GENERAL SAFETY INSTRUCTIONS
High Voltage Warning
Dangerous voltages are present within the power supply.
Critical Components
This product is not authorised for use as a critical component in nuclear control systems, life
support systems or equipment for use in hazardous environments without the express written
approval of the Managing Director of TDK-Lambda UK Ltd.
Servicing
This product is not customer serviceable.
Unit repairs shall only be carried out by TDK- Lambda UK Ltd or their authorised agents.
Contact: TDK-Lambda UK Ltd
Kingsley Avenue
Ilfracombe
Devon, EX34 8ES
Tel 01271 856600
Fax 01271 864894
Safety Class of Protection
The unit is designed for the following parameters : Material Group IIIb, Pollution Degree 2,
Overvoltage Category II, Class 1 (earthed), Indoor use. The unit is considered as fixed and
rated IPX0. The CPFE500F-12 and CPFE500F-24 are classed as having SELV outputs.
The CPFE500F-48 is classed as having a NON SELV output. All outputs are capable of
providing hazardous energy (>240VA). The final equipment should provide protection to
service personnel against inadvertent contact with the PSU output terminals.
Installation
This product is designed for use within other equipment which restrict access to authorised
competent personnel only. The unit covers/chassis must not be made user accessible.
The appliance may be mounted in any orientation except inverted (baseplate uppermost).
The customer has to ensure the baseplate temperature remains below certain limits.
Horizontal orientation input 90-149V baseplate temperature limited to 75°C.
Horizontal orientation input 150V or greater baseplate temperature limited to 85°C.
All other orientations baseplate temperature limited to 85°C.
With open frame version, any orientation is permitted at 85°C baseplate temperature.
The mains input connector is not acceptable for use as field wiring terminals.
The appliance must be securely mounted and the baseplate properly bonded to the main
protective earth contact before any connection to AC mains supply is made.
The ventilation openings must not be impeded – ensure a space at least 5cm between any
obstruction and the ventilation openings.
HANDBOOK FOR CPFE500F SERIES
Page 1
Environmental Parameters
Operation
0 0 (note 1,2)
Temperature -40 C to +50 C
Humidity 30% to 90% RH, non-
condensing
Air Pressure 70kPa to 106kPa
Altitude -200m to 2000m
* Note 1 – heatsinking must be provided to ensure the PSU baseplate temperature does not exceed 85DegC (see diagram for measurement location)
and installation notes.
* Note 2 – For 3 year life expectancy, continuous temperature of electrolytic capacitors should not exceed :-
Level of Insulation
Primary mains circuit to earth
Primary mains circuit to output
Output to earth
Input Parameters
Maximum input voltage range
Nominal input voltage range
Input frequency range
Maximum input current
Earth leakage
Efficiency (25°c,100% Load)
* Note 3 - In cases where conformance to various specs (UL, EN) are required, input voltage range will be 100~240VAC(50/60Hz).
Output Parameters
CPFE500F-12
Nom output Voltage 12VDC ± 1%
(note 4)
Max adjust range 9.6-14.4V
Maximum output 42A
current
Overcurrent protection 105-140%
Overvoltage 125-145% latched
Protection shutdown
Over-temp Protection Latched Shutdown
at 90~115°C
baseplate
temperature
* Note 4 - Max output power is limited to 504W
Storage & Transportation
0 0
-40 C to +85 C
10% to 95% RH, non-condensing
54kPa to 106kPa
-200m to 2000m
C11,12,25,26 67.5°c
C22,23,16,17 81°c
2.25~2.35KVDC
4.25~4.35KVDC
500VDC max
(note 3)
85 – 265VAC
100 – 240VAC
(note 3)
47 – 63 Hz
8.2Arms
1650µA Max
80% min
CPFE500F-28 CPFE500F-48
28VDC ± 1% 48VDC ± 1%
22.4-33.6V 38.4-57.6V
18A 10.5A
105-140% 105-140%
125-145% latched 125-145% latched
shutdown shutdown
Latched Shutdown Latched Shutdown
at 105~130°C at 105~130°C
baseplate baseplate
temperature temperature
