ESP-9V Battery-Operated Controller
User Manual - Table of Contents
Controls and Indicators .................... 2
Operating Modes ..................................... 2
Introduction ..................................... 3
Operation and Setup ........................ 3
Set Date .................................................... 3
Set Time .................................................... 3
Set Zone Watering Days .......................... 4
Custom Days ..............................................................4
Watering Day Options ............................................4
Cyclic Days .............................................................4
Odd Days ................................................................4
Even Days ...............................................................4
Set Zone Watering Run Times ................. 5
Auto Run .................................................. 5
1
ESP-9V Battery-Operated Controller
Rain+Birdt
......... 3
TM
Off ............................................................. 5
Manual Watering ..................................... 5
One-touch Manual Start ......................... 5
Seasonal Adjust ....................................... 6
Special Features ............................... 6
Delay Watering ........................................ 6
Contractor Default Save.......................... 6
Contractor Default Restore ..................... 6
Factory Default Restore .......................... 6
Rain Sensor Bypass ................................. 6
Installation ....................................... 7
Valve Wiring ............................................. 7
Batteries ................................................... 7
Replacing Batteries ..................................................7
Optional Rain Sensor .............................. 7
Troubleshooting ............................... 8
