Installation Instructions
1
Fuse block plate
2
Input/mains connection
3
Relay connection (beneath the mains fuse block)
4
Motor connection (beneath the mains fuse block)
Illustration 1.4 B2 Enclosure (Single-phase)
MI92D402
Internal Mains Fuse Replacement for VLT
FC 102/FC 103/FC 202/FC 301/FC 302
1
2
3
4
Illustration 1.5 B2 Enclosure (3-phase)
Danfoss A/S © 10/2018 All rights reserved.
®
Drives, 0.25–90 kW (0.3–125 hp)
Fuse block plate
Input/mains connection
Relay connection (beneath the fuse block plate)
Motor connection (beneath the mains fuse block)
3
