Power Source Selection (JP24)
The power for the expansion board can be supplied either from the development board connec-
tor (1) or from an external power source (4).
Power Source
Internal (via developmnet board connector)
External (via external power connector)
®
Anybus
CompactCom Starter Kit Reference Guide
Jumper Location
1-2
2-3
15 (20)
HMSI-27-224 2.0
