Packing List

Part Number
904.8T
80.55
81.312.1
25.68.20
C.12B
100.12.SV1
58.5
904.8KY
81.16.1
I1022

Operational Requirements

Main Power
Motor/Solenoid Rating
Enclosure Material
Environmental Temp.
Product Weight
The integrity and operational characteristics of this unit are not guaranteed outside the above
mentioned parameters. Use of this unit outside of these parameters nullifies warranty.
This unit will only accept up to 265 VAC. It cannot accept over this amount. If more than 265
VAC is supplied to this unit, critical damage will occur.

Overall Size

I-1022
Rev. B-36992 6/17/11
X = included in kit
Description
RINSE CHECK VALVE ¼" OD TEFLON BALL
LIQUID DETERGENT FEED INJECTION ELBOW
SPLIT PICK UP TUBE STIFFENER
20 FT ¼" OD LDPE TUBING
CONDUCTIVITY CELL
VINYL RINSE TUBING
OVERFLOW ELBOW KIT – DRY DETERGENT
RINSE CHECK VALVE ¼" COMP X 1/8" NPT KYNAR
TIE WRAPS 8" LONG
INSTRUCTION SHEET
For indoor use only
100-265VAC 50/60 Hz 1.5A
0-40°C
4.08 KG
X X
X
1 2
X X
X X
X X
X
5 5
X X
24VDC
ABS
32-104°F
9.0 LB
Page 2 of 8
X X
X
2 3
X X
X X
X X
X
X X
8 8
X X
