McKenzie Twin Storage Beds
GAC = Glazed Antique Cherry finish
CAF = Caffè finish
Assembly Instructions
Model #
1300GACf
1300CAFf
McKenzie
Twin Storage
Bed
Model #
1359GACf
1359CAFf
McKenzie
Twin Bookcase
Storage Bed
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Fax: 541-687-2060• Email: info@whittierwood.com
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
• For normal household use only. Not recommended for commercial use.
• Remove items before you move this unit.
• Do not overload the drawers.
• This assembly requires two people.
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code:
VN
WARNING
08/17
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Whittier Wood 1300GACf
Summary of Contents for Whittier Wood 1300GACf
- Page 1 If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you cannot order replacement parts through your dealer, please contact our customer service department.
- Page 2 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Parts List Please identify the parts and check that quantities received match those on this list. If you need to replace a part, refer to the following letter and part name.
- Page 3 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Parts List Part Description Quantity Adjustable Glide (installed) Knob (attached) 20" Drawer Slides (pre-installed sets) #6 x 1/2" Philtruss Screw (18 inserted) #6 x 3/4" Philtruss Screw (inserted) 1/4"...
- Page 4 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Parts List 1302GAC 1302CAF Twin Headboard Kit (x1) Part Description Quantity Headboard Assembly Left Bracket (attached) Right Bracket (attached) #8 x 1" Black Screw (inserted) #8 x 1-1/4" Pan Head Screw (inserted) #12 x 2-1/2"...
- Page 5 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Parts List 1361GACf 1361CAFf Bookcase Headboard Kit (x1) Part Description Quantity Left Bracket (attached) Right Bracket (attached) #8 x 1" Black Screw (inserted) Bookcase Headboard Assembly...
- Page 6 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Parts List Part Description Quantity Tack Glide (attached) #8 x 1-3/8" Lo-Profile Screw (inserted) 1300GACf_1300CAFf_1359GACf_1359CAFf — Page 6 — 08/17...
- Page 7 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Assembly Instructions This assembly requires two people. Tools Required: Phillips screwdriver, Slotted Screwdriver, 7/16" open end or box end wrench. Remove the Assembled Feet (YM) from the back of the Footboard (YB) as seen in Figure 1 and place them off to the side.
- Page 8 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Assembly Instructions This assembly requires two people. To attach the Side Panel (YH) to the Footboard (YB), align the brackets and slide the Side Panel (YH) down on to the Footboard (YB). See Figures 3 and 3a.
- Page 9 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Assembly Instructions This assembly requires two people. Place one end of a Trestle with T-Nuts (YI) facing towards the Headboard, behind the rib in the pedestal closest to the Headboard. Place the other end of the Trestle into the notched bracket in the Side Panel (YH).
- Page 10 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Assembly Instructions This assembly requires two people. Using the 90° brackets with two holes (YW) attach the two middle Trestles to the notched brackets in the Side Panel (YH) with four #6 x 1/2" Philtruss Screws (YS).
- Page 11 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Assembly Instructions This assembly requires two people. Facing the Footboard, attach the lower brace of the Pedestal Assembly to the Footboard with the 90° bracket with four holes (ZG) and four #6 x 1/2" Philtruss Screws (YS). See Figures 9 and 9a.
- Page 12 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Assembly Instructions This assembly requires two people. 11. If you have a Bookcase Headboard, stand in the open area of the assembly and reach behind the bookcase front legs to find the Large Adjustable Glides (T). Using a slotted screw driver, rotate the Large Adjustable Glides (T) clockwise until they bear weight.
- Page 13 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Assembly Instructions This assembly requires two people. 12. To make sure the bed is square, measure the distance between opposing corners. If one of the measurements is larger tap on a footboard leg until the measurement is equal. See Figure 12.
- Page 14 1300GACf 1300CAFf McKenzie Twin Storage Bed & 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed Assembly Instructions This assembly requires two people. Steps 14 – 15 are for the Bookcase Headboard Only 14. To adjust the brake tension on the Door Stay (K) turn the screw on the Door Stay clockwise to loosen or counterclockwise to tighten.
