AG Neovo LOC-32 Assembly Manual

Loc series display enclosure
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Assembly Guide of
LOC-Series Display Enclosure

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LOC-32 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AG Neovo LOC-32

Summary of Contents for AG Neovo LOC-32

  • Page 1 Assembly Guide of LOC-Series Display Enclosure...

  • Page 2: Table Of Contents

    Table of Contents General information: LOC-Series Display Enclosure ............... 3 Scope of delivery ..........................3 Preparations for installation and comissioning ................4 Mounting the monitor ........................10 Assembly for freestanding outdoor enclosure 32”-55” LOC-Series ........12 Maintenance..........................13 General information on cleaning and maintenance ............. 13 Changing the filters .......................

  • Page 3: General Information: Loc-Series Display Enclosure

    1. General information: LOC-Series Display Enclosure The LOC-Series display enclosure is equipped with a sturdy metal casing and has both a ventilation and a heating system. In outdoor use, it provides protection against humidity, wetness and heat as well as vandalism and theft. The devices comply with the IP54/IP65 protection standard and can be used in a temperature range from -20 °...

  • Page 4: Preparations For Installation And Comissioning

    3. Preparations for installation and comissioning For the assembly you need the following tools: 1) Hammer drill 2) Spirit level and pencil 3) Dowels and screws to match wall structure 4) Small slotted screwdriver or phase tester 5) 10 mm jaw spanner for mounting/dismantling the monitor holder 6) 8 mm jaw spanner to fix door braces 7) Water pipe plier for screwing the cable glands 8) 4 mm Allen key wrench for mounting the supporting arms on the monitor...
  • Page 5 Wall mounting of the metal housing Starting with model series 2018, the housing is mounted directly and without wall bracket, using the hanger bolts in the accessory package. Please check if the wall structure is suitable for this type of mounting (other mounting systems are not included).
  • Page 6 Assembly Guide of LOC-Series Display Enclosure Page 6...
  • Page 7 Lay down the housing with its back on a clean and padded surface. Unlock the door with the keys. Closing direction of the lock: Right side of door: Close in clockwise and open in counter clockwise direction. Left side of door: Open in counter clockwise and close in clockwise direction.
  • Page 8 Installing the cable glands before mounting the housing Screw the base body with the lock nut as shown. Remove the standard gasket. Pass the LAN cable through. Place the slotted gasket around the LAN cable and insert it into the base body. Provide sufficient cable length to the PC.
  • Page 9 Connecting the cables Setting up the power supply system In order to connect the housing to the main supply, there is a power distribution terminal strip with 3 terminals (L: Grey, N: Blue, PE: Green/yellow) located inside of the device. Please note that the connection may only be set up by a trained professional or an electrician.

  • Page 10: Mounting The Monitor

    4. Mounting the monitor Please follow the instructions below to prevent damage to the monitor during installation: First, please look for a clean and flat surface. When unpacking, make sure not to scratch the surface of the screen and avoid pressure load on the surface. Therefore, it is important that you thoroughly scan the storage area for objects such as screws or dirt.
  • Page 11 The picture shows the inside of the housing with the monitor holder (media player provided by customer, not included!) Heater Mounting holes Mounting bracket for monitor Mounting holes Heater Tilt adjustment /distance setting: The tilt of the monitor can be adjusted by loosening the nuts.

  • Page 12: Assembly For Freestanding Outdoor Enclosure 32"-55" Loc-Series

    4.1 Assembly for freestanding outdoor enclosure 32”-55” LOC-Series The LOF-Series (stand) is an optional freestanding floor mount to the LOC-Series. Following the assembly steps for the freestanding outdoor enclosure 32"-55" LOC-Series: Take the two columns (blue) and screw them together with the backplate (red). The cables can be inserted in both columns.

  • Page 13: Maintenance

    5. Maintenance 5.1 General information on cleaning and maintenance Clean the glass at regular intervals to ensure a clear view of the display. To do this, use a soft cloth, lukewarm water and mild soap or glass cleaner. Wipe the glass with a dry soft cloth to avoid lime stains.

  • Page 14: Technical Data

    6. Technical data Product description LOC-32 LOC-43 LOC-55 Screen diagonal 81 cm (32") 109 cm (43") 140 cm (55") 114,1 x 72,9 x 20,0 cm 141,0 x 88,1 x 20,0 cm Dimensions (WxHxD) enclosure / housing 89,8 x 59,3 x 17,0 cm...
  • Page 15 Technical drawing: 32" display enclosure Assembly Guide of LOC-Series Display Enclosure Page 1...
  • Page 16 Technical drawing: 43" display enclosure 1141 210.5 570.5 Assembly Guide of LOC-Series Display Enclosure Page 1...
  • Page 17 Technical drawing: 55" display enclosure 1410 1210 Assembly Guide of LOC-Series Display Enclosure Page 1...

This manual is also suitable for:

Loc-43Loc-55
