- Page 1 USER MANUAL CTS602 LIGHT BY NILAN Comfort Version 4.00 - 01.05.2020 B24_Comfort-252-302-Top_GB...
-
Page 2: Table Of Contents
TABLE OF CONTENTS General information Safety ..........................................3 Power supply ......................................3 Introduction ........................................3 Documentation ..................................... 3 Data plate ....................................... 4 Quick guide Functions in the user panel ..................................5 Main screen elements ..................................5 Main screen settings options ................................5 Warnings and alarms .................................... -
Page 3: General Information
The instructions can be downloaded from https://www.nilan.dk/en-gb/frontpage/download. If you have questions regarding installation and operation of the unit after having read the instructions, please contact your nearest Nilan dealer. A list of Nilan dealers is available on www.nilan.dk/forhandlere. ATTENTION The unit must be started up immediately after installation and connection to the duct system. -
Page 4: Data Plate
Data plate If your ventilation unit is a right-facing model, you will find Nilan's data plate at the top / front to the right. On a left-facing model the plate is placed to the left. ATTENTION When contacting Nilan with questions about the product, it is important to have the unit name and serial no. (SN) ready. -
Page 5: Quick Guide
Quick guide Functions in the user panel Main screen elements The main screen of the HMI user panel contains the settings options and the information that an operator mostly uses. 1. Shows the current room temperature in the house, measured via the extract air 2. -
Page 6: Warnings And Alarms
Warnings and alarms If the ventilation unit is faulty or an error If you press the symbol, a brief descrip- When the problem has been solved, you occurs, there will be either a warning or tion of the warning or the alarm will be can reset the warning or alarm by an alarm. -
Page 7: Service And Maintenance
General information A ventilation unit from Nilan can last for many years if it is properly serviced and maintained. Ventilation units are often hidden away, and they are therefore rarely given attention in everyday life. But just as you maintain your car, your ventilation unit will need servic- ing regularly to keep it functioning properly. -
Page 8: Illustration Of Filter Change
Illustration of filter change 1. Before opening the door, switch the unit off on the 2. The suitcase bracket at the top opens and the door is control panel under OPERATION. lifted out. 3. Remove the two filters from the unit. 4. -
Page 9: Annual Maintenance
Annual maintenance General cleaning The ventilation unit should be cleaned on the inside once a year. Dust can slip through the filters and mix with dampness from the ex- tract air. WARNING Stop the ventilation unit on the control panel and switch off the power supply for the unit before opening its front door. You may want to remove dust with a vacuum cleaner before wiping the ventilation unit inside. -
Page 10: User Settings
User settings Ventilations settings Turn off the ventilation unit If it is necessary to open the doors while servicing the ventilation unit, for instance when changing filters, the unit must be turned off. This is done under the menu Operation. When the unit is turned off, this icon appears on the main screen. -
Page 11: Show Data
Show data You can access current operational data for the ventilation unit. This will allow you to check that the unit operates satisfactorily and to identify the cause of potential alarms. >Show data > Operating state Description: Shows the operating setting in which the unit is running. >... -
Page 12: Week Program
Week program You can program the ventilation unit to run in accordance with specific settings at fixed times during the week via a week program. On the main screen in the top right side an icon will be displayed when the week program is active >... -
Page 13: Air Humidity
Air humidity The primary purpose of ventilation is to extract humidity from the house so it does not damage the building, and to achieve a good in- door climate. During long periods with sub-zero temperatures, air humidity in the house may fall to a level that is critical for the build- ing and for the indoor climate. -
Page 14: Co2 Control
Control This menu is only displayed if a CO -sensor has been installed, and the function has been chosen under Service settings. ATTENTION A CO sensor is not a standard part of all ventilation units, but may be purchased as an accessory. If the number of people using a building varies considerably, controlling ventilation through the CO level in the extract air may be a good solution. -
Page 15: Air Filter
Air filter ATTENTION It is important to change the filters regularly and when needed. Dirty filters reduce the efficiency of the ventilation unit and result in a poorer indoor climate and higher power consumption. From factory, the filter alarm has been set to signal filter replacement every 90 days. You can set the timer to fit the level of pollution in the area where the ventilation unit has been installed. -
Page 16: Temperature Control
Temperature control If you have not installed an after-heating element, use the settings to control the bypass damper. It is necessary to install an after-heating element if you want to control the supply air temperature and for it to contribute towards the heating of the dwelling. -
Page 17: Alarm List
Alarm list Comfort Alarm list The following list applies to Comfort ventilation units with the CTS602Light control. The events are divided into the following categories: Warning Operation continues, but an incident has occurred that should be kept in mind. Alarm Operation is partially or completely stopped as it is a critical fault that needs immediate attention. - Page 18 Software error Fault in the ventilation unit software Contact service. Watchdog Fault in the ventilation unit software Contact service. warning Content of Parts of the program setting have been lost. Reset alarm. database This may be due to a prolonged power cut or a changed lightning strike.
-
Page 19: Product Data
Product data Declaration of conformity... -
Page 20: Ecodesign Data Comfort 252 Top
NB! It is important to change filters regularly to sustain the performance and energy efficiency of the unit. Disassembly instructions The user manual, which can be downloaded at www.nilan.dk * Specific energy consumption AEC - annual electricity consumption 199 kWh/år (100 m... -
Page 21: Ecodesign Data Comfort 302 Top
NB! It is important to change filters regularly to sustain the performance and energy efficiency of the unit. Disassembly instructions The user manual, which can be downloaded at www.nilan.dk * Specific energy consumption AEC - annual electricity consumption 244 kWh/år (100 m... -
Page 22: Disposal
The environment - part of the solution At Nilan A/S we recognize our responsibility in minimizing the environmental impact of our products. We consider the impact on the environment in all aspects of production, operation and subsequent disposal. We recognize our responsibility in minimizing consumption of resources. - Page 24 S L Services 25 St Leonards Road, Horsham RH13 6EH West Sussex Tel: +44 (0) 79 19 44 44 52 Service@nilanuk.com www.nilanuk.com Ireland: Nilan Ireland Ballylahive, Abbeydorney Tel: +353 (0) 87 97 98 361 maurice@nilan.ie www.nilanireland.ei Nilan A/S Nilanvej 2...
