  • Page 1 User’s Manual SRP-370/372 Ver.2 Thermal Printer Rev. 2.01 http://www.samsungminiprinters.com...

  • Page 2: Srp-370/372 Ver

    PROHIBITED Do not pull the cable to unplug. • This can damage the cable, which is the origin of a fire or a breakdown of the printer. PROHIBITED Do not plug in or unplug with your hands wet. • You can be electrocuted.
  • Page 3 • After the disappearance of the smoke, call your dealer to repair it. TO UNPLUG PRINTER Install the printer on the stable surface. • If the printer falls down, it can be broken and you can hurt yourself. PRINTER PROHIBITED Do not let water or other foreign objects in the printer.

  • Page 4: Label Material

    Some semiconductor devices are easily damaged by static electricity. You should turn the printer “OFF”, before you connect or remove the cables on the rear side, in order to guard the printer against the static electricity. If the printer is damaged by the static electricity, you should turn the printer “OFF”.
  • Page 5 SRP-370/372 Ver.2 ■ Introduction The SRP-370/372 Roll Printer are designed for use with electronic instruments such as system ECR, POS, banking equipment, computer peripheral equipment, etc. The main features of the printer are as follows: 1. High speed printing : 47/52 (1/6” Feed) lines per second.

  • Page 6: Table Of Contents

    ■ Table of Contents 1. Setting Up the Printer ... 7 1-1 Unpacking... 7 1-2 Connecting the Cables ... 8 1-2-1 Serial Interface (RS-232C) ... 8 1-2-2 Parallel Interface (IEEE1284) ... 9 1-2-3 USB Interface ... 10 1-3 Connecting the Drawer ... 10 1-4 Setting the Dip Switches...

  • Page 7: Setting Up The Printer

    SRP-370/372 Ver.2 1. Setting Up the Printer 1-1 Unpacking Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. SRP-370/372 Cover Cable Roll Paper Manual AC Adapter Power Cord - 7 -...

  • Page 8: Connecting The Cables

    1-2 Connecting the Cables You can connect up the three cables to the printer. They all connect to the connector panel on the back of the printer, which is shown below: ※ NOTE Before connecting any of the cables, make sure that both the printer and the host are turned off.

  • Page 9: Parallel Interface (Ieee1284)

    1-2-2 Parallel Interface (IEEE1284) POWER Drawer kick-out Power supply connector connector Pin No. Source Host Host / Printer Host / Printer Host / Printer Host / Printer Host / Printer Host / Printer Host / Printer Host / Printer Printer...

  • Page 10: Usb Interface

    Do not connect a telephone line to the drawer kick-out connector; otherwise the printer and the telephone line may be damaged. Plug the drawer cable into the drawer kick-out connector on the back of the printer next to the power supply connector.

  • Page 11: Setting The Dip Switches

    1-4 Setting the Dip Switches 1-4-1 Serial Interface Switch No. Function SW1-1 Baud Rate Selection SW1-2 SW1-3 Handshaking SW1-4 Reserved SW1-5 Cutter Function SW1-6 Paper SW1-7 Reserved SW1-8 Reserved SW1-1 Switch No. Function SW2-1 Select Print Density SW2-2 SW2-3 SW2-4 Historical Control SW2-5 Reserved...

  • Page 12: Parallel & Usb Interface

    1-4-2 Parallel & USB Interface Switch No. Function SW2-1 Select Print Density SW2-2 SW2-3 SW2-4 Historical Control SW2-5 Reserved Interface Condition SW2-6 Selection SW2-7 Near End Sensor Status SW2-8 Printing width SW 2-1 SW 2-2 1-4-3 Auto Cutter Enable / Disable selection SW 5 Application Rev.

  • Page 13: Setting The Memory Switches

    The Memory Switch is available to be changed by three methods : - Memory Switch setting utility. - Control from ESC/POS command. Settings of the Memory Switch are stored in the NV memory : therefore, even if the printer is turned off, the settings are maintained. MSW1...
  • Page 14 MSW2-8 MSW2-7 MSW2-6 MSW2-5 MSW2-4 MSW2-3 Character Table MSW8 Switch Function Reserved MSW9 Switch Function Reserved Data Length Parity Selection Parity Check Flow Control Baud Rate Selection MSW9-8 Rev. 2.01 7 Bits Even Enable XON/XOFF MSW9-7 MSW9-6 - 14 - SRP-370/372 Ver.2 Page 0...

  • Page 15: Installing Or Replacing The Paper Roll

    1-6-2 Open the paper roll cover by pressing the cover-open button. ※ NOTE Do not open the print cover while the printer is operating. This may damage the printer. 1-6-3 Remove the used paper roll core if there is one.
  • Page 16 1-6-5 Be sure to note the correct direction that the paper comes off the roll. 1-6-6 Pull out a small amount of paper, as shown. Then close the cover. ※ NOTE When closing the cover, press the center of printer cover firmly to prevent paper miss-loading. 1-6-7 Tear off the paper as shown.

  • Page 17: Adjustments And Settings

    SRP-370/372 Ver.2 1-7 Adjustments and Settings It has 2 features ; Paper end and Black mark. For detecting Paper End, it must be positioned at "a" Position in drawing and it is a factory default setting. For detecting Black mark printed on the paper, it must be moved to "b" position. Optical density (O.D) must be higher than 0.6 in density to secure a standard working condition.

  • Page 18: Using The Printer

    ○ PAPER This light indicates the near end of the paper roll. Install a new paper roll and the printer will continue printing. When the light blinks, it indicates the self-test printing standby state or macro execution Standby state when the macro execution command is used.

  • Page 19: Connecting The Power Supply

    Do not plug in the power cord. Otherwise, you may damage the power supply or the printer. 1-10-1 Make sure that the printer’s power switch is turned off, and the power supply’s power cord is unplugged from the electrical outlet.

  • Page 20: Self Test

    2. Self Test The self-test checks whether the printer has any problems. If the printer does not function properly, contact your dealer. The self-test checks the following; 2-1 Make sure paper roll has been installed properly. 2-2 Turn on the power while holding down the FEED button. The self-test begins.

  • Page 21: Hexadecimal Dumping

    3-3 Close the cover, then the printer enters the hexadecimal dump mode. 3-4 Run any software program that sends data to the printer. The printer will print all the codes it receives in a two-column format. The first column contains the hexadecimal codes and the second column gives the ASCII characters that corresponds to the codes.

  • Page 22: Specification

    4. Specification Printing method Dot density Printing width Paper width Characters per line (default) Printing speed 180 DPI 203 DPI Receive Buffer Size ※ NOTE Printing speed may be slower, depending on the data transmission speed and the combination of control commands. Supply voltage SMPS Input voltage Frequency...

  • Page 23: Appendix

    Ver.2 5. Appendix 5-1 Cleaning Printer Paper dust inside the printer may lower the print quality. In this case clean the printer as follows. 5-1-1 Open the printer cover and remove the paper if exists. 5-1-2 Clean the print head with a cotton swab moistened with alcohol solvent.
