  • Page 1 INSTALLATION MANUAL Wheel Drive Electric Bicycle Kit EVBIKE-SET-36V-26F EVBIKE-SET-36V-26R EVBIKE-SET-36V-28F...

  • Page 2: Table Of Contents

    Thank you for purchasing EVBIKE product and we hope that you will become a happy user. Carefully read the entire manual prior to installation and first use! If you find any fact in the manual that would prevent you from using our product, please contact your reseller for further discussion and keep the original packaging.
  • Page 3 Maximum rim load: 70 Kg** Rim material: Alluminium alloy 6061, (double wall) Total bicycle load up to 120 kg must not be exceeded (includes the weight of the rider, bike and EVBIKE set). www.EVBIKE.cz Importer: Global World Logistic Ltd., EU-VAT ID: CZ682998344...
  • Page 4 Pedal assistant LCD display + fixing Cable harness Accelerator For succesful assembly of EVBIKE, you will also need following: — ribbons for cables fastening — screws, nuts, washers — special bottom bracket tools (see pictures a, b, c) — basic technical skills...
  • Page 5 1. INSTALLING EVIBIKE HUB MOTOR 1) Remove the original wheel and swap tire to the EVBIKE HUB motor rim. Remove the original wheel and put tire with tube to the EVBIKE rim. Remember also protective wheel rim strip. Newly assembled wheel with HUB motor should be checked and trued after 100-200 km.
  • Page 6 The cable come out on left side of rear fork when the bike is in normal position. ● After installation the hub motor you will need to adjust the sorting of gears. Its needed to avoid a collision with the hub motor. www.EVBIKE.cz Importer: Global World Logistic Ltd., EU-VAT ID: CZ682998344...

  • Page 7: Pedal Assistant

    7) Before final tightening of all screws is necessary to check the correct functioning of pedaling detection. If you mount kit on a scooter, or operate it only in accelerator mode, you can skip pedal assistant assembly. www.EVBIKE.cz Importer: Global World Logistic Ltd., EU-VAT ID: CZ682998344...

  • Page 8: Controller And Cabling

    Damages due the incorrect cable or pins connecting will void your warranty. When connecting the motor connector and controller, make sure that the arrows on the connectors facing each other (Fig. 13). brake accelerator LCD display brake www.EVBIKE.cz Importer: Global World Logistic Ltd., EU-VAT ID: CZ682998344...

  • Page 9: Lcd Panel Instalation And Usage

    1. Travel time - since the last reset (TM) and overall (TTM) 2. Speed (km / h or MPH) - current speed, maximum speed recorded during the ride (MXS) and average speed (AVS) www.EVBIKE.cz Importer: Global World Logistic Ltd., EU-VAT ID: CZ682998344...
  • Page 10 14. Surrounding temperature in °C or °F. * Recovery function can be set in several grades. Incorrect setting can damage your battery or other electrical equipment components. For proper configuration, please contact the service partner EVBIKE. Description of the control buttons: On the control panel you will find three buttons arrow up...
  • Page 11 Volts is 100% and 40V and less means that the battery is low. The battery amount indicator in default setting will not function correctly for a 48V battery. In the service center EVBIKE it is possible to calibrate the indicator to measure the correct values for 48V.
  • Page 12 All contacts must be clean and dry. If this error occurs regularly, it will be necessary to stop using the bike and get to a repair service. www.EVBIKE.cz Importer: Global World Logistic Ltd., EU-VAT ID: CZ682998344...
  • Page 13 You can set these wheel diameters: 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 700c and 28 inches. For the speed measurement the unit EVBIKE uses signals from the hall probes of the engine.

  • Page 14: Brakes, Accelerator, Handle

    Safety first! CAUTION NEVER MANIPULATE MOVING PARTS IF BATTERY IS CONNECTED. RISK OF SERIOUSLY INJURY! BEFORE HANDLING TURN OFF LCD DISPLAY, DISCONNECT BATTERY AND REMOVE IT OUT OF THE HOLDER. www.EVBIKE.cz Importer: Global World Logistic Ltd., EU-VAT ID: CZ682998344...

  • Page 15: Maintenance

    7 MAINTENANCE It might seem that the EVBIKE set is almost maintenance free. Main care will definetely require your battery. Please check separate battery user manual for more infromation. In this manual you can find only basic guidelines how to use lithium batteries.
  • Page 16 Importer: Global World Logistic Ltd., EU-VAT ID: CZ682998344...
