5. LinkBoxMB. Configuration & monitoring.
How to install and use the LinkBoxMB is explained in its Manual. It can be found in the
installation folder (if the Software is already installed) or it can be downloaded from the link
that can be found in the installation sheet supplied with the IntesisBox.
In this section only the specific project configuration for IntesisBox Modbus Server –
Modbus RTU Master is going to be explained.
The External Protocol in this IntesisBox is Modbus RTU.
5.1 Project configuration
To configure the integration connection parameters, and the points list, click on Config in
the Button Bar. The Modbus Configuration window will be opened. For integrations with a
large number of points an alternative CSV based configuration method is explained in in the
LinkBoxMB Manual.
5.1.1 Connection configuration
In this tab both the parameters for Modbus TCP and Modbus RTU are configured.
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox
is a registered trademark of Intesis Software SL
Figure 5.1 Connection tab
User's Manual r1 eng
