- Page 1 INSTALLATION INSTRUCTIONS CTS150 BY NILAN Comfort CT150 / CT200 (English) Version 2.21 - 07.02.2018...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Warnings ........................................................... Power supply ....................................................Disposal ..........................................................Ventilation system .................................................. General information Introduction ........................................................General information prior to installation ......................................Final inspection ......................................................How to set up the ventilation system ........................................Unit type ........................................................... Product description ................................................ - Page 3 Comfort CT150 / CT200 (English) BY NILAN Ducts ........................................................Unit .......................................................... Extract air ......................................................Supply air ......................................................Roof stack ....................................................... Regulation ........................................................Important information ..............................................Balancing connectors ................................................. Pressure drop diagram ..............................................Software settings User panel ........................................................Functions ......................................................Alarms ........................................................
-
Page 4: Warnings
Always disconnect mains electricity to the unit before opening the doors, e.g. for installation, inspection, cleaning and filter change. Disposal Ventilation system Nilan units mainly consist of recyclable materials. They should therefore not be disposed of with household refuse. Take them to your local recycling centre. -
Page 5: General Information Introduction
• Installation instructions/Software instructions • User manual • Wiring diagram The instructions can be downloaded from the Nilan website: http://www.nilan.dk/en-gb/frontpage/ download If you have further questions on unit installation after reading the instructions, contact your nearest Nilan distributor, who can be found on www.nilan.dk/en-gb/frontpage/download/dealers. -
Page 6: Unit Type
Unit type Product description Comfort CT150 / CT200 is a ventilation unit with heat recovery. It is useable for air volumes up to 175 / 200 m /h at 100 Pa external duct pressure. The unit extracts humid and poor quality air from the home via the bathroom, toilet, kitchen and utility room, and blows fresh air into rooms such as the lounge, bedrooms and office. -
Page 7: Dimensional Drawing
Comfort CT150 / CT200 (English) BY NILAN Dimensional drawing All dimensions are in mm. Left version: Ø 125 1040 1000 Connections: 1. Outdoor air 2. Supply air (inlet) 3. Extract air (outlet) 4. Discharge air 5. Condensate drain... - Page 8 Right version: 1040 Ø 125 1000 90,1 Connections: 1. Outdoor air 2. Supply air (inlet) 3. Extract air (outlet) 4. Discharge air 5. Condensate drain...
-
Page 9: Accessories
The Nilan water trap contains a ball which cease to prevent "false" air intake into the unit, so that condensate can run freely out of the unit. -
Page 10: Flexible Silencing
To facilitate later servicing of the unit, we recommend fitting a flexible connection between the unit and the duct system. Nilan's sound damping flexi-hose gives good sound damping both to the duct system and to roof stacks. Side mounted brackets for vertical mounting For vertical mounting of the unit a wall bracket can be purchased and attached in which the ducts can also be led and concealed. -
Page 11: Installation
A minimum free space in front of the unit of 60 cm is recommended. Comfort CT150 is a flexible unit which can be mounted horizontally, vertically or at an angle. However, it is important that the exhaust is always positioned at the bottom (see illustration below). -
Page 12: Installation Rails
Installation rails Comfort CT150 is always supplied with a set of installation rails. The rails must be mounted with a space between them of 1045 mm. The unit is then slid between them and fixed by turning up the ends of the rails. -
Page 13: Side Installation (Accessories)
It is possible to buy a mounting bracket, for mounting on the side of the unit. Comfort CT150 is prepared that the side bracket can be mounted on either the right or the left side. The ducts can be lead behind the bracket, which provides a nice installation. -
Page 14: Electrical Installation Electrical Connections
Electrical installation Electrical connections Safety ATTENTION All work must be carried out by qualified personnel and in accordance with applicable legislation and regulations. ATTENTION It is important that power is disconnected when working with the unit's electrical components. It is important to check that cables have not been damaged or trapped during connection and use. Connection points All connections are on the right side of the unit, seen from the front, if it is mounted horizontal. -
Page 15: User Panel
Comfort CT150 / CT200 (English) BY NILAN User panel CTS150 control-panel The control-panel comes standard with 4 m cable mounted with RJ11 connectors at each end. One plug is mounted in the control-panel and the second plug is mounted in the unit. -
Page 16: Electrical Connection, Unit
Electrical connection, unit Supply CAUTION Power sypply including safety switch must be installed by a certified electrician. It comes with a power cable for connection in socket. It is important for the unit to be bonded to earth. Unit Power supply 230V 50Hz max. 13A Safety switch... -
Page 17: Electrical Connection, Assessories
Comfort CT150 / CT200 (English) BY NILAN Electrical connection, assessories User select/cooker hood solution User selection of the CTS150 control, is a connector cable connected to the unit. A 10 m cable are connectet to a potential-free contact. When the contact is activated the unit change to fan level four and overrides all other functions. -
Page 18: External Electrical Preheating Element
External electrical preheating element If the unit is the non-Polar version, an external preheating element can be purchased for retro-fitting. The electric preheating element is mounted in the outdoor air duct before the unit with the necessary temperature sensor. Min. 25 cm 1x230V ~ 50 Hz max. -
Page 19: Plumbing Condensation Drain
INFO Nilan offers a water trap with a ball. The ball ensures that no air is sucked into the unit through the condensate drain if the water trap dries out. This ensures that water in the condensate tray... -
Page 20: Connections Water Trap
Connections water trap Ø20 mm Ø20 mm Ø20 mm min. 50 mm min. 112,5 mm min. 50 mm min. 170 mm Connections water trap generally Connection of Nilan water trap with ball The water trap can be turned... -
Page 21: Plumbing Connections For Accessories
Comfort CT150 / CT200 (English) BY NILAN Plumbing connections for accessories Water lock with ball (option) Connections for Nilan water lock: 1. Water lock with Ø32 mm spout 2. Reduction spout to Ø20 mm 3. Reduction piece to ¾" RG... -
Page 22: Ventilation Installation
Ventilation installation Duct system Legislation ATTENTION All work must be carried out by qualified personnel and in accordance with applicable legislation and regulations. Ducts There are two systems for transporting air round the building. Spiral tubes Spiral tubes are metal ducts which are cut to size with an angle grinder, screwed together with bends and manifolds and laid out in accordance with the working drawing. -
Page 23: Unit
Nilan offers flexible silicing, which, apart from providing a flexible connection between the unit and the duct system, also dampen the passage of sound from the unit to the duct system. -
Page 24: Regulation
Regulation Important information ATTENTION For the ventilation system to operate optimally, it is important that initial regulation is carried out correctly. We recommend having this done by experts. It is important to measure the total supply (inlet) air and extract (outlet) air. The system must have a minimum vacuum, i.e. -
Page 25: Software Settings
Comfort CT150 / CT200 (English) BY NILAN Software settings User panel Functions The CTS150 control panel provides the following functions: 1. Setting fan speeds: 0 (off) - 1 - 2 - 3 - 4 2. Green diode: On when the unit is running 3. -
Page 26: Settings
Settings Installing of PC programme Connect the PC to the unit via the USB BF connection, for this a USB AB cable is needed. The PC application can be downloaded via NilanNet in the menu item After Sales/Software. • Install the latest software "Installer PC Tool" •... - Page 27 Comfort CT150 / CT200 (English) BY NILAN 7. Click YES to allow changes to your PC 8. The PC programme will be installed 9. Click CLOSE to continue the installation 10. The USB driver will be transferred 11. Click NEXT 12.
-
Page 28: Pc-Setting Tool
PC-setting tool Explanation of symbols: • T3: Temperature sensor extract air • T4: Temperature sensor in the heat exchanger extract air • T8: Temperature sensor in outdoor air intake • RH: Humidity sensor in extract air • Inlet Fan: Inlet air •... -
Page 29: List Of Adjustable Parameters
Comfort CT150 / CT200 (English) BY NILAN List of adjustable parameters Description Interval Default settings Fan settings Fan level 0 is not adjustable Fan level 1 in/out (humidity low) [0 - 100] 23 / 25 Fan level 2 in/out (basic ventilation) - Page 31 Comfort CT150 / CT200 (English) BY NILAN...
