BEFORE USING THE POWER SUPPLY UNIT
Be sure to read this instruction manual thoroughly before using this product. Pay attention to all cautions and warnings before using this
product. Incorrect usage could lead to an electrical shock, damage to the unit or a fire hazard.
DANGER
· Never use this product in locations where flammable gas or ignitable substances are present.
WARNING
· Do not touch this product or its internal components while it is in operation, or within 5 seconds of shut down. There may be high voltage
or high temperature present and you may receive an electric shock or burn.
· When the product is operating, keep your hands and face away from it as you may be injured by flying debris in the event of a fault.
· Do not make unauthorized changes to this product, otherwise you may receive an electric shock and void your warranty.
· Do not use this product in the event of the emission of smoke or abnormal smell and sound etc. It might lead to fire and/or electric shock.
In such cases, please contact us. Do not attempt repair by yourself, as it is dangerous for the user.
· Do not operate these products in the presence of condensation. It might lead to fire and/or electric shock.
·
Do not drop or insert anything into the product. It might lead to a failure, fire and/or electric shock.
CAUTION
· This power supply is designed for use within an end product such that it is accessible to SERVICE ENGINEERS only.
· Confirm connections to input/output terminals and signal terminals are correct as indicated in the instruction manual before switching on.
· Input voltage, Output current, Output power, ambient temperature and ambient humidity should be kept within specifications, otherwise
the product will be damaged.
· Do not operate and store this product in an environment where condensation might occur. In such case, waterproof treatment is necessary.
·
Never operate the unit under over current or shorted conditions for 30 seconds or more and out of Input Voltage Range as specification. Insulation failure,
smoking, burning or other damage might occur to the unit.
· Do not use this product in environment with a strong electromagnetic field, corrosive gas or conductive substances.
· For applications which require very high reliability (Nuclear related equipment, traffic control equipment, etc.), it is necessary to provide a
fail safe mechanism in the end equipment.
· The information in this document is subject to change without prior notice. Please refer to the latest version of the data sheet, etc., for the
most up-to date specifications of the product.
· No part of this document may be copied or reproduced in any form without prior written consent of TDK-Lambda.
· Do not inject abnormal voltages into the output or signal of this product. The injection of reverse voltage or over voltage exceeding
nominal output voltage into the output or signal terminals might cause damage to internal components.
· Operation of this product under over-current or short circuit conditions can result in damage. Failures of the product under these conditions
have been assessed and are considered to be safe within the meaning of IEC/EN/UL/CSA 60950-1.
· This product contains a printed circuit board utilizing surface mounted devices. PCB stress such as bending, twisting etc could cause
damage. Therefore, please handle with care.
· In order to maintain SELV output, the base-plate must be protectively earthed in the end application. Where the base-plate is not earthed,
the output must be considered hazardous and must not be made user accessible.
· The output of this product may, under fault conditions, exceed SELV voltage limits. Therefore the output must be earthed in the end
equipment to maintain SELV. If the output is not earthed, they must be considered hazardous and must not be made user accessible.
· For input terminal of this product, connect DC input source with reinforced insulation or double insulation.
· The application circuits and their parameters are for reference only. Be sure to verify effectiveness of these circuits and their parameters
before finalizing the circuit design.
·
Use an HBC external fuse to each module to ensure safe operation and compliance with the Safety Standards to which it is approved.
CN-A24 SERIES
Instruction Manual
TDK-Lambda
CN-A24 Series
Instruction Manual
C259-04-11B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CN-A24 and is the answer not in the manual?

Questions and answers

Summary of Contents for TDK-Lambda CN-A24

  • Page 1 · No part of this document may be copied or reproduced in any form without prior written consent of TDK-Lambda. · Do not inject abnormal voltages into the output or signal of this product. The injection of reverse voltage or over voltage exceeding nominal output voltage into the output or signal terminals might cause damage to internal components.
  • Page 2: Table Of Contents

    TDK-Lambda CN-A24 Series Instruction Manual Table of Contents ■ Block Diagram ■ Sequence Time Chart ■ Terminal Explanation ■ Explanations on Specifications Input Voltage Range Output Voltage Adjustment Range Maximum Output Ripple and Noise Maximum Line Regulation Maximum Load Regulation Base-plate Temperature vs.
  • Page 3: Block Diagram

    TDK-Lambda CN-A24 Series Instruction Manual ■ Block Diagram +Vin -Vin ※: 5V model Only ※:5V model Only Switching frequency(fixed) : 360kHz ● ■ Sequence Time Chart - 2 -...
  • Page 4: Terminal Explanation

    TDK-Lambda CN-A24 Series Instruction Manual ■Terminal Explanation -Vin Name Plate +Vin [Input Side Terminals] [Output Side Terminals] : -Input Terminal : -Output Terminal -Vin : ON/OFF Control Terminal : -Remote Sensing Terminal +Vin : +Input Terminal TRM : Output Voltage Trimming Terminal...
  • Page 5: Explanations On Specifications

    TDK-Lambda CN-A24 Series Instruction Manual ■ Explanations on Specifications Input Fuse 1. Input Voltage Range This power module has no built-in fuse. Use external fuse Input voltage range for CN100A24 Series is indicated to acquire various Safety Standards and to improve safety.
  • Page 6: Output Voltage Adjustment Range

    TDK-Lambda CN-A24 Series Instruction Manual Reverse Input Connection C2 : 2.2μF Reverse input polarity would cause module damage. To reduce spike noise voltage at the output, connect For cases where reverse connections are possible, connect 2.2μF ceramic capacitor between +V and –V at 50mm a protective diode and fuse.
  • Page 7 TDK-Lambda CN-A24 Series Instruction Manual Output Voltage Adjustment by External Resistor or (2) In case of adjusting output voltage higher (2-1) Allowable maximum output current = maximum Variable Resistor (1) In case of adjusting output voltage lower output power ÷ adjusting output voltage.
  • Page 8: Maximum Output Ripple And Noise

    TDK-Lambda CN-A24 Series Instruction Manual Note : (3) To adjust output voltage for whole range Resistor values, as well as, connecting methods for Please connect the amplifier so as not to interfere external resistor (R1) and external variable resistor(VR) in internal impedance of the trim circuit when you are described below.
  • Page 9: Maximum Line Regulation

    TDK-Lambda CN-A24 Series Instruction Manual 4. Maximum Line Regulation OVP reset input voltage value : 10VDC and below Verifying OVP function shall be done by increasing Maximum value of output voltage change when input output voltage with external resistor. For verifying OVP...
  • Page 10: On/Off Control (Cnt Terminal)

    0.1uF capacitor between CNT terminal and –Vin terminal. 14. Series Operation 3. At L level, source current from CNT terminal to Series operation is possible for CN-A24 series. –Vin terminal is 0.4mA‐0.5mA. Connections shown in fig. 14-1 and fig. 14-2 are possible.
  • Page 11: Operating Ambient Temperature

    TDK-Lambda CN-A24 Series Instruction Manual 15. Operating Ambient Temperature 17. Storage Ambient Temperature There is no restriction on mounting direction but there Take note that sudden temperature changes can cause should be enough consideration for airflow so that heat condensation buildup, and other harmful affects to each does not accumulate around the power module vicinity.
  • Page 12: Isolation Resistance

    TDK-Lambda CN-A24 Series Instruction Manual 21. Isolation Resistance Use DC isolation tester (MAX 500V) between output and base-plate. Isolation resistance value is 100MΩ and above at 500VDC applied voltage. Make sure that during testing, the isolation testers do not generate a high pulse when the applied voltage is varied.
  • Page 13: Installation

    TDK-Lambda CN-A24 Series Instruction Manual ■ Installation 1. Mounting Method For position of the holes, see outline drawing of the By the following instruction shown in Fig.1-1, mount power module. power module onto printed circuit board. (4) Recommended Material of PCB...
  • Page 14: Recommended Soldering Condition

    TDK-Lambda CN-A24 Series Instruction Manual 4. Recommended Soldering Condition Recommended soldering conditions are as follows. (1) Soldering dip Dip condition : 260ºC within 10 seconds Pre-heat condition : 110ºC for 30 - 40 seconds (2) Soldering iron 350ºC within 3 seconds...
  • Page 15: Before Concluding Power Module Damage

    TDK-Lambda CN-A24 Series Instruction Manual ■ Before concluding power module damage Verify following items before concluding power module damage. 1) No output voltage ・Is specified input voltage applied? ・ Are the ON/OFF control terminal (CNT), remote sensing terminal (+S, –S), output voltage trimming terminal (TRM) correctly connected? ・...
  • Page 16: Option Heatsink

    ■ Option Heatsink Model Heatsink Size(W×H×D mm) Thermal Resistance *1 CN-A24 HAQ-10T 57.9×25.4×36.8 7.5℃/W *1: at convection cooling 1. For CN-A24 (1) HAQ-10T 〈Convection cooling〉 Thermal resistance: 7.5℃/W 〈Forced air cooling〉 57.9±1.0 49.7±0.2 P6.9 5=34.5 × 12-R0.5 Average air velocity [m/s] (2.0)
