Apollo Sprayers PRECISION-5 Instruction Manual page 18

Diagram # Part #
1 A4501
2 A4198
3 A4320
4 A4300
5 A4308
6 A9016
7 A4998
8 A4503
9 A4033
10 A2116
11 A2119
12 A4026
13 A4310
14 A4502
15 A4613
16 A4200
Description
Compressor Deck
110v Mini Compressor Unit
1/4" X 20 X 1/2" Hex Bolt Plated .5.
1/4" SAE F/W Plated Washer
1/4" X 20 Hex Nuts Plated
Rubber Foot
Pressure Regulator
1/8" Male NPT X 1/4" Male Hose Barb 90°
Air Line Hose Clip S.S.
1/4" Air Hose, Per Foot
1/4" X 1/4" Female Swivel Barb
Quick Connect Female With 1/4" Male Thread
1/4" X 20 Cap Nut Plated
Pressure Pot Support Bracket
Rubber Edge Trim
2 Quart Pressure Pot W/Single Regulator
Page 18
Quantity
1
1
12
16
4
4
1
1
2
3
1
1
8
1
2
1
