Analog Devices SHARC Audio EZ-Extender Manual page 73

A
R608 R607
2.43K 2.67K
0402 0402
DAC23P
1
R609 R611
2
2.43K 2.67K
0402 0402
DAC23N
R578 R602
2.43K 2.67K
0402 0402
DAC24P
3
R579 R600
2.43K 2.67K
0402 0402
DAC24N
4
A
B
C306
680PF
0402
U51
5
7
6
AD8652ARZ
R606
SOIC_N8
750.0
0402
R604
6.81K
0603
C304 R605
620PF 4.99K
0402 0603
AD1939C_VREF
R584
C305 4.99K
22UF 0603
ELEC_5MM
R581
C294
620PF 4.99K
0402 0603
R587
6.81K
R577 0603
750.0
0402
U51
2
1
3
AD8652ARZ
SOIC_N8
C307
680PF
0402
C302
680PF
0402
U52
5
7
6
AD8652ARZ
R610
SOIC_N8
750.0
0402
R588
6.81K
0603
C295 R582
620PF 4.99K
0402 0603
AD1939C_VREF
R585
C296 4.99K
22UF 0603
ELEC_5MM
C300 R598
620PF 4.99K
0402 0603
R597
6.81K
R580 0603
750.0
0402
U52
2
1
3
AD8652ARZ
SOIC_N8
C301
680PF
0402
B
CT121
R593
22UF
100.0
ELEC_4MM
0402
OUT23P
R603
49.9K
0603
CT118
R583
U53 22UF
3 100.0
ELEC_4MM
0402
1 OUT12_SE_L
2
AD8652ARZ
R599
SOIC_N8
100K
0402
R589
4.99K
0603
CT120
R590
22UF
100.0
ELEC_4MM
0402
OUT23N
R595
49.9K
0603
CT122
R592
22UF
100.0
ELEC_4MM
0402
OUT24P
R596
49.9K
0603
CT119
R594
U53 22UF
5 100.0
ELEC_4MM
0402
7 OUT12_SE_R
6
AD8652ARZ
R601
SOIC_N8
100K
0402
R586
4.99K
0603
CT123
R591
22UF
100.0
ELEC_4MM
0402
OUT24N
R576
49.9K
0603
C
5V 5V 5V
C299 C298 C297
0.1UF 0.1UF 0.1UF
0402 0402 0402
Top Left (White)
J7
CON_RCA_6B
9
7
Top Right (Red)
J7
CON_RCA_6B
10
8
ANALOG
DEVICES
SHARC AUDIO EZ-EXTENDER
Title
OUT12 VIA AD1939C
Size Board No.
C
Date 6-9-2009_15:31
C
D
OUT12
1
2
AD1939C_VREF
C303
0.1UF
0402
3
20 Cotton Road
Nashua, NH 03063
4
PH: 1-800-ANALOGD
Rev
A0223-2008
0.1
Sheet 23 of 24
D
