3. MAIN PARTS AND CONTROLS
BOOXTER TRIO
1. Worktop (plastic)
2. Carriage
3. Paper guide
4. Adjustable back support
5. Fixed back support
11. Support lath
12. Control panel
13. Main switch
14. AC IN connector and
main fuse
15. Foot pedal connector
16. Type plate and
serial number
17. Screws (shelf)
18. Supply shelf
19. Thumb screws
6
9
8
6. Positioning deck
7. Guide bracket
8. Safety cover, stapling unit,
staple cassette and
operating light
Side view, front
11
FASTBIND BooXTer Uno/Duo/Trio USER MANUAL | Version 0.1 | © Maping Co 2010
7
6
5
Top view, front
9. Detection sensor
19
12
13
4
3
2
1
19
18
17
15
16
14
