INSTALLATION INSTRUCTIONS

ECR 31
ECR supply and exhaust air system with integrated air heater and filter.
Matched to one another - Supply and exhaust air box with synchronised air volumes.
Convenient control - Supply and exhaust air boxes can be set using a shared remote control.
Pre-assembled - Supply air unit with fan, electric air heater, filter and controller. Makes fast and error-free installation pos-
sible.
Tempered - With pluggable, continuous controller. For constant, pleasantly temperate supply air, even in winter.
Quiet - Double-wall, sound insulated housing. For high demands for low noise levels and high levels of thermal insulation.
"Point-of-use" - Can be used directly in the lounge, e.g. in suspended ceilings.
Simple - Filter can be changed in seconds, without tools.
Can be combined in any way - Supply and exhaust air boxes can be used in tandem and on their own.
ECR compact box and ECR-A exhaust air box in tandem
