Summary of Contents for SOMFY CONNEXOON

  • Page 2 Thank you for choosing Need more information? Need assistance? www.somfy.co.uk...
  • Page 3 Connexoon Window RTS app is a new way to control your motorised blinds and curtains. Enjoy the experience of controling your RTS motorised solutions from your smartphone, and enjoy the many benefits they provide: light management, privacy and convenience. Connexoon Window RTS Compatible with RTS motorised blinds and curtains.
  • Page 4 STAY IN CONTROL Connexoon Window RTS, is a user friendly interface with 3 key functions CENTRALISATION Open and close your all your equipment with a simple click. TIMER Schedule the opening and closing of your equipment at the time and date of your choice, and simulate your presence.
  • Page 5 Connexoon window RTS is compatible with: interior interior roller curtains venetian blind blind roman blind zebra blind cellular blind light plug Philips Hue 5/47...
  • Page 6 CONTENTS Connexoon The Pack • The Connexoon unit • Installing Connexoon Registering products in the Connexoon unit (prog-prog) • Activating the Connexoon unit • Downloading the Connexoon application • Customising previously saved RTS products in the application from the •...
  • Page 7 < Back to Contents 7/47...
  • Page 8 < Back to Contents A. THE PACK The pack contains 8/47...
  • Page 9 10 seconds The PROG button enables your connection motorised Somfy products to be registered in your Connexoon The LAN socket enables the Connexoon unit RTS unit, without an internet to be connected to the internet unit via an connection. Connexoon (prog-prog) ethernet cable.
  • Page 10 < Back to Contents INSTALLATION Registering RTS Activate the ownload the Connexoon Customise Enjoy! products in the Connexoon unit. application the registered Connexoon unit products (prog-prog) 10/47...
  • Page 11 SEL button. The LED on the side of the unit indicates which channel you are on. < 5s Press the PROG (PRG) button on the Connexoon unit for 0.5 of a second. Once the product has been saved it will then perform an up and down movement.
  • Page 12 < Back to Contents A. REGISTER RTS products in the Connexoon unit (prog-prog) To test that products have been correctly registered in your Connexoon unit: < 5s Select the channel on which you wish to carry out the register test Press the PROG and SEL buttons simultaneously for 0.5...
  • Page 13 < Back to Contents B. ACTIVATING THE CONNEXOON UNIT Connect to somfy-connect.com www.somfy-connect.com Step 1 Step 2 Step 3 Step 4 Check that your Connexoon unit Enter your Choose your device Enter your PIN code and your internet box are correctly information connected, via the ethernet cable.
  • Page 14 < Back to Contents B. ACTIVATE THE CONNEXOON UNIT Connexoon Window activation steps Step 5 Step 6 Step 7 Step 8 Login and password Enter your Summary Confirmation personal information 14/47...
  • Page 15 < Back to Contents B. ACTIVATING THE CONNEXOON UNIT Receipt of the confirmation email Confirmation email 15/47...
  • Page 16 C. DOWNLOADING THE CONNEXOON < Back to Contents WINDOW RTS APPLICATION Download the smartphone application Connexoon Window available for IOS and Android. 16/47...
  • Page 17 < Back to Contents C. DOWNLOADING THE RTS CONNEXOON WINDOW APPLICATION Enter the email address and password that you Set your personal identity. have defined during the activation of your RTS Your identity enables you to find out what actions have been performed Connexoon window unit from your Smartphone.
  • Page 18 < Back to Contents D. FIRST USE: CUSTOMISING REGISTERED EQUIPMENT RAPIDLY (VIA PRO-PROG) Click "identify" to display the Select the icon for your To complete your installation, Name your equipment in the equipment concerned. equipment from the 20 available you need to customise the grey field, then press "save".
  • Page 19 < Back to Contents USE CONNEXOON WINDOW RTS 19/47...
  • Page 20 Description < Back to Contents A. THE INTERFACE Menu Weather Home page: Modes Scenarios Prog. timer Need assistance? Mode editor Pre-set and customised modes Products registered in Connexoon 20/47...
  • Page 21 Creation < Back to Contents B. CONTROL MY PRODUCTS CELLULAR SHADE VENETIAN BLIND close back You can control your Adjust the position of your equipment by Equipment with adjustable blinds, curtains, lighting, within the grey frame pressing the arrows or the "my" button. slats.
  • Page 22 Description < Back to Contents C. SIMPLIFY YOUR LIFE: SCENARIOS Connexoon Window RTS offers 4 scenarios - At home - Away - Sun protection - Privacy Customise any of these scenarios by selecting the actions that you wish to perform (open or close your blinds, your curtains, switch your lights on or off, etc.) and by activating or deactivating your programmes.
  • Page 23 Creation < Back to Contents C. SIMPLIFY YOUR LIFE: SCENARIOS For each scenario: Select the scenario that you Press to programme want to customise: a scenario • Select the equipment that you want to operate, then - At home confirm the order in which you wish to allocate it •...
  • Page 24 Description < Back to Contents D. SIMPLIFY YOUR LIFE: AMBIANCES This function enables you to save your favourite ambiances and change them in one click, as often as you want. E.g.: My remote ambiance closes the lounge curtains,switches off the light and lights up the strip of LEDs behind the television.
  • Page 25 D. SIMPLIFY YOUR LIFE: AMBIANCES After pressing the button to edit your ambiances, select the one you want to amend by pressing To customise your ambiance, Connexoon enables you to take a photo of your setup. Press icon to capture the setup.
  • Page 26 Creation D. SIMPLIFY YOUR LIFE: AMBIANCES To customise your ambiance using an icon, press To customise your ambiance with a Confirm your ambiance to save it photo/image from your photo gallery, press To take a photo again, press Name your ambiance Select the equipment that you want to include in your ambiance Press the equipment...
  • Page 27 Description < Back to Contents E. TIMER Click on the icon to access the timer menu. The timer enables actions to be scheduled on my equipment at a particular time. 27/47...
  • Page 28 Creation < Back to Contents E. TIMER Press to access the "Timer" menu, then to configure this function Activate or deactivate your timer Press to add a new timer programme 28/47...
  • Page 29 Creation < Back to Contents E. TIMER Name your timer programme (e.g.: morning, wake-up, sunlight, evening, bedtime, etc.) you can define a timer programme choose to use the "sunset" or "sunrise" functions. You can adjust this setting by using the lower cursor. Select the days on which you want your timer to activate.
  • Page 30 < Back to Contents MANAGE MY INSTALLATION 30/47...
  • Page 31 Description < Back to Contents MANAGE MY INSTALLATION By clicking on menu , you can access several configuration and management functions for your Connexoon Window application: • the control panel • your messaging system • the application settings • your account •...
  • Page 32 Description < Back to Contents A. CONTROL PANEL This menu enables you to display the history of the actions taken on all your connected equipment. • The red dot indicates that command has been intentionally stopped. Press the icon for more information. 32/47...
  • Page 33 Description < Back to Contents B. MESSAGING SYSTEM You will find all the information on forthcoming updates and new features in the Connexoon messaging system. 33/47...
  • Page 34 Description < Back to Contents C. SETTINGS Geolocalise your home for local weather information Activate/Deactivate the weather display on the home page Activate/Deactivate the help button display on the right of all the screens 34/47...
  • Page 35 Description < Back to Contents D. MY ACCOUNT In this tab, you will find the information that you have entered when activating Connexoon. Press the arrow to access the modification page for your identity. USER NAME Nicolas save 35/47...
  • Page 36 You or your installer can fill out this tab. This will enable you to contact him directly if you have any questions. You can also contact Somfy customer services (technical.uk@somfy.com). Direct link to make a call Direct link to send an email...
  • Page 37 Description < Back to Contents F. LEGAL NOTICES The "legal notices" menu enables you to find all of the legal notices and precautions for use. 37/47 37/47...
  • Page 38 < Back to Contents ADVANCED FUNCTIONS OF THE INSTALLATION 38/47...
  • Page 39 Description < Back to Contents ADVANCED INSTALLATION FUNCTIONS In this menu, you can: • Register new RTS equipment compatible with your Connexoon. • Remove equipment registered on your Connexoon To access these functions press 39/47...
  • Page 40 Creation < Back to Contents A. RENAMING YOUR PRODUCTS IN THE APPLICATION Press on the pencil Press the configuration tab Press menu to the right of the equipment to change its name 40/47 40/47...
  • Page 41 Creation < Back to Contents A. RENAMING YOUR PRODUCTS IN THE APPLICATION You can rename your product by editing the "name" field in the grey rectangle positioned at the top of the screen. To check that it is the right product to be renamed, press "identiy". The product will then make an up and down movement or flash.
  • Page 42 Creation < Back to Contents B. REGISTER RTS EQUIPMENT ON YOUR CONNEXOON Press the configuration tab Press Press the menu 42/47...
  • Page 43 Select the icon representing the product that you to add to the installation: RTS motors/ wall control unit or remote control. Ensure want to register on the Connexoon unit. actuators or Philips Hue lights, then that the control only actuates the product confirm by pressing being added.
  • Page 44 Creation < Back to Contents B. REGISTER RTS EQUIPMENT ON YOUR CONNEXOON Press the PROG button of the handset Press OK if your product has moved, or Check the product has been successfully of the product to be added until "start again"...
  • Page 45 Creation < Back to Contents B. REGISTER RTS EQUIPMENT ON YOUR CONNEXOON Name your product, then press OK The product then appears on your list. 45/47...
  • Page 46 Creation < Back to Contents C. REMOVING RTS PRODUCTS VIA THE APPLICATION Press the PROG button of the control Press Ensure that the control only actuates the product actuating the product to be removed for about to be removed. Test the product by controlling it from 3 seconds, until it makes an up and down the wall switch or handset.
  • Page 47 Creation < Back to Contents C. REMOVING RTS PRODUCTS VIA THE APPLICATION Test that removal has been successful by Press OK to close the procedure. Press OK if your product has not moved, or "start pressing "test". again" if it has not. If removal has successfully taken place, the product will not respond.
