Device technology

2 Device technology
2.1

Standard Power Supply, 640/320/160 mA, MDRC

2.1.1

Technical data

Supply
Outputs
Connections
Operating and display elements
Degree of protection
KNX power supplies generate and
monitor the KNX system voltage (SELV).
The bus line is decoupled from the power
supply by an integrated choke.
The voltage output is short-circuit and
overload protected.
The two-color LED indicates device
output status.
Supply voltage U
s
Power consumption
- SV/S 30.160.1.1
- SV/S 30.320.1.1
- SV/S 30.640.3.1
Power loss
- SV/S 30.160.1.1
- SV/S 30.320.1.1
- SV/S 30.640.3.1
KNX voltage output I
1
Rated voltage U
N
Minimum distance between 2 SV/S in one line
Voltage output I (SV/S 30.640.3.1 only)
2
Rated voltage U
N
Current
- SV/S 30.160.1.1
- SV/S 30.320.1.1
- SV/S 30.640.3.1 (total current I
Power failure buffering time
KNX
Mains voltage input
Tightening torque
LED status (two-colored green/red)
IP 20
Device type SV/S 30.640.3.1 has an
additional 30 V DC short-circuit and
overload protected voltage output that
can be used to power an additional bus
line (in combination with a separate
choke).
100 – 240 V AC, 50/60 Hz
(85...265 V AC)
Normal operation
6.6 W
12.5 W
24 W
Normal operation
1.8 W
2.5 W
4 W
1 line with integrated choke
30 V DC +1/-2 V, SELV
200 m (KNX bus line)
without choke
30 V DC +1/-1 V, SELV
The voltage output without choke may only be
used to power an additional bus line in
combination with a separate choke.
Rated curr.
I
N
160 mA
320 mA
and I ) 640 mA
1 2
200 ms
Bus connection terminal
Screw terminal
0.2...2.5 mm
2
0.2...4 mm
Maximum 0.6 Nm
Green: I < I
Ovl
Red: overload.
Red, flashing: short-circuit
EN 60 529
SV/S xx.xxx.x.1 | 2CDC501049D0201 Rev. A 7
Maximum
21 W
30 W
55 W
Maximum
4.4 W
6 W
9 W
Overload curr. Short-circuit curr.
I I
Ovl Sc
0.3 A 0.5 A
0.5 A 0.8 A
0.9 A 1.4 A
2
fine-strand
solid
