upgrade process for either individual or bulk management of PDUs. See Appendix C details.
Page 119: Usb Method
2. Transfer the updated *FW file to the root directory. Close the FTPs. 3. Connect to the PDU via SSH using a program such as HyperTerm or PuTTY. 4. Login using a role with administration privileges. PANDUIT PDU USER MANUAL...
Page 120 5. Enter the command sys upd all. 6. It will show the message: System will enter upgrade mode after reboot, System Reboot now, Are you sure? (Y/N). 7. Enter Y. 8. When the upload is finished, the system will reboot automatically. PANDUIT PDU USER MANUAL...
Page 121: Appendix C: Bulk Management Of Pdus
Appendix C: Bulk Management of PDUs A dedicated G6 Upgrade Tool (GUT) is included with every firmware release. This utility enables a user to bulk manage PDUs. This utility features Firmware Upgrading, Configuration Replication (common parameters) and management of uncommon parameters (.csv) file.
Page 122: Figure 98: System Management Download Configuration Web Gui
Insert IP Address or Range of the target PDU(s) c. Insert admin credentials d. Load the confi.ini file to the G6 Upgrade Utility and click Start Conf.ini Figure 99: G6 Upgrade Tool Interface 3. Configuration Replication of Un-Common Parameters a.
Page 123: Figure 100: Example Csv File
Figure 100: Example CSV File d. Load the Config.csv file to the G6 Upgrade Utility and click Start Config.csv Figure 101: G6 Upgrade Tool Interface PANDUIT PDU USER MANUAL...
Page 124: Appendix D: System Reset Or Password Recovery
20 seconds. This will cause a reset of the iNC controller erasing all existing configurations, including username(s) and password(s). It does not change the Energy (kWh) value and does not affect the outlet state. PANDUIT PDU USER MANUAL...
Page 125: Appendix E: Pdu Alarms
Circuit Breaker Status ON Circuit Breaker Status OFF Outlet X Active Power Above upper critical Outlet X Active Power Above upper warning Outlet Outlet X Active Power Below lower warning Outlet X Active Power Below lower critical PANDUIT PDU USER MANUAL...
Page 126 System Communication Lost Daisy Chain state changed USB Port User Activity User X Authentication failure User Activity User X User logged in User Activity User Activity User X Session timeout User Activity User X User blocked PANDUIT PDU USER MANUAL...
Page 127: Trap Codes Assigned To Alarms List
The circuit breaker (1-12) current is ABOVE critical threshold value 28-30 The circuit breaker (1-12) current is BELOW critical threshold value 40-51 The circuit breaker (1-12) is in OFF state 52-99 The outlet (1-48) active power is ABOVE critical threshold PANDUIT PDU USER MANUAL...
Page 128 Trap codes assigned for warning alarms: Trap Class Trap Trap Description Code Warning The PDU unit active power is ABOVE warning threshold value. The PDU unit active power is BELOW warning threshold value. The PDU warning energy alarm. PANDUIT PDU USER MANUAL...
Page 129 Trap Class Trap Trap Description Code Informational 380-391 The circuit breaker (1-12) is in ON state. 392-439 The outlet (1-48) IMMEDIATE ON occurred. 440-487 The outlet (1-48) DELAYED ON occurred. 488-535 The outlet (1-48) IMMEDIATE OFF occurred. PANDUIT PDU USER MANUAL...
Page 130 Network interface link state is up. Communication Module reset. Communication Module start. Daisy Chain state changed. User xxx logged in. User xxx session timeout. User xxx blocked. User xxx password changed. User password settings changed. User xxx added. User xxx deleted. PANDUIT PDU USER MANUAL...
Page 131 The outlet (1-48) active power current alarm cleared. 838-845 The sensor (1-8) temperature/humidity alarm cleared. 846-853 The sensor (1-8) lost communication alarm cleared. 854-856 Input Phase (1-3) Frequency Deasserted above upper critical 857-859 Input Phase (1-3) Frequency Deasserted below lower critical. PANDUIT PDU USER MANUAL...
Page 132 Input Phase Measurement Active Power of PHASE (1-3) asserted 1124-1126 below lower critical Input Phase Measurement Apparent Power of PHASE (1-3) 1127-1129 asserted above upper critical Input Phase Measurement Apparent Power of PHASE (1-3) 1130-1132 asserted below lower critical Warning PANDUIT PDU USER MANUAL...
Page 133 Input Phase Measurement Apparent Power of PHASE (1-3) deasserted above upper critical/below lower critical/above 1148-1150 upper warning/below lower warning Role Added by Admin User 1151 Role Deleted by Admin User 1152 Role Modified by Admin User 1153 PANDUIT PDU USER MANUAL...
Page 134: Figure 102: Screws On Network Controller
Appendix F: Panduit Network Controller Replace or Rotate 180° 1. Use a T10 Torx screwdriver on the screws as shown in Figure 98. The screws are held in with retaining washers. Figure 102: Screws on Network Controller a. Controller may be rotated to accommodate overhead or underfloor power. If rotating controller, YOU MUST DISCONNECT the ribbon cable to prevent damage to the ribbon cable.
Page 135: Figure 103: Ribbon Cable For The Network Controller
Figure 103: Ribbon Cable for the Network Controller 3. Replace and tighten the two (T10) screws on the Intelligent Network Controller to 2.2 – 3.1 lbf-in (0.25 – 0.35 N-M). Overtightening the screws may result in metal deformation. PANDUIT PDU USER MANUAL...
Page 136: Appendix G: Direct Connect To The Pdu By Changing Your Pc's Ip Address
Changing Your PC’s IP Address Note: Instructions refer specifically to Windows 10. Please refer to your operating system documentation if you are not using Windows 10. 1. Type control into Windows Search and select Control Panel. Figure 104: Control Panel PANDUIT PDU USER MANUAL...
Page 137: Figure 105: Network Status And Tasks
2. In the Control Panel window, select View network status and tasks under the Network and Internet heading. Figure 105: Network Status and Tasks 3. Select Change adapter settings from the menu on the left. PANDUIT PDU USER MANUAL...
Page 138: Figure 106: Change Adapter Settings
Figure 106: Change Adapter Settings 4. Right-click Ethernet and select Properties. Figure 107: Properties PANDUIT PDU USER MANUAL...
Page 139: Figure 108: Ethernet Properties
Figure 108: Ethernet Properties 5. Select Internet Protocol (TCP/IP) Version 4 (you may need to scroll down). Then click the Properties button. PANDUIT PDU USER MANUAL...
Page 140 Figure 109: Internet Protocol Version 4 6. Select the Use the following IP address radio button. The Use the following DNS server addresses radio button then selects automatically. PANDUIT PDU USER MANUAL...
Page 141: Figure 110: Ip Settings For Direct Connection
8. Connect the PDU network connection directly to the PC’s Ethernet card using a patch cable. 9. Power the PDU unit. 10. Open a web browser on the PC. 11. Enter the address bar http://192.168.0.1 into your browser. PANDUIT PDU USER MANUAL...
Page 142: Appendix H: Command Line Interface (Cli)
([ ]). For data of type array, the 'x' character as index of array in command input syntax means all indexes. You must be logged into the PDU before commands can be sent. See below for a list of all CLI commands. PANDUIT PDU USER MANUAL...
Page 143: Figure 111: Connect Ma017 To The Pdu In/Serial Port
Connecting to the CLI through the serial interface An option to communicating through the serial interface is to use the specialized YOST Serial Data Cable Panduit Part Number: MA017. This cable Remaps Panduit G6 Serial Interface to a YOST interface.
Page 144: Cli Commands
6. Enter your password. Press Enter. 7. You are now logged into the SSH. Refer to the CLI Commands table below for available commands. NOTE: SSH connection is not available when serial connection is enabled. CLI Commands Help Commands PANDUIT PDU USER MANUAL...
Page 145 NTP Status : ON sys ntp [on/off] Sets the ntp Panduit>sys ntp on status to (G6 Only) SUCCESS ON/OFF Panduit>sys ntp off SUCCESS sys ntp [server1] [server2] Set the Panduit>sys ntp 162.159.200.1 primary and (G6 Only) secondary IP PANDUIT PDU USER MANUAL...
Page 146 (G6 Only) GMT offset GMT Name : Chennai, Kolkata, Mumbai, Delhi GMT Offset : UTC+05:30 Sets the UTC sys ntp gmtoffset Panduit>sys ntp gmtoffset +00:03 code defined [UTCoffset] SUCCESS for every (G6 Only) Reboot required for change to take effect...
Page 147 System Reboot now, Are you sure? ile. (Y/N):Y NOTE 1: There must be a valid file named Panduit.fw existing in root directory. NOTE 2: If in daisy chain configuration, main PDUs will upgrade all daisy chain firmware. sys log del event Delete event Panduit>sys log del event...
Page 148 Command Description Example sys log edit event [on/off] Configure PANDUIT>sys log edit event on 1 [interval] event log SUCCESS collection PANDUIT>sys log edit event off 1 parameters SUCCESS sys log del data Delete data Panduit>sys log del data log file.
Page 149: Network Commands
Command Description Example Panduit> sys updatehid rfid 1 1 Updating HID RFID firmware, please wait… Handle update is SUCCESS, PDU will reboot now sys updatercm rcm Updates the Panduit> sys updatercm rcm (G6 Only) Updating RCM firmware, please wait… firmware Panduit>...
Page 150 HTTPS protocol is being turned off, Please reboot to validate System Reboot now, Are you sure?(Y/N): net redfish Query or Panduit> net redfish on/off net SUCCESS https. Status: OFF Panduit>net redfish on net redfish on SUCCESS Panduit>net redfish off SUCCESS PANDUIT PDU USER MANUAL...
Page 151 ON v3: ON trap: ON net snmp [v1v2c/v3] [on/off] Sets SNMP Panduit>net snmp v1v2c on / net snmp v3 On or Off. SUCCESS Panduit>net snmp v1v2c off / net snmp v3 SUCCESS net snmp trap [on/off/port] Query the Panduit>net snmp trap on...
Page 152 Command Description Example <Write_community> <Enable/Disable> net snmp v3 <index> Configure Panduit>net snmp v3 1 admin AP <username> the SNMP 123456789 SHA 123456789 AES128 <securitylevel[AP/ANP/NAN v3 manager. enable P]> <Auth_password> SUCCESS <Auth_algo[MD5/SHA]> <Priv_key> <Priv_algo[AES128/AES19 2/AES256]> <Enable/Disable> net [mac/tcpip] Displays the Panduit>net mac...
Page 153 100% 11 KB 739.8 KB/s 00:00 File successfully uploaded. net ip [v4] [v6] [v4v6] Changes Panduit>net ip v4 the mode Reboot required for change to take effect between IP protocol is changed, Please reboot to validate PANDUIT PDU USER MANUAL...
Page 154 Phy speed is changed, reboot to validate 1gbps System Reboot now, Are you sure?(Y/N):Y net dns [-h <hostname> Changes Panduit>net dns -h admin -d test -s1 the DNS 10.10.105.20 -s2 10.10.105.21 -d <domain> -s1 domain Reboot required for change to take effect <server1>...
Page 155 ETH0 AUTH:EAP-TLS ETH0 IDENTITY :SmartPower information ETH1 AUTH :EAP-TLS ETH1 IDENTITY :SmartPower net eap [eth0/eth1] Setting the Panduit>net eap eth0 enable outer TLS [enable/disable] outer TLS identity system_bangalore_center01 identity [Identity] authenticati passphrase smartpower passphrase SUCCESS [private key passphrase] information...
Page 156 Example Client Key and Client Certificate via FTPS, before setting via CLI. net eap [eth0/eth1] Setting the Panduit>net eap eth1 enable outer PEAP [enable/disable] outer inner MSCHAP identity PEAP inner MSCHAP authenticati system_bangalore_center01 passphrase identity [Identity] password smartpower [password] information...
Page 157: User Commands
[role:admin/user/manager] 123456789 interactive (G6 Only) method. Re enter Password for confirmation 123456789 Enter role : admin | user | manager admin Enter temperature scale (C/F) SUCCESS Panduit>usr options non-interactive add user2 123456789 123456789 admin f SUCCESS PANDUIT PDU USER MANUAL...
Page 158 Command Description Example usr roleoptions Add Users Panduit> usr roleoptions interactive [interactive/non- interactive] and set Enter command from List: add/del/edit credentials, [add/del/edit] define roles [rolename] Enter role name [Admin Privilege required? : Admin Bangalore privileges yes/no] Enter role description using...
Page 159 Numerical character policy in Password : yes | no Do You want to Enforce at least 1 Special character policy in Password : yes | no SUCCESS Panduit>usr pwdpolicy non-interactive get Password Policy details are: maxpwdlen = 12 minpwdlen=8 Password Aging Interval = Never Expire...
Page 160 Session Management details are: chkuserblocking = 1 maxnumfailedlogins=3 blocktimeout=10 idletimeout=10 SUCCESS Panduit> usr sessionmgmt non- interactive set yes 3 10 10 SUCCESS INTERACTIVE APPROACH* When the user selects an Interactive Approach, user will be prompted for each parameter/option to perform the respective action.
Page 161: Device Commands
Panduit>dev daisy rna init daisy chain. SUCCESS System Reboot now, Are you sure? (Y/N):N dev daisy [rna/qna] [create] Creating Panduit>dev daisy rna init create daisy chain SUCCESS System Reboot now, Are you sure? (Y/N):N dev outlet [PDUID] [status] Query all Panduit>dev outlet 1 status...
Page 162 SUCCESS reboot delay Panduit>dev outlet 1 outlet42 set poweronstate lastknown SUCCESS Panduit>dev outlet 1 42 set ondelay 7200 SUCCESS Panduit>dev outlet 1 42 set offdelay 7200 SUCCESS Panduit>dev outlet 1 42 set rebootdelay 60 SUCCESS PANDUIT PDU USER MANUAL...
Page 163 Command Description Example dev outlet [pduID] Command Panduit>dev outlet 1 1 on [outletindex/outletname] to Turn SUCCESS [on/off/ondelay/offdelay/reb on/off/off Panduit>dev outlet 1 1 rebootdelay ootdelay/reboot] delay/ SUCCESS ondelay/r ebootdelay the outlet power dev usb [on|off] Query or Panduit> dev usb on/off USB.
Page 164 1 POWER SHARE output is ON Panduit> dev powershare 1 func on SUCCESS Panduit> dev powershare 1 func off SUCCESS dev handle [pduID] Enables Panduit>dev handle 1 hot lock handle [cold/hot] [lock/unlock] SUCCESS function dev tempscale get Display Panduit>dev tempscale get SUCCESS information...
Page 165 Panduit>dev rcm 1 fwver RCM Firmware version :53 SUCCESS Panduit>dev rcm 1 hwver RCM Hardware version :16 SUCCESS Panduit>dev rcm 1 selftest start RCM self test initiated successfully for PDU 1 SUCCESS Panduit>dev rcm 1 selftest result Last Self Test has Passed...
Page 166: Power Commands
0W apparent power: 0W NOTE: For Monitored PDUs, this command is invalid. pwr phase [pduid] [idx] Query Panduit> pwr phase 1 1 specified SUCCESS phase’s PDU ID 1 : PHASE 1 power Feature electric VoltageMeasType : Phase 1 to N information.
Page 167 Command Description Example pwr cb [pduid] [idx] Query Panduit>pwr cb 1 1 specified SUCCESS circuit PDU ID 1 : CB 1 power Feature breaker’s frequency : 50Hz Electric voltage : 227.0V information. current : 0.0A activepower : 0.0W apparentpower : 0.0VA powerfactor : 1.00...
Page 168: Appendix I: Radius Server Configuration
User-Role User VALUE User-Role Admin END-VENDOR Panduit 4. Load dictionary.Panduit by appending the following line to /etc/freeradius/3.0/dictionary $INCLUDE /usr/share/freeradius/dictionary.Panduit 5. Add authorized users to with the /etc/freeradius/3.0/mods-config/files/authorize desired role. (Note: the ‘users’ file location may vary based on unique customizations or different package managers.) When specified, the User-Role MUST be the first attribute of the user.
Page 169 User-Role. Note: You may need to change this example based on any client restrictions that are enforced. Usage: radtest [OPTS] user passwd radius-server[:port] nas-port-number secret # radtest 'radroleadmin' '34567890’ 192.0.2.1 0 'panduit#1' '' Sending Access-Request of id 212 to 192.0.2.1 port 1812 User-Name = "radroleadmin"...
Page 170: Appendix J: Panduit G6 Accessories
KE025X Option 5 Key for Tumbler TU025X Note: Panduit G6 PDU Controller can handle a maximum of 8 sensors. Some part numbers have multiple sensors built in (e.g. EC001 has 4 sensors, ACF05 or ACF06 has 2 sensors). PANDUIT PDU USER MANUAL...
Page 171: Appendix K: Compliance Model Number Details
4: 200-240Vac (Delta), 3 phase 5: 100-240Vac, 1 phase 6: 120-208Vac (Wye), 3 phase #: Different management feature. 0: Basic PDU 1: Metered iPDU 2: Metered, Outlet switched iPDU 5: Outlet Metered iPDU 6: Outlet Metered, Outlet switched iPDU PANDUIT PDU USER MANUAL...
Page 172: Appendix L: Json Api Web Service
• Nested arrays or arrays of objects are not supported. • Maximum object depth is 2. For additional details on the Redfish API – please refer to “G6 PDU Redfish Manual v1.0 FW5.x.pdf” For a copy of this document send a request to systemsupport@panduit.com...

Panduit G6 User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Panduit G6

Summary of Contents for Panduit G6
