JessEm Tool Mast-R-Fence Operating Instructions And Parts Manual page 10

Installing Sub-Fence Offset Track Fence Offset Track
Fence Model 04010 and Model 04100 are both Fence Model 04010 and Model 04100 are both
equipped with sub-fence offset tracks. These t tracks. These
offset tracks are designed to be installed two offset tracks are designed to be installed two
allow for a 1/32" or 1/16" offset of the sub allow for a 1/32" or 1/16" offset of the sub-fence.
Notice the female profile of the extrusion, you will female profile of the extrusion, you will
see that one side of the profile is deeper than the see that one side of the profile is deeper than the
other side. The small side is 1/32" and the other side. The small side is 1/32" and the
deeper side is 1/16".
Figure 18
The sub-fence offset tracks are located on the fence offset tracks are located on the
backside of the fence in a specially designed backside of the fence in a specially designed
storage location (Fig. 17).
Remove one side of the fence sub-fences by fences by
unscrewing the black knob and removing the unscrewing the black knob and removing the
sub-fence bolts (Fig. 18). Once the sub . Once the sub-fence
has been removed, notice the end of the fence has been removed, notice the end of the fence
extrusion. The fence extrusion is designed with extrusion. The fence extrusion is designed with
Figure 19
mating male profiles designed to accept the ting male profiles designed to accept the
offset tracks (Fig. 19). Side the offset tracks ). Side the offset tracks
onto the fence extrusion take care that you install onto the fence extrusion take care that you install
both offsets on the same side (Fig. 20 ffsets on the same side (Fig. 20). Both
offsets should always be installed on the same offsets should always be installed on the same
side to insure the sub-fence is offset the same fence is offset the same
distance at the top and bottom of the sub distance at the top and bottom of the sub-fence.
Once the offset tracks are securely in place, Once the offset tracks are securely in place,
reinstall the sub-fence with the sub- -fence bolt,
Figure 20
washer , and black locking knob.
