McKenzie Bed Collection
AFGAC = Glazed Antique Cherry finish
AFCAF = Caffè finish
Model #
1346AFGACc
1346AFCAFc
McKenzie Queen Bed
1349AFGACc
1349AFCAFc
McKenzie King Bed
Congratulations!
This fine piece of furniture will make a gorgeous
addition to your home. For the best results, read the
Assembly Instructions and before you begin
your project.
CALL US FIRST!
Service Policy: We will replace any part that is
defective, missing or damaged during assembly.
Please contact Whittier Wood Products customer
service department directly by phone, fax, mail or
email for a replacement part.
Hours: Our friendly customer service staff can be
reached Monday-Friday 7:00 a.m. to 5:00 p.m.
(Pacific Time). You may leave a message 24 hours
a day, seven days a week.
800-653-3336
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.
P.O. Box 2827
Eugene, OR 97402 USA
Model #
1341AFGACc
1341AFCAFc
McKenzie Twin Bed
Model #
• Outside the U.S. or Canada: 541-687-0213 • Fax: 541-687-2060
IMPORTANT NOTES:
For normal household use only. Not recommended
for commercial use.
Unload items before you move this unit.
Before you load or move this unit, check to make
sure all screws and supports are tight.
Before you begin your project, completely read the
Assembly Instructions.
Store this item: 1- in its box; 2- in a dry place; 3- in
temperatures that range from 40°F to 90°F (not on
a cold and possibly damp cement floor).
Periodically inspect your furniture for any loose
glue joints, screws or any other problem that might
affect the stability of your furniture. Tighten or
repair as needed.
This assembly requires two people.
Do not return this item to the store.
To Order: Designate the finish, provide the furniture model
number (found next to the illustration of your unit), the part
letter, production code, quantity needed, reason for
replacement, your full name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one
or two business days from the time we receive your
request. Please allow five to ten business days for delivery.
Production Code:
VN
.
05/10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whittier Wood 1346AFGACc
Summary of Contents for Whittier Wood 1346AFGACc
- Page 1 To Order: Designate the finish, provide the furniture model defective, missing or damaged during assembly. number (found next to the illustration of your unit), the part Please contact Whittier Wood Products customer letter, production code, quantity needed, reason for service department directly by phone, fax, mail or replacement, your full name, address and telephone number.
- Page 2 1341AFGACc or 1341CAFc McKenzie Twin Bed; 1346AFGACc or 1346CAFc McKenzie Queen Bed; 1349AFGACc or 1349CAFc McKenzie King Bed — Parts List Please identify the parts and check that quantities received match those on this list. If you need to replace a part, refer to the following letter and model name.
- Page 3 1341AFGACc or 1341AFCAFc McKenzie Twin Bed; 1346AFGACc or 1346CAFc McKenzie Queen Bed; 1349AFGACc or 1349AFCAFc McKenzie King Bed Assembly Instructions This Assembly Requires Two People Tools Required: 5mm Hex Wrench (provided) and Phillips Screwdriver C or Cb Shipping Straps Fig. 1 1346AFGACc shown in illustrations.
- Page 4 Fig. 3a Fig. 3 Using the Hex Wrench (N) provided, attach the Footboard (B) to the Rails with 6 x 12mm Hex Bolts (H) and 1/4" Lock Washers (J) as shown in Figures 3 and 3a. Fig. 4 NOTE: Not applicable for the Twin Bed. Attach an Assembled Foot (Db) to four of the Slats (Cb) as shown in Figure 4.
- Page 5 Fig. 5 Position the Slats (C for Twin; Cb for Queen or King) on the bottom edges of the rails as shown in Figure 5. Attach with #8 x 1-1/4" Black Screws (E). For the Queen or King bed, place the slat without the Foot Assembly attached nearest to the Footboard.
