DEMA Nitro Plus Manual page 11

3 Roller Fixed – Roller Block
(Rinse/Sanitizer Pump)
Spring Loaded - Roller Block
Item
No. DEMA Kit No.
1 81.173.12
2 41.40.2
3 81.174.1
4 81.128.2
5 81.172.1
6 25.85.2
7 80.59.60MK.1 60 RPM Detergent Pump Motor Kit
8 81.47.1
9 81.118.15
10 25.85.19
Item
No. DEMA Kit No.
1 81.173.7
2 41.40.2
3 81.174.1
4 81.128.2
5 81.172.2
6 25.85.2
7 80.59.15MK.1 15 RPM Rinse/Sanitizer Pump Motor Kit
8 81.47.1
9 81.118.16
10 25.85.19
I-1205
Rev. B-43816
(Detergent Pump)
Detergent Pump Parts
Detergent Pump Assy w/60 RPM Motor (no enclosure)
#6‐32 x 1/2" Stainless Steel Screw
Blue Pump Cover
Blue Pump Base
Spring Loaded Roller Block Assembly
#10‐32 x 1/2" Stainless Steel Screw
1/2" Hole Plug (not shown, plugs unused 1/2" holes on back of enclosures)
Detergent Pump Kit ‐ Blue Pump Parts & Roller Block Assy, no motor
#10‐32 x 2" Stainless Steel Screw
Rinse/Sanitizer Pump Parts
Rinse/Sani Pump Assy w/15 RPM Motor (no enclosure)
#6‐32 x 1/2" Stainless Steel Screw
Blue Pump Cover
Blue Pump Base
3 Roller Fixed ‐ Roller Block Assembly
#10‐32 x 1/2" Stainless Steel Screw
1/2" Hole Plug (not shown, plugs unused 1/2" holes on back of enclosures)
Rinse/Sani Pump Kit ‐ Blue Pump Parts & Roller Block Assy, no motor
#10‐32 x 2" Stainless Steel Screw
3/23/2018
Squeeze Tube
(See Common Replacement Parts on page 12)
Description
Description
Page 11 of 13
