1321AFGAC
McKenzie Harmony
Queen Storage Bed
Model #
1330AFGAC
McKenzie Harmony
King Storage Bed
Assembly Instructions
Congratulations!
This fine piece of furniture will make a handsome
addition to your home. For the best results, start
by reading the Assembly Instructions before you
begin your project.
For normal household use only.
recommended for commercial use.
Unload items from this unit prior to moving.
Before
loading or moving this unit, check all screws
and supports for tightness.
Do not overload the drawers.
Keep children away from electrical components.
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
P.O. Box 2827
Eugene, OR 97402 USA
1321AFGAC shown
Service Policy:
which are defective, missing or damaged.
Please contact Whittier Wood Products
customer service department directly (by
phone, fax, mail or E-mail) for replacement
parts.
Hours:
Our friendly customer service staff
can be reached Monday-Friday 7:00 a.m. to
5:00 p.m. (Pacific Time). A message can be
left 24 hours a day, 7 days a week.
To Order:
Provide the complete furniture
model number, part letter, production code,
quantity needed, reason for replacement
and your full name and address along with
a telephone number in case we need to
contact you.
Parts ship from our Eugene, Oregon factory
within 1 or 2 business days from the time
we receive the request. Please allow 5-10
business days for delivery.
800-653-3336
800-653-3336
Outside U.S. or Canada: 541- 687- 0213
Outside U.S. or Canada: 541- 687- 0213
Fax: 541-687-2060 • w ww
Fax: 541-687-2060 •
Mail: P.O. Box 2827 • Eugene, Oregon 97402, U.S.A
Mail: P.O. Box 2827 • Eugene, Oregon 97402, U.S.A
Completely read the Assembly Instructions before
you begin your project.
Store the item: 1) in the box; 2) in a dry place; 3) in
temperatures ranging from 40° to 90°. (Not on a cold,
possibly damp, cement floor.)
Inspect your furniture periodically for any loose glue
joints or screws, or any other problem which may be
affecting the stability of your furniture. Tighten or repair
as needed.
This Assembly requires two people.
Production Code:
VN
We will replace parts
w ww.whittie
.whittier r wood.com
wood.com
12/08
