  • Page 1 Bulletin HY30-5503-M1/UK Service Manual Series F11 Effective: August, 2015 Supersedes: November, 2011...
  • Page 2: Table Of Contents

    The products described herein, including without limitation, product features, specifications, designs, availability and pricing, are subject to change by Parker Hannifin Corporation and its subsidiaries at any time without notice. Offer of Sale Please contact your Parker representation for a detailed ”Offer of Sale”.
  • Page 3: General Information

    Our unique timing gear design synchronizes - F11-5, -6, -10, -12, -14 and -19 with shaft and cylinder barrel, making the F11 CETOP mounting flange and shaft end. very tolerant to high ’G’ forces and torsional - F11-6, -10, -12 and -14 with ISO flange vibrations.
  • Page 4: Specification And Operating Temperature

    Note: The temperature should be measured at the utilized drain port. Continuous operation may require case flushing in order to meet the viscosity and temperature limitations. For further information we refer to: Catalogue HY30-8249/UK Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
  • Page 5: Design

    (4) so that the cylinder barrel always rotates at the same speed as the shaft (3). The shaft is supported by two heavy duty tapered roller bearings (7). Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
  • Page 6: Operational Check

    Also, check for lea- kage at the shaft seal and between the bearing and barrel housings. Drain Flow Series Normal Normal (l/min) (gpm, US) (l/min) (gpm, US) F11-5 0.05 0.26 F11-6 0.05 0.26 F11-10 0.08 F11-12 0.08 F11-14 0.08...
  • Page 7: Assembly

    Not to tight and no backlash. 3. Place the distance ring on the big 6. Place the lock washer(s) on to the tapered roller bearing. shaft. Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
  • Page 8 9. Assemble the valve plate. Make sure the slot is in correct position and ring to the barrel housing. Lubricate the valve plate is located as shown in them with oil before assembly. picture. Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
  • Page 9 14. Assemble the pistons. Lubricate the ball sockets before assembly. housing. 15. Assemble the shaft package with 18. Lubricate the sealing surface on pistons in to the cylinder barrel. the shaft before assembling the shaft seal. Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
  • Page 10 21. Carefully tap down shaft seal and 24. Tap down the flat key and turn the support ring. shaft at least one revolution. Make sure the back-lash of the gears are correct (see page 12). Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
  • Page 11: Barrel Retaining Ring

    5. Opening barrel retaining ring Connection ports A and B Opening barrel retaining ring 3. Assemble the cylinder barrel as 5. Assemble the cylinder barrel as shown in picture. shown in picture. Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
  • Page 12: Torque And Gear Backlash

    F11-6 48±8 35±6 F11-10 48±8 35±6 F11-12 48±8 35±6 F11-14 48±8 35±6 F11-19 48±8 35±6 Gear Backlash F11-5 through F11-19 0.10 - 0.25 mm Frame size "R" mm F11-5 25.0 F11-6 31.3 F11-10 31.3 F11-12 31.3 F11-14 31.3 F11-19 37.5...
  • Page 13: Split View

    Service Manual Bulletin HY30-5503-M1/UK Series F11 Split View Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
  • Page 14 Ring Gear Kuggkrans Tap Rol Bearing Koniskt Rullager Spacer Ring Distansring Tap Rol Bearing Koniskt Rullager Lock Washer Låsbricka Round Nut Rundmutter Guide Spacer Distanshylsa Shim Schims Hexagon Screw Insexskruv Hexagon Screw Insexskruv Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
  • Page 15: Parts Specification

    Item Title Benämning Check Valve Cone Backventilkägla Compression Spring Tryckfjäder Hex Socket Plug Sexkantpropp O-ring O-ring Adapter Nipple Adapternippel O-ring O-ring Hexagon Plug assy Insexpropp kpl Expanding Plug Expanderplugg Grease Fitting Smörjnippel Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
  • Page 16: Valve Plates

    From the front, when installed, Bi-directional, motor operation, high pressure they looks the same as the M Right hand rotation, motor operation, internal drain valve plate. Left hand rotation, motor operation, internal drain Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
