TABLE OF CONTENTS Safety Information ------------------------------------------------------------- 1 Important Safety Instruction ------------------------------------------------- 2 Special Notice ------------------------------------------------------------------ 2 Connection ---------------------------------------------------------------------- 3 Stand Assembly Instruction ------------------------------------------------- 3 Front Panel Controls ---------------------------------------------------------- 4 Power Switch ------------------------------------------------------------------- 4 Power Indicator --------------------------------------------------------------- 4 Operate Explanation ---------------------------------------------------------- 5 OSD Menu --------------------------------------------------------------------- 5 Specification -------------------------------------------------------------------- 7 Display Mode ------------------------------------------------------------------- 8... -
Page 3: Safety Information
Safety Information CE Declaration of Conformity We declare under our responsibility that the product is in conformity with the following standards: • EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 (Safety requirement of Information Technology Equipment). • EN55032:2012 (Radio Disturbance requirement of Information Technology Equipment). • EN55024:2010 (Immunity requirement of Information Technology Equipment). •... -
Page 4: Important Safety Instruction
Important Safety Instruction 1. Read these instructions thoroughly and keep this user manual for future use. 2. Do not use the product near water. Never spill liquid of any kind of the products. Clean LED monitor when power off. Never clean it with liquid cleanness or liquefier. Better use clean wet cloth carefully. -
Page 5: Connection
Connection 1. Turn off computer and unplug power cord. 2. To connect signal cable with 15pin into VGA connector on the back of monitor, and to be sure to tighten switches on both ends of signal cable. 3. To plug PC and monitor adapter to the nearest socket. 4. -
Page 6: Front Panel Controls
Front Panel Controls Press it to open the OSD MENU, to MENU select MENU options when the OSD MENU is displayed. ◄ Hot key to select input signal Down selection button ► Hot key to adjust value Up selection button Hot key to automatically optimize AUTO positions, phase and clock when OSD... -
Page 7: Operate Explanation
Operate Explanation Your LCD has been adjusted to its optimal status before shipment. You can also adjust the image in accordance with the following allustrations and steps. ● Press the “MENU” button to start the OSD feature. ● Click the “◄” or “►” to select the function to be adjusted. ●... - Page 8 Language Menu Select the language OSD H. Pos. Move the OSD left and right on the screen OSD V. Pos. Move the OSD up and down on the screen OSD Timer Adjust OSD display time setting Transparency Adjust OSD Transparency Mode Select PC/GAME/MOVIE display mode Others...
-
Page 9: Specification
Specification L-W22C L-W24C L-W27C Panel Size 21.5” 23.6” 27” Max resolution 1920x1080/WXGA 1920x1080/WXGA 1920x1080/WXGA Display Color 16.7M 16.7M 16.7M Pixel Pitch 0.248mm x 0.248mm 0.2715mm x 0.2715mm 0.311mm x 0.311mm Brightness 250cd/m 250cd/m 250cd/m Contrast Ratio 30,000,000:1 (DCR) 30,000,000:1 (DCR) -
Page 10: Display Mode
59.887 106.5 WSXGA+ 1680 x 1050 65.29 59.954 146.25 Full HD 1920 x 1080 67.5 60.1 Company Address: 5F-1, No. 3-1, Park Street, Nangang District, Taipei, 11503, Taiwan. Copyright © 2016 AG Neovo. All rights reserved. L-W22C/ L-W24C/ L-W27C _UM_V010...
