- Page 1 Bulletin HY30-8251/UK Application Guide Saw Motor Series F11iP Effective: June 10, 2009 Supersedes: January 16, 2009 LogMax_GM_650.ai Leif A./07-04-09...
- Page 2 The user must analyze all aspects of the application, follow applicable industry standards, and follow the information concerning the product in the current product catalog and in any other materials provided from Parker or its subsidiaries or authorized distributors.
- Page 3 Application Guide Introduction Parker Hannifin offers an extensive range of compo- Parker Hannifin holds a leading position when it comes nents suitable for forestry machines and will assist with to product and application knowledge, dedicated to an optimal technical solution to obtain the most cost- serve the forestry machine market.
- Page 4 Shaft torque (theor.) F11-19 Please note: Displacement [cm 19.0 at 100 bar [Nm] 30.2 - Parker Hannifin will assign a Pressure (at the motor) [bar] Mass moment of inertia specific model number to a max intermittent (x10 ) [kg m ] 0.88x10...
- Page 5 - The connected spool valve functions, '2' and '3', control during the entire cutting cycle. the speed of the motor as well as the saw bar speed. - The pressure reducing valve, '1', reduces the pressure to the saw bar cylinder. Parker Hannifin Pump and Motor Division Trollhättan, Sweden...
- Page 6 "; min 14 deep) Chain tensioning; port R Return port B (S and R are pipe thread, (pipe thread; ISO 228-G "; min 14 deep) ISO 228-G "; min 9 deep) Parker Hannifin Saw_motor_ports_L.H.ai Pump and Motor Division Trollhättan, Sweden Leif A./07-05-11...
- Page 7 "; min 14 deep) Saw bar feed (piston side); port E (pipe thread;ISO 228-G "; min 14 deep) Return port A (pipe thread; ISO 228-G "; min 14 deep) Parker Hannifin Saw_motor_ports_R.H.ai Pump and Motor Division Leif A./07-05-11 Trollhättan, Sweden...
- Page 8 Tel: +351 22 999 7360 Tel: +358 (0)20 753 2500 parker.portugal@parker.com parker.finland@parker.com © 2009 Parker Hannifin Corporation. All rights reserved. Bulletin HY30-8251/UK. PDF 06/2009 European Product Information Centre Free phone: 00 800 27 27 5374 (from AT, BE, CH, CZ, DE, DK, EE, ES, FI, FR, IE, IL,...
