- Page 1 INSTALLATION MANUAL Battery for electric bike EVBAT36V13A-S EVBAT36V16A-S EVBAT36V20A-G EVBAT48V13A-S EVBAT48V17A-G...
- Page 2 Thank you for purchasing the EVBIKE product and we hope that you will be very happy with its use. Before installation and first use, please read the entire manual carefully! If you have found a fact in the owner's manual that would prevent you from using the product, please contact your dealer for further agreement and retain the original packaging.
-
Page 3: Specification
• Battery USE • Warning on potential hazards and end-user instruction SPECIFICATION EVBIKE batteries use traction cells 18650, thanks to which the battery delivers excellent long- lasting driving performance. Further technical parameters of the product are shown in the table below. - Page 4 SPECIFICATION EVBAT36V16A-S EVBAT36V20A-G Nominal voltage: 36 V 36 V Nominal capacitty: 15,6 Ah/561 Wh 20Ah/720Wh Basic capacitty: * 15 Ah 19,5Ah Constant discharge current: 20 A 20 A Peak discharge current: 25 A 25 A Minimal voltage (protect): 29 V 29 V Charging Voltage: 42,0 V...
- Page 5 EVBAT48V17A-G SPECIFICATION EVBAT48V13A-S Nominal voltage: 48 V Nominal capacitty: 13 Ah/624Wh 16,5 Ah/792 Wh Basic capacitty: * 12,35 Ah 16,2 Ah Constant discharge current: 30 A 30 A Peak discharge current: 35 A 35 A Minimal voltage (protect): 41 V 41 V Charging Voltage: 54,6 V...
- Page 6 (the distance between the frame and the edges of the battery should be 20 mm from the wheel frame). EVBAT36V13A-S Importer: GWL POWER a.s. CZ25948253 Škroupova 631/6, 500 02 Hradec králové...
- Page 7 EVBAT36V13A-S: EVBAT36V16A-S | EVBAT36V20A-G | EVBAT48V13A-S | EVBAT48V17A-G Importer: GWL POWER a.s. CZ25948253 Škroupova 631/6, 500 02 Hradec králové...
- Page 8 Drill the installation hole: Remove the battery holder. Then transfer the distance of the bolt pitch to the appropriate place of the wheel frame. Always try to make ready Battery holder Screw the battery holder to the frame Use screws suitable for screwing, the use of threaded rivets in pre-drilled holes is ideal if you do not have the bracket attached to the frame by self-tapping screws WARNING During assembly, ensure that the connector is securely mounted in the holder !!
- Page 9 Checking the charge status To check the charge status of the battery, press the button with the symbol. Depending on the current discharge status, the corresponding number of LEDs will light up. The number of LEDs illuminated indicates the discharge status. If only the red LED is lit, the battery must be recharged.
-
Page 10: Battery Use
BATTERY USE 1. Correct charging Lithium cells that contain EVBIKE batteries can be recharged in any discharge state and have no memory effect. For this reason, we recommend that you recharge the battery after a long break. This will allow you to enjoy full performance and long drive. Always disconnect the battery from the charger after charging. -
Page 11: Warranty
AND END USER TRAINING 1. Warranty The quality guarantee covers the manufacturing defects that the battery demonstrably showed at the time of delivery and the rated battery capacity at delivery. The warranty applies to the normal operating functionality within the specifications specified by the manufacturer. Guaranteed nominal battery capacity is achieved when discharging the recommended discharge current depending on battery type and temperature 25 °... - Page 12 • Protect from improper handling. • Do not insert the opposite polarity. When inserting, keep the markings. If the batteries are reversed, a short circuit or charging may occur. • Prevent short circuit. If the positive (+) and negative (-) battery terminals are connected together, a short circuit occurs.
- Page 13 Recycling of batteries and cells - statutory mandatory information a) the method of securing the take-back or separate collection; for this purpose, the manufacturer publishes, in a manner accessible to the end-user, the current list of take-back and separate collection points containing at least the name of the place and his address: Instead of take-back and separate collection: EVPower a.s., Průmyslová...
