Description
Header
JP8
Rx
Tx
MI0
MI1
MD0
(NC)
(NC)
(NC)
Please refer to the Anybus CompactCom M40/M30 Hardware Design Guide for more
information.
3.4

Option Board Overview (Brick)

The option board for brick provides in-circuit access to all signals of the Anybus CompactCom
host interface, allowing in-circuit debugging and evaluation capacities.
The option board operates at 3.3 VDC.
Fig. 5
No
1
2
3
4
®
Anybus CompactCom Starter Kit Reference Guide
Signal
Signal Name
Name
Serial Mode
Printed on
Board
RX RX
TX TX / OM3
MI0 MI0
MI1 MI1
MD0 MD0
(NC)
(NC)
(NC)
4
2
1
Description
Brick adaptor card
USB base board
See Connectors, p. 8.
See Control Switches, p. 9.
Shift SPI Mode
Register
ASM RX ASM RX
ASM TX / ASM TX /
OM3 OM3
MI0 MI0/SYNC
MI1 MI1
MD0 MD0
12 (20)
8-bit Mode 16-bit Mode
ASM RX ASM RX
ASM TX / ASM TX /
OM3 OM3
MI0/SYNC MI0/SYNC
MI1 MI1
MD0 MD0
3
HMSI-27-224 2.0
