Packing List

Part Number
904.8T
80.55
81.312.1
25.68.20
C.12B
100.12.SV1
58.5
904.8KY
81.16.1
I974

Operational Requirements

Trigger Signal Inputs
Motors/Solenoid Valves
Detergent Pump Rate
Rinse/Sanitizer Pump Rate
Operating Temp
Case Material
The integrity and operational characteristics of this unit are not guaranteed outside the above
mentioned parameters. Use of this unit outside of these parameters nullifies warranty.
This unit will only accept up to 265 VAC. It cannot accept over this amount. If more than 265
VAC is supplied to this unit, critical damage will occur.

Overall Size

I-974
Rev. J-43816 3/23/18
X = included in kit
Description
RINSE CHECK VALVE ¼" OD TEFLON BALL
LIQUID DETERGENT FEED INJECTION ELBOW
SPLIT PICK UP TUBE STIFFENER
20 FT ¼" OD LDPE TUBING
CONDUCTIVITY CELL
VINYL RINSE TUBING
OVERFLOW ELBOW KIT – DRY DETERGENT
RINSE CHECK VALVE ¼" COMP X 1/8" NPT KYNAR
TIE WRAPS 8" LONG
INSTRUCTION SHEET
For indoor use only
X
1
X
X
X
X
5
X
115/230VAC 50/60 Hz 1.5A
24VDC
6oz/min (180ml/min)
1.3oz/min (40ml/min)
4-30°C 40-100°F
ABS
X X X
X X
2 2 3
X X X
X X X
X X X
X
X X
5 8 8
X X X
