Generac Power Systems HTS Wn Owner's Manual page 52

ITEM PART NO. QTY.
1 0F8934 1
2 0F5083 1
0G3009 1
0G3009A 1
0G2749 1
3 0F4284 1
4 095282 1
5 0F4302A 1
6 0F4460 2
7 0536210193 1
8 077228 1
9 0F5508L 1
0F5508M 1
10 0F5503 1
11 074525 1
12 072164 1
13 0F4801 1
14 0F5926 1
15 0F5901 1
16 0F5180 3
17 * 0F4410 1
18 * 0G5641A 1
19 0F4802 1
20 0D3610 1
21 * 055868 1
24 074654 2
064933 2
25 * 046357 REF
26 0F5039 1
27 * 027911 REF
28 064510 1
29 063578 1
30 054199 1
31 062209 1
32 083736 1
33 0D6584 1
34 067210A 1
35 * 046689 REF
36 0F5040 1
37 075355 1
38 0D4203 1
39 0A9457 1
40 091472 1
41 091472A 1
42 072115 1
072121 1
072116 1
072122 1
50
Section 8 — Exploded Views & Parts Lists
Assembly — Drawing No. 0F8939-E - Page 3
DESCRIPTION
AV HTS 2000-2600A NEMA12
DECAL HTS TRANSFER SWITCH
DECAL HTS T/S
DECAL HTS T/S
DECAL, HTS T/S
KEYPAD COMM XFER SW IN-PHASE
DECAL-LIVE CIRCUIT
ASSY KEYPAD INTERFACE 32" HTS
SPACER M4/#8 X 5/16 X 1/4 NYL
ASSY WIRE #0 12.00" (GROUND
WIRE)
DECAL-ENCLOSURE NOTE
DECAL HTS TEST SEQUENCE 2000A
DECAL HTS TEST SEQUENCE 2600A
DECAL SWITCH INFO
DECAL MANUAL OPERATION
MNL HNDL 6-1600A WN (SUPPLIED
W/SW)
PLATE MOUNTING PCB ASSEMBLY
ASSY COVER PCB COM XFER SWTCH
ASSY COVER COMM XFER SWITCH
BATTERY AAA
ASSY PCB COMM TRANSFORMER
ASSY PCB OTS RELAY-COMM XFERSW
BRACKET TOGGLE SWITCH
DECAL MAINTENANCE DISCONNECT
SWITCH TOGGLE 4PDT 15A SPADE
TRANSFRM 600V TO 240V 500VA
TRANSFRM 240/480V-120/480V
BLOCK TERM 20A 6 X 6 X 1100V
LABEL CPL (CT) TB1
RELAY PNL 12VDC DPDT 10A@240VA
DECAL-TERMINAL NOTE
PLATE DATA - GTS
DECAL DANGER HIGH VOLTAGE
DECAL UL LABEL E84929-GTS
DECAL-CSA GTS
ASSY GRD.TERM.1600-2600A
DECAL GROUND LUG
BLOCK TERM 20A 4 X 6 X 1100V
LABEL CPL (RS485) TB2
DECAL SIGNAL BEFORE XFER
ASSY NEUTRAL BLOCK 1600A ATS
DECAL NEUTRAL
DUCT WIRING 1 X 1.5 (138" LG)
COVER WIRE DUCT 1 IN (138" LG)
XFRSW 2000A 3P WN600V
XFRSW 2000A 4P WN600V
XFRSW 2600A 3P WN600V
XFRSW 2600A 4P WN600V
ITEM PART NO. QTY.
43 0F8932A 2
0F8932B 2
0F8932C 2
44 0D6391 1
45 0C8308 2
46 * 0F8941$ 1
47 0F6888 1
48 0F6776A 1
49 0F6776B 1
53 074672A 1
55 0C8095 1
56 0C7942 4
57 0F9340 1
58 0G7015 1
100 0C6748 2
101 0F7806 13
102 038150 2
103 022264 2
104 087680 1
105 0D6511 12
106 0E6423 12
107 0C2212 4
108 0A2111 2
109 0C2267 8
110 0A1661 REF
111 092980 2
113 022237 4
114 022195 4
115 022196 4
116 067989 2
117 063378 8
118 091477 5
119 0F5272 12
122 022304 8
123 0A5768 10
124 048610 4
125 029333A 2
126 064101 REF
127 022131 4
128 0C6937A 4
129 029745 4
130 022473 4
131 025870 4
DESCRIPTION
BRKT SWITCH 2000A 3P
BRKT SWITCH 2000A 4P-2600A 3P
BRKT SWITCH 2600A 4P
SHIELD TRANSFER SW 2000-2600A
DECAL TERMINAL SHOCK HAZARD
WIRE HARNESS HTS 2000-2600A
(NOT SHOWN)
SUB-PLATE HTS 600-2600A
DECAL DIP SWITCH CONFIG PCB
COVER
DECAL DIP SWITCH CONFIG ENCL
SWITCH MICRO DPDT SEL & AUX 2PL
WIRE HARN. STRIP 16"
HARN STRIP 8"
TAG BATTERY DISCONNECT
TVSS ASSEMBLY 600-2600A
NUT HEX LOCK M4-0.7 SS NYL INS
NUT HEX FL WHIZ M4-0.7
WASHER FLAT #8 ZINC
WASHER LOCK #8-M4
NUT WING M6-1.0
SPACER .20 X .375 X .375 PL
NUT HEX FL WHIZ M5-0.8
SCREW PHTT M4-0.7 X 16 ZYC
SCREW SWAGE #10-32 X 5/16 ZYC
SCREW HHTT M5-0.8 X 12 BP
RIVET POP .156 X .675 AL
SCREW PPHM M4-0.7 X 25
WASHER LOCK 3/8
WASHER LOCK 1/2
NUT HEX 1/2-13 STEEL
NUT HEX FL WHIZ M8-1.25
HOLDER CABLE TIE
RIVET WIRE DUCT MNT
CLAMP CABLE FLAT
WASHER FLAT 1/2 ZINC
WASHER FLAT M10 HEAVY DUTY
SCREW HHC 1/2-13 X 1 G5
TIE WRAP UL 7.4" X .19" BLK
NUT HEX FL WHIZ 3/8-16
WASHER FLAT 3/8-M10 ZINC
INSULATOR STANDOFF 3200V3/8-16
SCREW HHC 3/8-16 X 1 G5
WASHER FLAT 1/4-M6 ZINC
NUT WING 1/4-20
