Description
Header
JP17
JP20
JP21
JP22
Signals TxD and RxD (JP22) are printed on the board as seen from the application. The signal
names for the different modes are given as seen from the brick.
Please refer to the Anybus CompactCom B40 Hardware Design Guide for more information.
®
Anybus CompactCom Starter Kit Reference Guide
Signal
Signal Name
Name
Serial Mode
Printed on
Board
D7 DIP2_7
D6 DIP2_6
D5 DIP2_5
D4 DIP2_4
D3 DIP2_3
D2 DIP2_2
D1 DIP2_1
D0 DIP2_0
OM0 OM0
OM1 OM1
OM2 OM2
nCS
nWE
nIRQ
nOE
nRESET RESET
D15 LED4A
D14 LED4B
D13 LED3A
D12 LED3B
D11 LED2A
D10 LED2B
D9 LED1A
D8 LED1B
TxD . RX
RxD TX / OM3
IOC0 MI0
IOC1 MI1
(NC)
(NC)
(NC)
(NC)
Shift SPI Mode
Register
DIP2_7 DIP2_7
DIP2_6 DIP2_6
DIP2_5 DIP2_5
DIP2_4 DIP2_4
DIP2_3 DIP2_3
DIP2_2 DIP2_2
DIP2_1 DIP2_1
DIP2_0 DIP2_0
OM0 OM0
OM1 OM1
OM2 OM2
CT
PA IRQ
RESET RESET
LED4A LED4A
LED4B LED4B
LED3A LED3A
LED3B LED3B
LED2A LED2A
LED2B LED2B
LED1A LED1A
LED1B LED1B
ASM RX ASM RX
ASM TX / ASM TX /
OM3 OM3
MI0 MI0/SYNC
MI1 MI1
17 (20)
8-bit Mode 16-bit Mode
D7 D7
D6 D6
D5 D5
D4 D4
D3 D3
D2 D2
D1 D1
D0 D0
OM0 OM0
OM1 OM1
OM2 OM2
CS CS
WE WEL
IRQ IRQ
OE OE
RESET RESET
LED4A D15
LED4B D14
LED3A D13
LED3B D12
LED2A D11
LED2B D10
LED1A D9
LED1B D8
ASM RX ASM RX
ASM TX / ASM TX /
OM3 OM3
MI0/SYNC MI0/SYNC
MI1 MI1
