Nitro Existing Program Training
December 1, 2009

Advertisement

loading
Need help?

Need help?

Do you have a question about the Nitro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DEMA Nitro

Summary of Contents for DEMA Nitro

  • Page 1 Nitro Existing Program Training December 1, 2009...
  • Page 2 Nitro bridges the gap between compact basic dispensers and large dispensers with multi-features but too bulky for smaller kitchen environments – Probe or probeless operation from the same unit – Pre-wired power supply – Password protected digital programming – Multi-lingual display –...
  • Page 3 Nitro Features • 100-260VAC 50/60Hz main power (constant power) • 24-480VAC trigger signals • Detergent pump output 6 oz./min (180ml / min) • Rinse pump output 1.3 oz./min (40ml / min)
  • Page 4 Nitro Button Functions SANITIZER EXIT button PRIME button exits the primes programming sanitizer and and moves moves cursor cursor right in left in programming programming ENTER button Rinse Prime enters / UP arrow programming primes rinse and accepts values entered...
  • Page 5 Idle Screen & Priming • Idle / Default screen shown when unit is not being programmed • Unit will return to this screen during long periods of no button activity • Press and hold any prime button to prime each pump...
  • Page 6 Language Screen- English • Press ENTER to modify language • Use UP & DOWN arrows to select between 4 languages – English, Spanish, Portuguese and French • Press ENTER to select desired language • Press DOWN arrow for Rack Count screen...
  • Page 7 Rack Count • Displays number of rack counts registered • Rack counts are generated by rinse length in conveyor mode or machine operations in door mode • Press DOWN arrow for Information screen...
  • Page 8 Information Screen • Displays the following information • DET – P = Probeless mode – C = Concentration mode • SP – Not applicable for probeless mode – Detergent set point in concentration mode • Input – Actual probe reading •...
  • Page 9 System Access Screen • Allows program and setup features to be modified • Press ENTER to gain access • Note: The training covers Concentration mode 1 followed by Probeless mode...
  • Page 10 Enter Code – Concentration Mode • Enter code to gain access • Use SANITIZER button to move cursor left and EXIT button to move cursor right • Use UP & DOWN arrows to change digit in each position • Press ENTER when access code is displayed...
  • Page 11 Concentration Mode – Concentration Set Point • Press ENTER to modify setting • Use UP & DOWN arrows to adjust concentration set point • Press ENTER when desired setting is displayed • Press DOWN arrow to advance to feed rate...
  • Page 12 Concentration Mode – Feed Rate • Controls how quickly set point is reached, high feed rate can lead to over shooting – 5 is a good starting point • Press ENTER to modify setting • Use UP & DOWN arrows to adjust feed rate •...
  • Page 13 Concentration Mode – Feed Limit • Limits the amount of time that the detergent pump will run without reaching set point • Press ENTER to modify setting • Use UP & DOWN arrows to adjust feed limit in minutes and seconds •...
  • Page 14 Concentration Mode - Alarm Delay • Amount of time before detergent alarm sounds • Press ENTER to modify setting • Use UP & DOWN arrows to adjust time setting (minutes / seconds) • Press ENTER when desired setting is displayed •...
  • Page 15 Concentration Mode - Alarm Volume • Sets volume of audible detergent alarm • Press ENTER to modify setting • Use UP or DOWN arrows to adjust volume • Press ENTER when desired volume is reached • Press DOWN arrow to advance to rinse speed...
  • Page 16 Concentration Mode - Rinse Speed • Adjust rinse pump speed • Press ENTER to modify setting • Use UP & DOWN arrows to adjust rinse speed • Press ENTER when desired speed is displayed • Press DOWN arrow to advance to rinse length...
  • Page 17 Concentration Mode - Rinse Length • Rinse length should match the amount of rinse time per rack • Allows Nitro to count racks on a conveyor machine • Use UP & DOWN arrows to adjust rinse length • Press ENTER when desired length is displayed •...
  • Page 18 Concentration Mode - Sanitizer Speed • Adjust sanitizer pump speed • Press ENTER to modify setting • Use UP & DOWN arrows to adjust sanitizer speed • Press ENTER when desired speed is displayed • Press DOWN arrow to advance to company name...
  • Page 19 Concentration Mode – Detergent Control Mode • Press ENTER to modify setting • Use UP or DOWN arrows to change between probeless or concentration • Press ENTER when concentration is displayed • Press DOWN arrow to advance to machine type...
  • Page 20 Concentration Mode - Machine Type • Press ENTER to modify setting • Use UP or DOWN arrows to change between conveyor and door • Press ENTER when desired machine type is displayed • Press DOWN arrow to advance to trigger mode...
  • Page 21 Concentration Mode – Trigger Mode • Press ENTER to modify setting • Use UP or DOWN arrows to change between Detergent/Rinse, Detergent Only or Rinse Only • Press ENTER when desired mode is displayed • Press DOWN arrow to advance to concentration set point...
  • Page 22 Concentration Mode – Company Name • Up to 16 characters • Press ENTER to modify setting • Use LEFT & RIGHT arrows to move between characters • Use UP & DOWN arrows to at adjust each character • Press ENTER when desired name is displayed •...
  • Page 23 Concentration Mode - Rack Count • Displays number of rack counts registered • Rack counts are generated by rinse length in conveyor mode or machine operations in door mode • Press DOWN arrow to advance to enter code...
  • Page 24 Concentration Mode - Enter New Code • Press ENTER to change code or • Press UP or DOWN arrows to move to other screens or • Press EXIT to leave programming mode...
  • Page 25 Concentration Mode - Enter Code • Access Code gains access to system programming setup. • Use SANITIZER button to move cursor left and EXIT button to move cursor right • Use UP & DOWN arrows to change digit in each position •...
  • Page 26 Concentration Mode - Accept Program Code • Press EXIT to accept new access code • Press any other button to reject new access code...
  • Page 27 • Press EXIT to leave programming mode or use UP & DOWN arrows to navigate to other screens to make changes...
  • Page 28 Enter Code – Probeless Mode • Enter code to gain access • Use SANITIZER button to move cursor left and EXIT button to move cursor right • Use UP & DOWN arrows to change digit in each position • Press ENTER when access code is displayed...
  • Page 29 Probeless Mode - Recharge Time • The “top off” or subsequent detergent feeds after initial new tank detergent feed • Press ENTER to modify setting • Use UP & DOWN arrows to adjust time setting (minutes & seconds) • Press ENTER when desired setting is displayed •...
  • Page 30 Probeless Mode - Dwell Time • For conveyor machine type only • Amount of time between initial and subsequent recharges • Press ENTER to modify setting • Use UP & DOWN arrows to adjust time setting (minutes / seconds) • Press ENTER when desired setting is displayed •...
  • Page 31 Probeless Mode -Dead Cycles • For door machine type only • The number of machine operations that will not get a subsequent recharge • Press ENTER to modify setting • Use UP & DOWN arrows to adjust number of cycles between recharges •...
  • Page 32 Probeless Mode -Initial Charge • The time the detergent will dispenser for a new tank of water • Press ENTER to modify setting • Use UP & DOWN arrows to adjust time setting (minutes / seconds) • Press ENTER when desired setting is displayed •...
  • Page 33 Probeless Mode - Charge Clock • For conveyor machine type only • Defines time between trigger signals for an initial charge • Press ENTER to modify setting • Use UP & DOWN arrows to adjust time setting (hours / minutes) •...
  • Page 34 Probeless Mode –Charge Activate • For door machine type only • Allows the dispenser to recognize machine fill versus rinse cycle • Trigger mode must be set to “Rinse Only” • Press ENTER to modify setting • Use UP & DOWN arrows to adjust time setting •...
  • Page 35 Probeless Mode - Rinse Speed • Press ENTER to modify setting • Use UP & DOWN arrows to adjust rinse speed • Press ENTER when desired speed is displayed • Press DOWN arrow to advance to rinse length (conveyor mode) or sanitizer speed (door mode)
  • Page 36 • For conveyor machine type only • Rinse length should match the amount of rinse time per rack • Allows Nitro to count racks on a conveyor machine • Use UP & DOWN arrows to adjust rinse length • Press ENTER when desired length is displayed •...
  • Page 37 Probeless Mode - Sanitizer Speed • Press ENTER to modify setting • Use UP & DOWN arrows to adjust sanitizer speed • Press ENTER when desired speed is displayed • Press DOWN arrow to advance to company name...
  • Page 38 Probeless Mode – Detergent Control Mode • Press ENTER to modify setting • Use UP or DOWN arrows to change between probeless or concentration • Press ENTER when desired mode is displayed • Press DOWN arrow to advance to machine type...
  • Page 39 Probeless Mode - Machine Type • Press ENTER to modify setting • Use UP or DOWN arrows to change between conveyor and door • Press ENTER when desired machine type is displayed • Press DOWN arrow to advance to trigger mode...
  • Page 40 Probeless Mode – Trigger Mode • Press ENTER to modify setting • Use UP or DOWN arrows to change between Detergent/Rinse, Detergent Only or Rinse Only • Press ENTER when desired mode is displayed • Press DOWN arrow to advance to recharge time...
  • Page 41 Probeless Mode – Company Name • Can be up to 16 characters • Press ENTER to modify setting • Use LEFT & RIGHT arrows to move between characters • Use UP & DOWN arrows to at adjust each character • Press ENTER when desired name is displayed •...
  • Page 42 Probeless Mode - Rack Count • Displays number of rack counts registered • Rack counts are generated by rinse length in conveyor mode or machine operations in door mode • Press DOWN arrow to advance to enter code...
  • Page 43 Probeless Mode - Enter New Code • Press ENTER to change code or • Press UP or DOWN arrows to move to other screens or • Press EXIT to leave programming mode...
  • Page 44 Probeless Mode - Enter Code • Access Code gains access to system programming setup. • Use SANITIZER button to move cursor left and EXIT button to move cursor right • Use UP & DOWN arrows to change digit in each position •...
  • Page 45 Probeless Mode - Accept Program Code • Press EXIT to accept new access code • Press any other button to reject new access code...
  • Page 46 • Press EXIT to leave programming mode or use UP & DOWN arrows to navigate to other screens to make changes...
