Installation Instructions
1.5 Mains Fuse Replacement Table
Single-phase drives
To replace the same type of mains fuse installed in the unit, refer to Table 1.14. For a list of maximum mains fuse sizes that can be
installed in the unit, or for hp/kW sizes not shown in this chart, refer to the operating guide.
Unit rating
[kW] [hp] 208–230 V
0.37 0.5
0.55 0.75
0.75 1
1.1 1.5 LP-CC-15 15 A, 600 V, Class CC
1.5 2 JJN-20 20 A, 300 V, Class T
2.2 3 JJN-30 30 A, 300 V, Class T
3 4 JJN-35 35 A, 300 V, Class T
3.7/4 5 JJN-50 50 A, 300 V, Class T
5.5 7.5 JJN-60 60 A, 300 V, Class T
7.5 10 JJN-80 80 A, 300 V, Class T
11 15
15 20 FWX-150 150 A, 250 V
18.5 25
22 30 FWX-200 200 A, 250 V
30 40
37 50
45 60
55 75
75 100
90 125
Table 1.14 Mains Fuse Replacement (Single-phase)
MI92D402
Internal Mains Fuse Replacement for VLT
FC 102/FC 103/FC 202/FC 301/FC 302
FC 102/FC 103/FC 202
460–480 V
— —
— —
— —
—
—
—
—
—
—
—
— —
—
— —
—
— —
— —
— —
— —
— —
— —
