Installation Instructions
1.4 Mains Voltage Ratings
Single-phase drives
FC 102/FC 103
[V]
kW (hp)
208–230
1.1 (1.5)
460–480
—
575–600
—
Table 1.4 A5 Enclosure (Single-phase)
FC 102/FC 103
[V]
kW (hp)
208–230
1.5–5.5 (2–7.5)
460–480
—
575–600
—
Table 1.5 B1 Enclosure (Single-phase)
FC 102/FC 103
[V]
kW (hp)
208–230
7.5 (10)
460–480
—
575–600
—
Table 1.6 B2 Enclosure (Single-phase)
FC 102/FC 103
[V]
kW (hp)
208–230
15 (20)
460–480
—
575–600
—
Table 1.7 C1 Enclosure (Single-phase)
FC 102/FC 103
[V]
kW (hp)
208–230
22 (30)
460–480
—
575–600
—
Table 1.8 C2 Enclosure (Single-phase)
MI92D402
Internal Mains Fuse Replacement for VLT
FC 102/FC 103/FC 202/FC 301/FC 302
FC 202
FC 301/FC 302 [NO]
kW (hp)
1.1 (1.5)
—
—
FC 202
FC 301/FC 302 [NO]
kW (hp)
1.5–5.5 (2–7.5)
—
—
FC 202
FC 301/FC 302 [NO]
kW (hp)
7.5 (10)
—
—
FC 202
FC 301/FC 302 [NO]
kW (hp)
15 (20)
—
—
FC 202
FC 301/FC 302 [NO]
kW (hp)
22 (30)
—
—
Danfoss A/S © 10/2018 All rights reserved.
®
Drives, 0.25–90 kW (0.3–125 hp)
FC 301/FC 302 [HO]
kW (hp)
—
—
—
FC 301/FC 302 [HO]
kW (hp)
—
—
—
FC 301/FC 302 [HO]
kW (hp)
—
—
—
FC 301/FC 302 [HO]
kW (hp)
—
—
—
FC 301/FC 302 [HO]
kW (hp)
—
—
—
kW (hp)
—
—
—
kW (hp)
—
—
—
kW (hp)
—
—
—
kW (hp)
—
—
—
kW (hp)
—
—
—
5
