- Page 3 Automatic and manual models. Single phase power only - 115 or 230 volt. SSM33I SRM4 SUMP/EFFLUENT PUMPS SUMP/EFFLUENT/SEWAGE PUMPS (115 Volt-Single Phase Only) (115 or 230 Volt-Single Phase) *The SSM33 series pumps have been replaced by the SSM33I series pump as of February 2000. 13800A991 Bag #18812A100...
- Page 4 TYPICAL SECTION DRAWING FOR SSM33/SSM33I SERIES Piggy-Back Control Control Vertical Float Switch 10’ Cord Control Vertical Float Switch 20’ Cord. Not Shown (Automatic Only) Cable Tie. Not Shown (Automatic Only) 13800A991...
- Page 5 TYPICAL SECTION DRAWING FOR SRM4 SERIES Piggy-Back Control Cable Tie Not Shown (Automatic Only) 13800A991...
- Page 6 PARTS LIST SSM33/SSM33I AND SRM4 Part Part Description Req’d Numbers Description Req’d Numbers Ring, Lift 26230A000 Plate, Bottom, with Volute Case 27005D000 Plug, 1/4” NPT 05022A056 Screw, Tapping, #10 x 1” Lg. Plate, Name (Not Stamped) 23780A000 (SSM33, SRM4) 09822A036 Tapping, Screw (SSM33/SSM33I) 09822A032 Screw, Tapping, #10 x ¾”...
-
Page 7: Safety Warnings
UL AND CSA APPROVAL shipping. However, occasionally damage may result due to All pumps have UL and CSA approval pending. Myers is a rough handling. Carefully go over the pump and check for SSPMA certified pump member. - Page 8 Have methane, hydrogen sulfide and other gasses which are ELECTRICIAN make electrical checks. highly poisonous. For this reason, Myers recommends (d) Check for burned out motor. Occasionally lightning installing effluent pumps with a quick removal system. The can damage a motor even with lightning protection.
- Page 9 TYPICAL SUMP INSTALLATION FOR SSM33/SSM33I Series GROUNDED TYPE 115 OR 230 VOLT RECEPTACLE. MIN. HEIGHT ABOVE FLOOR 4 FEET. PUMP CORD PLUGS NTO SERIES WITCH CORD FOR AUTOMATIC OPERTION. PUMP CORD CAN BE PLUGGED DIRECTLY INTO RECEPTACLE FOR MANUAL OPERATION. MIN.
- Page 10 TYPICAL SUMP INSTALLATION FOR SRM4 SERIES GROUNDED TYPE 115 OR 230 VOLT RECEPTACLE. MIN. HEIGHT ABOVE FLOOR 4 FEET. PUMP CORD PLUGS NTO SWITCH CORD FOR AUTOMATIC OPERTION. PUMP CORD CAN BE PLUGGED DIRECTLY INTO RECEPTACLE FOR MANUAL OPERATION. BOTH SWITCH AND PUMP CORDS ARE 20 FT.
- Page 11 Evenly tighten screws. (4) Disconnect the switch from its tether point and remove (10) Replace oil in the motor housing using only Myers from the discharge piping. submersible transformer oil. The level should be 3/4”...
-
Page 12: Power Cord Replacement
(5) Reinstall the power cord as noted in the previous section. (6) Replace oil in the motor housing using only Myers submersible transformer oil. The level should be 3/4” below the top of the motor housing. Check with dip stick to assure that the pump is properly filled. -
Page 13: Performance Curves
SRM4 DIMENSIONAL DRAWING Turn On Turn Off PERFORMANCE CURVES F. E. Myers, 1101 Myers Parkway, Ashland, Ohio 44805-1969 419/289-1144, FAX: 419/289-6658, www.femyers.com 13800A991 8/01 Myers (Canada), 269 Trillium Drive, Kitchener, Ontario N2G 4W5 519/748-5470, FAX: 519/748-2553... -
Page 14: Warranty Period
SUMP & RESIDENTIAL SEWAGE During the time periods and subject to the conditions hereinafter set forth, F. E. Myers will repair or replace to the original user or consumer any portion of your new MYERS product which proves defective due to defective materials or workmanship of MYERS.
