- Page 1 USER MANUAL CTS150 BY NILAN Comfort CT150 (English) Version 2.01 - 26.01.2017...
-
Page 2: Table Of Contents
Product description ................................................Operation and maintenance Service ..........................................................Maintenance ....................................................Water trap ......................................................Filter replacement ..................................................Illustration of filter change............................................. Illustration of pollen filter change........................................... Exchanger ....................................................... Product specifications Declaration of compliance ............................................Ecodesign specification Comfort CT150 ....................................... -
Page 3: Power Supply
Always disconnect mains electricity to the unit before opening the doors, e.g. for installation, inspection, cleaning and filter change. Disposal Ventilation system Nilan units mainly consist of recyclable materials. They should therefore not be disposed of with household refuse. Take them to your local recycling centre. -
Page 4: Quick Guide Control Panel
Quick guide Control panel Functions The CTS150 control panel provides the following functions: 1. Setting fan speeds: 0 (off) - 1 - 2 - 3 - 4 2. Green diode: On when the unit is running 3. Setting low humidity: Can be set between 15 and 45% 4. -
Page 5: Fan Speed
Comfort CT150 (English) BY NILAN Fan speed Recommended fan speed setting in relation what the installer set. The system may only be switched off, for example, in an emergency where residents are asked to go inside, close doors and windows and shut down the ventilation system. -
Page 6: General Details System Type
System type Product description Comfort CT150 is a ventilation unit with heat recovery. It is useable for air volumes up to 175 m3/h at 100 Pa external duct pressure. The unit extracts humid and poor quality air from the home via the bathroom, toilet, kitchen and utility room, and blows fresh air into rooms such as the lounge, bedrooms and office. -
Page 7: Operation And Maintenance Service
Operation and maintenance Service Maintenance Ventilation units produced by Nilan last for many years, but to get the most out of the unit while avoiding unnecessary power consumption, correct maintenance is important. The following parts require regular maintenance: • Water trap •... -
Page 8: Illustration Of Filter Change
Illustration of filter change. 1. Switch off the unit on the control panel before opening 2. Slacken the finger screws on the right and left doors to the door open 3. Remove the two filters from the unit 4. We recommend vacuuming the filter chambers to remove any dirt 5. -
Page 9: Illustration Of Pollen Filter Change
Comfort CT150 (English) BY NILAN Illustration of pollen filter change. 1. Switch off the unit on the control panel before opening 2. Slacken the finger screws on the right door to open the door 3. Remove the filter from the unit 4. -
Page 10: Exchanger
Exchanger Inspect the exchanger every 18 months for dust and dirt to ensure free passage for the air. A blocked exchanger increases electricity consumption. • Switch off the unit on the control panel before opening the front doors • Slacken the finger screws (1) on the front door and lift it off •... -
Page 11: Product Specifications
Comfort CT150 (English) BY NILAN Product specifications Declaration of compliance... -
Page 12: Ecodesign Specification Comfort Ct150
Ecodesign specification Comfort CT150 SEC* average climate - 42.7 kWh/(m2.a) SEC* cold climate - 82.1 kWh/(m2.a) SEC* warm climate - 17.5 kWh/(m2.a) SEC-Class Type Residential ventilation unit Type of drive Variable speed drive Type of heat recovery system Recuperative (counterflow heat exchanger) Thermal efficiency of heat recovery 91.9 %... - Page 13 Comfort CT150 (English) BY NILAN...
- Page 15 Comfort CT150 (English) BY NILAN...
- Page 16 United Kingdom: S L Services 25 St Leonards Road, Horsham RH13 6EH West Sussex Tlf. +44 (0) 7919 444452 stuart315@aol.com www.nilanuk.com Ireland: Nilan Ireland Ballylahive, Abbeydorney Tlf. +353 (0) 87 9798361 maurice@nilan.ie www.nilanireland.ie Nilan A/S Nilanvej 2 DK-8722 Hedensted Tlf.
