Rice Lake 520 Installation Manual page 30

SERIAL Menu
Parameter Choices
Level 3 Submenus
BAUD 9600
19200
300
600
1200
2400
4800
BITS 8NONE
7EVEN
7ODD
TERMIN CR/LF
CR
EOLDLY 0000000
0-255
HANDSHK OFF
ON
ADDRESS 0000000
0-255
FORMAT DEFAULT 7
CUSTOM
BUS FMT
DEFAULT 8
STREAM OFF
LFT
IND
Level 3 Submenus
BAUD 9600
19200
300
600
1200
2400
4800
BITS 8NONE
7EVEN
7ODD
TERMIN CR/LF
CR
EOLDLY 0
number
HANDSHK OFF
ON
EDP Port
Baud rate. Selects the transmission speed for the EDP port.
Selects number of data bits and parity of data transmitted from the EDP port.
Termination character. Selects termination character for data sent from the EDP port.
End-of-line delay. Sets the delay period, in 0.1-second intervals, from when a formatted line is
terminated to the beginning of the next formatted serial output. Value specified must be in the
range 0-255, in tenths of a second (10 = 1 second).
Specifies whether XON/XOFF flow control characters are used.
Specifies the decimal indicator address for RS-485 connections. RS-232 communications is
disabled if an address other than zero is specified for this parameter. RS-485 addresses must be
in the range 01–255.
Specifies whether the serial port sends data using the default stream format (using either 7 or 8
weight digits), a custom stream format (configured in STRMFMT), or is streamed to a network
bus (Profibus, Remote I/O). For more specific information on CUSTOM stream format, see
Table 13-5 on page 69.
Specifies whether data is streamed from the EDP port.
LFT - Legal for Trade - streams the displayed weight
IND - streams the current A/D converted weight
Printer Port
Baud rate. Selects the transmission speed for the printer port.
Selects number of data bits and parity of data transmitted from the printer port.
Termination character. Selects termination character for data sent from the printer port.
End-of-line delay. Sets the delay period, in 0.1-second intervals, from when a formatted line is
terminated to the beginning of the next formatted serial output. Value specified must be in the
range 0-255, in tenths of a second (10 = 1 second).
Specifies whether XON/XOFF flow control characters are used.
Table 3-5. Serial Menu Parameters (Continued)
Description
Configuration 25
