5.0 SPECIFICATIONS
Table 15 Liebert NXL UPS specifications
Model Size
Input Parameters
Permissible Input Frequency Range, Hz
Reflected Input THDi, Nominal Voltage, Full Load, %
Battery & DC Parameters
Minimum End of Discharge Voltage, VDC
DC Ripple Voltage in Float & Const V Ch. Mode, %
Temperature Compensated Battery Charging
Output Parameters
Output Voltage Regulation (100% Unb. Load)
Output Frequency Regulation, %
Output THDv Linear Load at Nominal Voltage, %
Output THDv at Nominal Voltage
Including a 100kVA Non Linear Load per EN 62040-3, %
Capacity to Handle High Crest Factor Load
Capacity to handle Step Load, %
Step Load Transient Recovery (linear loads), %
Unbalance Loads Current Capacity
Capacity to Handle Leading PF Load
®
Vertiv | Liebert NXL
Input Voltage to Rectifier, VAC
Input Voltage to Bypass, VAC
Input Voltage Range, VAC
Input Frequency, Hz
Power Walk-In, sec
Bypass Neutral Current
Battery Type VRLA (Valve Regulated Lead Acid) or FLA (Flooded Lead Acid)
Nominal Battery Bus, VDC
Battery Float Voltage, VDC
Inverter Type
Output Power, kW
Output Voltage, VAC
Output Voltage Regulation, %
Output Frequency, Hz
at 0.95 Lead
at 0.9 Lead
Voltage Displacement, ° el
Compliance to FCC Class-A
Overload Conditions, % FL
™
625-1100kVA Installation Manual |
625kVA 800kVA
480V 3-phase, 3-wire
575V 3-phase, 3-wire
600V 3-phase, 3-wire
480V 3-phase, 3-wire or 4-wire
575V 3-phase, 3-wire or 4-wire
600V 3-phase, 3-wire or 4-wire
+10% to -30%
55 to 65
<5%
1 to 30 (selectable) in 1 sec. Increment
up to 1.7 times full-phase current
480V
540V
384V (for VRLA / Flooded Lead Acid)
<1 (RMS value) < 3,4% Vpp
Optional (with temperature probe)
IGBT-based Sine-Sine PWM Controlled
625
480V 3-ph, 3-wire or 4-wire
575V 3-ph, 3-wire or 4-wire
600V 3-ph, 3-wire or 4-wire
< 1% (3-phase RMS average)
< 2% (3-phase RMS average)
± 0.1
<2%
2.5% (max)
0-100 or 100-0
Within 5% peak-to-peak in one line cycle.
100% of nominal phase current
Subject to Max. kW rating
Subject to 12.5% kW derate or same Rating and 10°C Temp.
Derate
120° ±1° el (with 100% unbalanced load)
Standard
See Figures 66, 67 and 68
Specifications
1100kVA
60
800 1100
60
3:1
83
