TDK-Lambda DRJ120 Series Instruction Manual

BEFORE USING THE POWER SUPPLY UNIT (Common)
Be sure to read this instruction manual thoroughly before using this product. Pay attention to all cautions
and warnings before using this product. Incorrect usage could lead to an electrical shock, damage to the unit
or a fire hazard.
DANGER
Never use this product in locations where flammable gas or ignitable substances are present.
INSTALLATION WARNING
• When installing, ensure that work is done in accordance with the instruction manual. When installation is
improper, there is a risk of electric shock and fire.
• Installation shall be done by Service personnel with necessary and appropriate technical training and
experience. There is a risk of electric shock and fire.
• Do not cover the product with cloth or paper etc. Do not place anything flammable around. This might
cause damage, electric shock or fire.
WARNING on USE
• Do not touch this product or its internal components while circuit in operation, or shortly after shutdown.
You may receive a burn.
• While this product is operating, keep your hands and face away from it as you may be injured by an
unexpected situation.
• There are cases where high voltage charge remains inside the product. Therefore, do not touch even if
they are not in operation as you might get injured due to high voltage and high temperature.
You might also get electric shock or burn.
• Do not make unauthorized changes to this product nor remove the cover as you might get an electric
shock or might damage the product. We will not be held responsible after the product has been modified,
changed or dis-assembled.
• Do not use this product under unusual condition such as emission of smoke or abnormal smell and sound
etc. Please stop using it immediately and shut off the product.
It might lead to fire and electric shock. In such cases, please contact us. Do not attempt repair by yourself,
as it is dangerous for the user.
• Do not operate and store these products in environments where condensation occurs due to moisture and
humidity. It might lead fire and electric shock.
• Do not drop or apply shock to this product. It might cause failure. Do not operate these products
mechanical stress is applied.
CAUTION on MOUNTING
• Confirm connections to input/output terminals are correct as indicated in the instruction manual before
switching on.
• Input/output lines, please use the wires as short and thick as possible.
• Do not use this product in special environment with strong electromagnetic field, corrosive gas or
conductive substances and direct sunlight, or places where product is exposed to water or rain.
• Mount this product properly in accordance with the instruction manual, mounting direction and shall be
properly be ventilated.
DRJ120, 240 Series
Instruction Manual
1/14
TDK-Lambda
DRJ120, 240 Series
INSTRUCTION MANUAL
PA637-04-01B
