SelectBlinds Inside Mount Spring Roller Instructions page 2

Roller Shade Installation Instructions
Continuous Loop Clutch System with Spring Loaded End Plug
Please Follow These Installation Instructions
The universal brackets can be
1
mounted in three different ways
Bracket Part # F5
Extension Bracket Part # F6
2 Installing the roller shade
a. Place spring loaded end plug side into the bracket and compress until firmly inserted into the bracket
A
B
C
Spring loaded end plug
b. Place other end of the shade into position on the bracket and adust until the spring loaded end plug side
CLICKS in place. Once you hear a CLICK, the shade is locked in place
b-1
3 For OB Mounts
a. Slide decorative end caps
over the brackets
Covers are not available
for the F7 Brackets (2 ¼" x 3 ¼")
a
2
a
2
Mounting Outside Frame Mounting Inside Frame
a
1
a-1 a
1
1
b-2
"CLICK"
Ceiling Mount
a-2
1
2
To unlock the shade,
slide plastic stop to
release and pull shade
away from bracket
"CLICK"
With safety in mind we have
provided you with a P-Clip to
keep the beaded chain out of
the reach of small children.
Mount the P-Clip to the side of
the window frame for inside
mount, or the frame or wall for
outside mount. Do not apply
tension to the chain control.
The chain should run through
the P-clip freely.
09/09
