BEFORE USING THE POWER SUPPLY UNIT
Be sure to read this instruction manual thoroughly before using this product. Pay attention to all cautions and warnings before
using this product. Incorrect usage could lead to an electrical shock, damage to the unit or a fire hazard.
DANGER
Never use this product in locations where flammable gas or ignitable substances are present. There are risks of igniting these
substances and exploding by an arcing.
WARNING
• When installing, ensure that work is done in accordance with the instruction manual.When installation is improper, there is
risk of electric shock and fire.
• Installation shall be done by Service personnel with necessary and appropriate technical training and experience. There is a
risk of electric shock and fire.
• Do not cover the product with cloth or paper etc. Do not place anything flammable around. This might cause damage,
electric shock or fire.
• Do not touch this product or its internal components while circuit in operation, or shortly after shutdown. There may be high
voltage or high temperature present and you may receive an electric shock or burn.
• While this product is operating, keep your hands and face away from it as you may be injured by an unexpected situation.
• Do not drop or insert anything into this product. It might cause a failure, fire and electric shock.
• Do not use this product under unusual condition such as emission of smoke or abnormal smell and sound etc.
It might lead to fire and electric shock. In such cases, please contact us. Do not attempt repair by yourself, as it is dangerous for
the user.
• Do not make unauthorized changes to this product nor remove the cover as you might get an electric shock or might
damage the product. We will not be held responsible after the product has been modified, changed or dis­assembled.
• Do not operate and store these products in environments where condensation occurs due to moisture and humidity. It might
lead fire and electric shock.
• Do not drop or apply shock to this product. It might cause failure. Do not operate these products mechanical stress is
applied.
CAUTION
• Do not use this product in special environment with strong electromagnetic field, corrosive gas or conductive substances
and direct sunlight, or places where product is exposed to water or rain.
• Mount this product properly in accordance with the instruction manual, mounting direction and shall be properly be
ventilated.
• This power supply is designed and manufactured for use within an end product such that it is accessible to
SERVICE ENGINEERS only.
• Confirm connections to input/output terminals are correct as indicated in the instruction manual before switching on.
• Input voltage, Output current, Output power, ambient temperature and ambient humidity should be kept within specifications,
otherwise the product will be damaged.
• Do not use this product in environment with a strong electromagnetic field, corrosive gas or conductive substances.
• For applications, which require very high reliability (Nuclear related equipment, medical equipment, traffic control equipment, etc.),
it is necessary to provide a fail­safe mechanism in the end equipment.
• Never operate the product under over current or short­circuit conditions, or outside its specified Input Voltage Range.
Insulation failure, smoking, burning or other damage may occur.
• This product contains a printed circuit board utilizing surface mounted devices.
PCB stress such as bending, twisting etc. could cause damage. Therefore, please handle with care.
• This power supply has possibility that hazardous voltage may occur in output terminal depending on failure mode.
The output of these products must be protected in the end use equipment to maintain SELV.
• The information in this document is subject to change without prior notice. Please refer to the latest version of the data sheet,
etc., for the most up­to date specifications of the product.
• No part of this document may be copied or reproduced in any form without prior written consent of TDK­Lambda.
Note : CE MARKING
CE Marking, when applied to a product covered by this handbook, indicates compliance with the low voltage directive.
DRJ15­100 Series
Instruction Manual
<Page>
1/14
TDK­Lambda
Series
DRJ15­100
INSTRUCTION MANUAL
A265­04­01

Advertisement

loading
Need help?

Need help?

Do you have a question about the DRJ15 and is the answer not in the manual?

Questions and answers

Summary of Contents for TDK-Lambda DRJ15

  • Page 1 TDK­Lambda Series DRJ15­100 INSTRUCTION MANUAL DRJ15­100 Series Instruction Manual BEFORE USING THE POWER SUPPLY UNIT Be sure to read this instruction manual thoroughly before using this product. Pay attention to all cautions and warnings before using this product. Incorrect usage could lead to an electrical shock, damage to the unit or a fire hazard.
  • Page 2 /C2E : European terminal type compliant with UL60950­1 Class 2 output (*2) Output Power type (*2) Option of DRJ100 Series Name 2. Terminal Explanation DRJ15, DRJ30 DRJ15/E, DRJ30/E +V : +Output terminal -V -V 24VDC/1.25A 24VDC/1.25A -V : -Output terminal V.ADJ...
  • Page 3: Connecting Method

    DRJ15-24-1 DC OK DRJ50-24-1 DRJ100-24-1 100-240VAC 100-240VAC 100-240VAC Recommended torque : DRJ15, DRJ30 Input, Output terminal 1.0N·m (10.2kgf·cm) ~ 1.4N·m (14.2kgf·cm) DRJ15, DRJ30 terminal 1.0N·m (10.2kgf·cm) DRJ50, DRJ100 Input, Output terminal, terminal 1.0N·m (10.2kgf·cm) ~ 1.4N·m (14.2kgf·cm) DRJ15/E, DRJ30/E DRJ50/E...
  • Page 4 TDK­Lambda Series DRJ15­100 INSTRUCTION MANUAL 4. Explanation of Functions and Precautions 4­1. Input Voltage Range Input voltage range is single phase 85­264VAC (47­63Hz) or 120­370VDC. Input voltage, which is out of specification, might lead unit damage. For cases where conformance to various safeties required, described as 100­240VAC (50­60Hz).
  • Page 5 TDK­Lambda Series DRJ15­100 INSTRUCTION MANUAL 4­7. Series Operation For series operation, either method (A) or (B) is possible. Method (A) Method (B) + Power Power Load Supply Supply - ­V ­V + Load - + Power Power Load Supply Supply -...
  • Page 6 Withstand Voltage Tester Note 1 : DRJ15, DRJ30 have monolithic ceramic capacitor in secondary circuit to Some of the withstand voltage tester may generate high voltage at the matching with monolithic ceramic capacitor and may cause the unit damage. So, please check the waveform of applied voltage.
  • Page 7: Mounting Directions

    Refer to the derating below. Do not exceed the load deratings. Load (%) is percent of maximum output power or maximum output current, do not exceed its derating of maximum load. DRJ15, DRJ30, DRJ50 ( Include option model /E ) Mounting (A)
  • Page 8 Series DRJ15­100 INSTRUCTION MANUAL 5­3. Output Derating according to Input Voltage Load(%) is percent of maximum output current value in a rated output voltage. DRJ15, DRJ30, DRJ50, DRJ100 ( Include option model /E ) Load (%) Input Voltage (VAC) Mounting (A), (B) 90 ­...
  • Page 9 DRJ series can be used with contact to the insulating chassis. (not covered by safety standard). However, never use in contact mounting with heat source such as power supply. Refer to the below derating for contact mounting. DRJ15 ( Include option model /E ) Mounting (A) Mounting (B)
  • Page 10: Wiring Method

    TDK­Lambda Series DRJ15­100 INSTRUCTION MANUAL 6. Wiring Method (1) The output load line and input line shall be separated, and use all lines as thick and short as possible to make lower impedance. The output load line and input line shall be twisted or use shielded wire to improve noise sensitivity.
  • Page 11 The life expectancy of power supply is calculated in condition of rated input voltage and 24­hour continuous operation. Load (%) is percent of maximum output power or maximum output current, do not exceed its derating of maximum load. ♦ DRJ15 Mounting(A) Mounting(B) years...
  • Page 12 8. Internal Fuse Rating Fuse is in Live line. DRJ series uses time­lug fuse. DRJ15, DRJ30 : AC250V, 2.5A DRJ50, DRJ100 : AC250V, 3.15A 9. External Fuse Rating Refer to the following fuse rating when selecting the external input fuse.
  • Page 13 TDK­Lambda Series DRJ15­100 INSTRUCTION MANUAL (2) Press against the bottom front side for locking. Shake the unit slightly to check the locking action. 10­2. Power supply removal from DIN RAIL Switch main power off and disconnect your system from the supply network. Push the button on the rear upper edge of the unit or move the removal hole on the rear down edge downwards by rotating screw driver.
  • Page 14: Warranty Period

    TDK­Lambda Series DRJ15­100 INSTRUCTION MANUAL 12. DRJ series UL508 Listed Condition (1) Wire Requirement Use minimum 75 C wire Use copper conductor only (2) For use in a Pollution degree 2 environment only (3) These products are considered for use where maximum surrounding air temperature does not exceed 70 When installing these products please refer to section 5­2 for deratings.
