- Page 1 INSTALLATION MANUAL Batt eries for electric drive of bikes EVBAT48V9A EVBAT36V13A...
- Page 2 Thank you for purchasing EVBIKE product and we hope that you will become a happy user. Carefully read the enti re manual prior to installati on and fi rst use! If you fi nd any fact in the manual that would prevent you from using our product, please contact your reseller for further discussion and keep the original packaging.
-
Page 3: Specifications
• Safety Precautions and Instructions for the End Consumer SPECIFICATIONS EVBIKE batteries use specially designed traction cells 18650 that result in a superb drive power with a long life. Some further technical parameters of our product are shown in the table below. - Page 4 Dismantle the battery bracket that is fastened with screws TORX (fig. 2). Subsequently apply the span of the screws onto a suitable place of the bracket. Always try to use the holes already made. In most cases only one hole will need to be done (fig. 3 and 4). www.EVBIKE.cz Importer: GWL Power Ltd., EU-VAT ID: CZ682998344...
- Page 5 Now reinstall all the parts of the bracket and tighten the TORX screws (fig. 7). Connect the battery cable to the motor control unit, making sure you get the polarity right. www.EVBIKE.cz Importer: GWL Power Ltd., EU-VAT ID: CZ682998344...
- Page 6 WARNING: During any ride the batt ery must always be locked and the key must be away of the lock. Unlock Move forward Release 3. Descripti on of the individual parts of the batt ery: Power terminals ON/OFF switch and LED indicator Batt ery Lock Protecti ve fuse Charger connector www.EVBIKE.cz Importer: GWL Power Ltd., EU-VAT ID: CZ682998344...
-
Page 7: Error Messages
Please check the connection of the battery and the cable of any breakage. Furthermore, check the system settings whether the recuperation (regeneration of the braking energy) is not active and disable it if needed. www.EVBIKE.cz Importer: GWL Power Ltd., EU-VAT ID: CZ682998344... -
Page 8: Using The Battery
1. Proper charging: Lithium cells 18650 that are used in EVBIKE batteries can be charged in any status of discharge and these batteries do not have any memory effect. That is why we recommend always charging the battery after a ride or in the course of a longer break so that you can enjoy a full power and long reach. -
Page 9: Warranty
This instruction must be provided by the last seller. In case of a distant sale, this instruction is done by attaching a manual. Further information regarding using the battery can be found on the website of the reseller. www.EVBIKE.cz Importer: GWL Power Ltd., EU-VAT ID: CZ682998344... - Page 10 • Store the batteries charged and take a measure of their voltage every 1 month. If the value is near its minimum, recharge the battery. • Operate the batteries under supervision or under a constant monitoring by a protection and control system. Avoid overcharging and total discharging. www.EVBIKE.cz Importer: GWL Power Ltd., EU-VAT ID: CZ682998344...
-
Page 11: Declarations Of Conformity
Decree-Law No 17/2003 Coll. establishing technical requirements for low-voltage electric devices (or LOW VOLTAGE DIRECTIVE 2006/95/EC). This statement is issued on the basis of documents presented by the producer. www.EVBIKE.cz Importer: GWL Power Ltd., EU-VAT ID: CZ682998344...
